Problem Solving Guide

Thermal motor protection

Your Symmetry is equipped with a
safeguard to recognize when the vacuum
heats up and shuts itself down to protect
your vacuum cleaner. Note that when this
happens, the headlight is still on but the
motor shuts off. Common reasons why a
vacuum may overheat include operating a
vacuum with a full bag or when there is a
clog in the vacuum.
• Unplug the vacuum.
• Inspect your vacuum for a full bag
condition or a hose clog and correct
the problem. Locate the Thermal Motor
Reset button on the back of the vacuum.
Press button and resume vacuuming.
If problem continues, contact your
Authorized Simplicity Retailer.
Thermal Reset
1. Unplug machine 3. Correct problem
2. Locate problem 4. Press reset button
source (clogged
If problem persists,
hose or full bag) consult owner' s manual
or contact retailer.
1. Unplug machine 3. Correct problem
2. Locate problem 4. Press reset button
source (clogged
hose or full bag)
26

Trouble Shooting

PROBLEM POSSIBLE REASON
Vacuum won't turn on • Power cord not firmly
plugged in
• Blown fuse or tripped
breaker
• Needs service
Vacuum won't pick up or • Vacuum bag full
low suction • Clogged filter
• Hose clogged
• Worn brushroll
• Broken belt
Dust escaping from vacuum • Dust cover not installed
properly
• Filter not installed
correctly
• Vacuum bag not installed
correctly
Any other service should be done by an
Authorized Service Representative.
Service 1-888-9-SIMPLY
To locate your nearest retailer, visit our website at
www.simplicityvac.com
Problem Solving Guide
POSSIBLE SOLUTION
• Plug unit in firmly
• Check house fuse or
breaker. Replace fuse /
reset breaker.
• Take to Authorized Retailer
(1-888-9-SIMPLY)
• Install new bag
• Install new filter
• Remove obstacle
• Replace brush strips
• Replace belt
• Reinsert the dust cover
and secure latch
• Review filter installation
(page 19)
• Review bag installation
(page 18)
