IKEA Kyld Instruction Manual

IKEA Kyld Instruction Manual

Ikea kyld refrigerator instruction manual
Hide thumbs Also See for Kyld:
Table of Contents

Advertisement

Quick Links

See also: User Manual , Manual
KYLD
GB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Kyld and is the answer not in the manual?

Questions and answers

Related Manuals for IKEA Kyld

Summary of Contents for IKEA Kyld

  • Page 1 KYLD...
  • Page 3 ENGLISH...

  • Page 4: Table Of Contents

    Care and cleaning Installation Troubleshooting Product description Technical information Operation IKEA GUARANTEE Daily Use Subject to change without notice. Safety information Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages.

  • Page 5: Safety Instructions

    ENGLISH By clients in hotels, motels, bed and breakfast and other – residential type environments Keep ventilation openings, in the appliance enclosure or in • the built-in structure, clear of obstruction. Do not use mechanical devices or other means to accelerate •...
  • Page 6 ENGLISH flames and sources of ignition in the Electrical connection room. Ventilate the room. Warning! Risk of fire and • Do not let hot items to touch the plastic electrical shock. parts of the appliance. • Do not put soft drinks in the freezer •...

  • Page 7: Installation

    ENGLISH • The refrigerant circuit and the insulation • Do not cause damage to the part of the materials of this appliance are ozone- cooling unit that is near the heat friendly. exchanger. • The insulation foam contains flammable gas. Contact your municipal authority for information on how to discard the appliance correctly.
  • Page 8 ENGLISH with the letter “E“ or by the earth symbol or coloured green and yellow. 2. Connect the wire coloured blue to the terminal either marked with the letter “N“ or coloured black. 3. Connect the wire coloured brown to the terminal either marked with the “L“...

  • Page 9: Product Description

    ENGLISH Product description Product overview Vegetable drawers Least cold zone Glass shelves Intermediate temperature zone Fan - cooling Bottle rack Coldest zone Control panel Dairy compartment with lid Door balcony Bottle balcony Freezer drawer Freezer drawer Freezer drawer...

  • Page 10: Operation

    ENGLISH Operation Control panel Temperature indicators LED Fast Freezing indicator LED Fast Freezing Temperature regulator lights up. Selection is progressive, varying Switching on from 2 to 8°C. Insert the plug into the wall socket. At first button touch actual setting LED keeps blinking.

  • Page 11: Daily Use

    ENGLISH Daily Use Freezing Calendar Freezer blocks Freezer blocks Two freezer blocks are supplied in the 10-12 10-12 10-12 10-12 freezer; this increase the length of time for which food will keep in the event of a The symbols show different types of frozen power failure or breakdown.
  • Page 12 ENGLISH The freezing process lasts 24 hours: during depending on the time available for this this period do not add other food to be operation. frozen. Small pieces may even be cooked still When the freezing process is completed, frozen, directly from the freezer: in this case, return to the required temperature (see cooking will take longer.
  • Page 13 ENGLISH Vegetable Drawers Caution! Do not move the glass shelf above the vegetable drawer to ensure correct air circulation. Bottle rack Place the bottles (with the opening facing front) in the pre-positioned shelf. Fruit and vegetables should be placed in these drawers (see the picture).

  • Page 14: Hints And Tips

    ENGLISH The green light (B) comes on. Fan - cooling The fan - cooling function let food cool quickly and a more uniform temperature in the compartment. Switch on the fan - cooling function when the ambient temperature exceeds 25°C. 2.

  • Page 15: Care And Cleaning

    ENGLISH wrapped in aluminium foil or polythene avoiding a rise in temperature of the bags to exclude as much air as possible. latter; • Bottles: these need a cap and should be • lean foods store better and longer than stored on the door bottle shelf, or (if fatty ones;...
  • Page 16 ENGLISH This operation will improve the should be washed with lukewarm water performance of the appliance and save and some neutral soap to remove the electricity consumption. typical smell of a brand-new product, then dried thoroughly. Periods of non-operation Caution! Do not use detergents When the appliance is not in use for long or abrasive powders, as these periods, take the following precautions:...

  • Page 17: Troubleshooting

    ENGLISH cleaner provided, which you will find it is in operation, neither on the internal already inserted into the drain hole. walls nor on the foods. The absence of frost is due to the continuous No defrosting of the freezer circulation of cold air inside the The freezer compartment of this model, on compartment, driven by an automatically...
  • Page 18 ENGLISH Problem Possible cause Solution Food products placed in Allow food products to cool to the appliance were too room temperature before stor- warm. ing. The door is not closed cor- Refer to "Closing the door". rectly. The Fast Freezing function Refer to "Fast Freezing func- is switched on.

  • Page 19: Technical Information

    ENGLISH Problem Possible cause Solution The door has been Open the door only if necessa- opened often. The Fast Freezing function Refer to "Fast Freezing func- is switched on. tion". There is no cold air circula- Make sure that there is cold tion in the appliance.

  • Page 20: Ikea Guarantee

    IKEA GUARANTEE How long is the IKEA guarantee valid? The range of appliances named LAGAN and all appliances purchased in IKEA This guarantee is valid for five (5) years...
  • Page 21 IKEA. service providers and/or an authorized service contractual partner or where What will IKEA do to correct the problem? non-original parts have been used. IKEA appointed service provider will • Repairs caused by installation which is examine the product and decide, at its sole faulty or not according to specification.
  • Page 22 EU country and taken to another EU Please refer to the last page of this manual country, the services will be provided in the for the full list of IKEA appointed contacts framework of the guarantee conditions and relative national phone numbers.

  • Page 23: Environmental Concerns

    ENGLISH ENVIRONMENTAL CONCERNS dispose appliances marked with the symbol Recycle the materials with the symbol with the household waste. Return the Put the packaging in applicable containers product to your local recycling facility or to recycle it. Help protect the environment contact your municipal office.
  • Page 24 0900 235 45 32 ma - vr 08.00 - 20.00, 15 cent/min., starttarief 4.54 cent Nederland en/of zat 09.00 - 20.00 en gebruikelijke belkosten 0900 BEL IKEA (zondag gesloten) Österreich 0810 300486 max. 10 Cent/min. Mo - Fr 8.00 - 20.00 Uhr Polska...
  • Page 25 ENGLISH...
  • Page 26 ENGLISH...
  • Page 27 ENGLISH...
  • Page 28 21552 © Inter IKEA Systems B.V. 2014 AA-1082308-1...

This manual is also suitable for:

Kylig
