Summary of Contents for Simplicity Symmetry
- Page 1 (The chances are you’ r e never going to read me) Owner’s Manual all models www.simplicityvac.com...
-
Page 2: Table Of Contents
Contents IMPORTANT SAFETY INSTRUCTIONS .............. Polarization instructions ................... Description of the vacuum ................Before using your Symmetry the first time ............Operation Unwinding the power cord ................Turning vacuum on / off .................. Vacuuming carpet .................... Vacuuming hard surfaces ................. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Polarization Instructions When using an electrical appliance, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE POWER CORD, 2-WIRE POLARIZED CORD Household Models: SYM, SYMUSA, SYMCLNT, SYMCL, USING THIS APPLIANCE SYMS, SYMD, SYMPNT & SYMP WARNING: The manufacturer cannot accept responsibility for damage To reduce the risk of electric shock, this product is... -
Page 4: Description Of The Vacuum
Description of the vacuum Description of the vacuum Description of the vacuum Description of the vacuum Ergonomic handle Main on / off power switch (for models SYM, SYMS, SYMD, SYMPNT, SYMP, SYMCNT & SYMC) Power Cord Carrying handle Bag compartment cover (to replace vacuum bag) Xenon headlight Vacuum nozzle Furniture guard... -
Page 5: Before Using Your Symmetry For The First Time
Before using your Symmetry for the first time Operation Attaching the handle to the vacuum Unwinding the power cord The vacuum cleaner and the handle are • The upper cord hook rotates to allow for packed separately. quick access to the power cord. -
Page 6: Vacuuming Carpet
Carpet height adjustment “on / off” switch located on the side of bag compartment to the “on” position as Your Simplicity upright vacuum cleaner is indicated on the switch. designed with an automatic self-adjusting rug nozzle. No manual adjustments are required. -
Page 7: Vacuuming Under Furniture
Operation Operation Vacuuming under furniture Carrying the vacuum Your Simplicity Symmetry will lay flat on the To safely transport your vacuum, especially floor for effective cleaning under beds when carrying the vacuum up and down and tables. stairs, use the carry handle. -
Page 8: Attachment Cleaning
SYMD, SYMP & SYMC With the on-board cleaning tools and vacuum Your vacuum is equipped with a dusting brush, wand, your Simplicity Symmetry becomes a upholstery brush and crevice tool. Other tools comprehensive cleaning system. The models are available at your Authorized Simplicity equipped with on-board tools include an Retailer. -
Page 9: Cleaning Tools
These kits are effective overall cleaning tools to address some of the hard to reach areas of your home or car. Talk to your Simplicity Retailer to see which tools might be beneficial for your home. Deluxe Attachment Set (SDAK1) 1. - Page 10 There is no way to turn the brushroll off. attachment cleaning. Therefore, when using the cleaning tools it is important to keep your Simplicity vacuum from running in the same spot for a period of time, as Note: The vacuum bags are disposable carpet or flooring damage could result.
-
Page 11: Maintenance And Care
Maintenance and Care Maintenance and Care Replacing the vacuum bag When to change filters • Open the bag compartment lid. At minimum, it’s recommended to replace the filters once a year or after using twelve • Remove vacuum bag by pulling bag collar vacuum bags, whichever comes first. -
Page 12: Removing And Reinstalling Bottom Plate
Maintenance and Care Maintenance and Care Removing and reinstalling bottom plate Replacing the secondary filter CAUTION: Disconnect the vacuum cleaner The secondary filter protects the motor from the electrical outlet before removing the from dust and dirt. Before installing a new bottom plate. -
Page 13: Replacing The Agitator Belt
Maintenance and Care Maintenance and Care Replacing the agitator belt Replacing the agitator belt Models: SYM, SYMUSA, SYMCLNT, Models: SYMPNT & SYMP SYMCL, SYMS, SYMD, SYMCNT & SYMC NOTE: To ensure maximum cleaning efficiency, the condition of the belt should be checked NOTE: To ensure maximum cleaning efficiency, regularly. -
Page 14: Replacing The Headlight Bulb
Annual checkup reminder bottom plate. To keep your vacuum in peak operating condition, it is recommended you bring your vacuum to your Authorized Simplicity Retailer for an annual checkup. Your Retailer will conduct a comprehensive Inlet Tube examination to ensure your vacuum is in top... -
Page 15: Thermal Motor Protection
Problem Solving Guide Problem Solving Guide Thermal motor protection Trouble Shooting Your Symmetry is equipped with a Thermal Reset 1. Unplug machine 3. Correct problem safeguard to recognize when the vacuum 2. Locate problem 4. Press reset button heats up and shuts itself down to protect... -
Page 16: Warranty
Warranty Owner’s Warranty Information keep this for your records… What is Covered: This warranty covers any defects in material and workmanship in your new Simplicity Symmetry vacuum. Date of purchase How Long Coverage Lasts: Warranty coverage for Simplicity Symmetry models SYMUSA, SYMCLNT and SYMCL Serial number lasts three years. - Page 17 www.simplicityvac.com ©2009 Tacony Corporation B503-3400C...
