Icom IC-E90 Service Manual page 35

[RF UNIT]
REF ORDER
NO. NO.
J251 6510022860 S.CONNECTOR AXK6S30445P
J252 6450000870 CONNECTOR
W1 7030010040 S.JUMPER
W2 7030010040 S.JUMPER
EP1 0910055443 PCB
EP2 6910013310 S.BEAD
EP3 6910014640 S.BEAD
EP4 6910014640 S.BEAD
EP5 6910014640 S.BEAD
EP6 6910014640 S.BEAD
[AF UNIT]
REF ORDER
NO. NO.
IC51 1130007570 S.IC
IC151 1110003200 S.IC
IC251 1110004520 S.IC
IC252 1110001810 S.IC
Q1 1530003010 S.TRANSISTOR 2SC4117-GR (TE85R)
Q2 1530003220 S.TRANSISTOR 2SC4406-4-TL
Q11 1590001170 S.TRANSISTOR XP1501-(TX) .AB
Q51 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q52 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q53 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q54 1590002700 S.TRANSISTOR XP4214 (TX)
Q55 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q56 1590002700 S.TRANSISTOR XP4214 (TX)
Q57 1540000350 S.TRANSISTOR 2SD2216-S (TX)
Q58 1590002380 S.TRANSISTOR XP1115 (TX)
Q59 1590001690 S.TRANSISTOR UN9115 (TX)
Q61 1590001690 S.TRANSISTOR UN9115 (TX)
Q62 1590002380 S.TRANSISTOR XP1115 (TX)
Q63 1590002380 S.TRANSISTOR XP1115 (TX)
Q64 1510000620 S.TRANSISTOR 2SA1576 T106 S
Q65 1590001730 S.TRANSISTOR UN9113 (TX)
Q66 1590001730 S.TRANSISTOR UN9113 (TX)
Q67 1590001730 S.TRANSISTOR UN9113 (TX)
Q101 1590001980 S.TRANSISTOR XP4315 (TX)
Q102 1530002560 S.TRANSISTOR 2SC4403-3-TL
Q103 1590001730 S.TRANSISTOR UN9113 (TX)
Q201 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q202 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q203 1550000010 S.FET
Q204 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q205 1540000350 S.TRANSISTOR 2SD2216-S (TX)
Q206 1590001980 S.TRANSISTOR XP4315 (TX)
Q207 1590002380 S.TRANSISTOR XP1115 (TX)
Q208 1510000510 S.TRANSISTOR 2SA1576A T106R
Q209 1590001170 S.TRANSISTOR XP1501-(TX) .AB
Q251 1550000010 S.FET
Q253 1590001690 S.TRANSISTOR UN9115 (TX)
D1 1750000770 S.VARICAP
D2 1750000360 S.DIODE
D3 1750000360 S.DIODE
D51 1790001240 S.DIODE
D52 1790001250 S.DIODE
D101 1750000360 S.DIODE
D102 1750000360 S.DIODE
D103 1790000860 S.DIODE
D104 1790001250 S.DIODE
D151 1750000360 S.DIODE
D152 1750000360 S.DIODE
D201 1750000360 S.DIODE
FI101 2020001950 S.CERAMIC
FI102 2020001940 S.CERAMIC
FI151 2020001270 CERAMIC
DESCRIPTION
HEC2711-01-020
ERJ2GE-JPW
ERJ2GE-JPW
B 5845C
MMZ1608D121B
MPZ2012S221A-T
MPZ2012S221A-T
MPZ2012S221A-T
MPZ2012S221A-T
DESCRIPTION
BU4094BCFV-E2
TA31136FN (EL)
M5222FP 600C
TA7368F (TP1)
2SJ364-Q (TX)
2SJ364-Q (TX)
HVC376BTRF
1SS364 (TE85L)
1SS364 (TE85L)
MA2S728-(TX)
MA2S111-(TX)
1SS364 (TE85L)
1SS364 (TE85L)
MA133 (TX)
MA2S111-(TX)
1SS364 (TE85L)
1SS364 (TE85L)
1SS364 (TE85L)
FL-338 (69.450 MHz)
SFECS13M3DA0001-B0 (SFECS13.35M
CFWLB450KE2A-B0 (CFWM450E)
[AF UNIT]
REF ORDER
NO. NO.
X1 6050010160 S.XTAL
L3 6200004600 S.COIL
L4 6200004590 S.COIL
L5 6200004590 S.COIL
L8 6200005700 S.COIL
L9 6200004600 S.COIL
L101 6200004480 S.COIL
L103 6200004780 S.COIL
L104 6200001980 S.COIL
L151 6150005010 S.COIL
R1 7030005600 S.RESISTOR
R2 7030005090 S.RESISTOR
R3 7030005090 S.RESISTOR
R4 7030006610 S.RESISTOR
R5 7030004970 S.RESISTOR
R7 7030005120 S.RESISTOR
R8 7030005240 S.RESISTOR
R9 7030004970 S.RESISTOR
R10 7030008010 S.RESISTOR
R11 7030008400 S.RESISTOR
R12 7030008010 S.RESISTOR
R13 7030008010 S.RESISTOR
R51 7030005040 S.RESISTOR
R52 7030005000 S.RESISTOR
R54 7030005040 S.RESISTOR
R55 7030005000 S.RESISTOR
R56 7030005040 S.RESISTOR
R57 7030005000 S.RESISTOR
R58 7030005050 S.RESISTOR
R59 7030005050 S.RESISTOR
R60 7030005000 S.RESISTOR
R61 7030005090 S.RESISTOR
R62 7030005160 S.RESISTOR
R63 7030005040 S.RESISTOR
R64 7030007290 S.RESISTOR
R101 7030005040 S.RESISTOR
R102 7030005040 S.RESISTOR
R103 7030005040 S.RESISTOR
R104 7030005040 S.RESISTOR
R105 7030005040 S.RESISTOR
R107 7030007340 S.RESISTOR
R108 7030005290 S.RESISTOR
R109 7030004970 S.RESISTOR
R110 7030004990 S.RESISTOR
R111 7030004990 S.RESISTOR
R112 7030005040 S.RESISTOR
R113 7030007270 S.RESISTOR
R114 7030007280 S.RESISTOR
R151 7030005220 S.RESISTOR
R152 7030007290 S.RESISTOR
R153 7030007570 S.RESISTOR
R154 7030005120 S.RESISTOR
R155 7030005720 S.RESISTOR
R156 7030007340 S.RESISTOR
R158 7030005110 S.RESISTOR
R159 7030005040 S.RESISTOR
R161 7030008010 S.RESISTOR
R162 7030005040 S.RESISTOR
R163 7030008010 S.RESISTOR
R164 7030008010 S.RESISTOR
R165 7030008010 S.RESISTOR
R166 7030008010 S.RESISTOR
R167 7030005110 S.RESISTOR
R201 7030005000 S.RESISTOR
R202 7030005230 S.RESISTOR
R203 7030009280 S.RESISTOR
R204 7030005050 S.RESISTOR
R205 7030005240 S.RESISTOR
R206 7030005160 S.RESISTOR
R207 7030005110 S.RESISTOR
R208 7030005220 S.RESISTOR
R209 7030005030 S.RESISTOR
R210 7030004980 S.RESISTOR
R211 7030005060 S.RESISTOR
R212 7030007290 S.RESISTOR
R213 7030005040 S.RESISTOR
R214 7030005040 S.RESISTOR
R215 7030008290 S.RESISTOR
6 - 4
DESCRIPTION
CR-583 (13.800 MHz)
MLF1608D R15K-T
MLF1608D R18K-T
MLF1608D R18K-T
ELJRE 22NG-F
MLF1608D R15K-T
MLF1608D R82K-T
MLF1608A 1R5K-T
NL 252018T-1R0J
LS-528 (637AN-0223GW=P3)
ERJ2GEJ 273 X (27 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 394 X (390 kΩ)
ERJ2GEJ 470 X (47 Ω)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 470 X (47 Ω)
ERJ2GEJ 123 X (12 kΩ)
ERJ2GEJ 182 X (1.8 kΩ)
ERJ2GEJ 123 X (12 kΩ)
ERJ2GEJ 123 X (12 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 471 X (470 Ω)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 471 X (470 Ω)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 471 X (470 Ω)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 471 X (470 Ω)
ERJ2GEJ 104 X (100 kΩ)
ERJ2GEJ 105 X (1 MΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 222 X (2.2 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 153 X (15 kΩ)
ERJ2GEJ 682 X (6.8 kΩ)
ERJ2GEJ 470 X (47 Ω)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 221 X (220 Ω)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 151 X (150 Ω)
ERJ2GEJ 331 X (330 Ω)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 222 X (2.2 kΩ)
ERJ2GEJ 122X (1.2 kΩ)
ERJ2GEJ 102 X (1 kΩ)
ERJ2GEJ 563 X (56 kΩ)
ERJ2GEJ 153 X (15 kΩ)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 123 X (12 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 123 X (12 kΩ)
ERJ2GEJ 123 X (12 kΩ)
ERJ2GEJ 123 X (12 kΩ)
ERJ2GEJ 123 X (12 kΩ)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 471 X (470 Ω)
ERJ2GEJ 334 X (330 kΩ)
ERJ2GE
ERJ2GEJ 103 X (10 kΩ)
ERJ2GEJ 473 X (47 kΩ)
ERJ2GEJ 105 X (1 MΩ)
ERJ2GEJ 224 X (220 kΩ)
ERJ2GEJ 223 X (22 kΩ)
ERJ2GEJ 152 X (1.5 kΩ)
ERJ2GEJ 101 X (100 Ω)
ERJ2GEJ 333 X (33 kΩ)
ERJ2GEJ 222 X (2.2 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 472 X (4.7 kΩ)
ERJ2GEJ 183 X (18 kΩ)
S.=Surface mount
