Summary of Contents for Tuncmatik Eco 1-2-3 kVA
- Page 4 ekil 3 KGK tecrübesi olmayan herhangi bir ki i tarafından çalı tırılabilir.
- Page 8 ü ç ı ı ı ı ı ç ı ö ç ö ç ö ı ı ı ç ç ı ı ç ı ı ı ı ı ı ı ü ı çı ı ı çı ı ı ç ı ç ö...
- Page 10 Akü Modu 4 saniyede bir çalar Akü dü ük Saniyede bir çalar A ırı yük Saniyede iki kere çalar Arıza Sürekli çalar Bypas modu 10 saniyede bir çalar...
- Page 12 ı çı ı ü üç ü ı ü ı ı üç ü ü ö ç ı ı ı ü ç ö ı çı ı ü...
-
Page 23: User Manual
NEWTECH ECO 1-2-3 kVA UNINTERRUPTIBLE POWER SUPPLY USER MANUAL info@tuncmatik.com / www.tuncmatik.com... -
Page 24: Table Of Contents
Table of Contents 1. 1. 1. 1. I I I I S S S S W W W W MPORTANT MPORTANT AFETY AFETY ARNING ARNING MPORTANT MPORTANT AFETY AFETY ARNING ARNING 1-1. Transportation 1-2. Preparation 1-3. Installation 1-4. Operation 1-5. Maintenance, service and faults 2. -
Page 25: Important Safety Warning
1. Important Safety Warning Please comply with all warnings and operating instructions in this manual strictly. Save this manual properly and read carefully the following instructions before installing the unit. Do not operate this unit before reading through all safety information and operating instructions carefully. -
Page 26: Operation
Never connect neutral line of input to neutral line of output. Otherwise, it will cause the damage of the UPS. (see figure 3) Figure 3 Do not connect appliances or devices which would overload the UPS system to the UPS output sockets. Place cables in such a way that no one can step on or trip over them. - Page 27 Caution - risk of electric shock. The battery circuit is not isolated from the input voltage. Hazardous voltages may occur between the battery terminals and the ground. Before touching, please verify that no voltage is present! Batteries may cause electric shock and have a high short-circuit current. Please take the precautionary measures specified below and any other measures necessary when working with batteries: －remove wristwatches, rings and other metal objects...
-
Page 28: Rear Panel View
2. Installation and setup NOTE: Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. Please keep the original package in a safe place for future use. 2-1. Rear panel view 1kVA 2kVA 3kVA 1. Output receptacles 2. - Page 29 Step 2: UPS output connection Simply plug devices to output sockets. During power failure, UPS will provide power to connected devices. Step 3: Communication connection Communication port: RS-232 port Intelligent slot To allow for unattended UPS shutdown/start-up and status monitoring, connect the communication cable one end to the RS-232 port and the other to the communication port of your PC.
- Page 30 Step 7: External battery connection Follow the below chart to make external battery connection. To external To external battery battery Step 8: External battery capacity configuration in software To calculate accurate backup time of external batteries, it’s necessary to configure battery numbers in software.
-
Page 31: Button Operation
3. Operations 3-1. Button operation Button Function Turn on the UPS: Press and hold ON/Mute button for at least 2 seconds to turn on the UPS. Mute the alarm: After the UPS is turned on in battery mode, press and hold this button for at least 5 seconds to disable or enable the alarm system. - Page 32 Display Function Backup time information Indicates the backup time in pie chart. Indicates the backup time in numbers. H: hours, M: minute, S: second Fault information Indicates that the warning and fault occurs. Indicates the warning and fault codes, and the codes are listed in details in 3-5 section.
-
Page 33: Audible Alarm
3-3. Audible Alarm Battery Mode Sounding every 4 seconds Low Battery Sounding every second Overload Sounding twice every second Fault Continuously sounding Bypass Mode Sounding every 10 seconds 3-4. LCD display wordings index Abbreviation Display content Meaning Enable Disable Escape High loss Low loss Battery... - Page 34 01: Output voltage setting Interface Setting For 208/220/230/240 VAC models, you may choose the following output voltage: 208: presents output voltage is 208Vac 220: presents output voltage is 220Vac 230: presents output voltage is 230Vac 240: presents output voltage is 240Vac For 110/150/120/127 VAC models, you may choose the following output voltage: 110: presents output voltage is 110Vac...
-
Page 35: Operating Mode Description
05: Bypass mode enable/disable Interface Setting ENA: Bypass mode enable DIS: Bypass mode disable 06: Bypass voltage range setting Interface Setting Press the Down key or Up key to set the acceptable high voltage point and acceptable low voltage point: HLS: Bypass high voltage point LLS: Bypass low voltage point For 208/220/230/240 VAC models:... -
Page 36: Faults Reference Code
Operating mode Description LCD display Bypass mode When input voltage is within acceptable range but UPS is overload, UPS will enter bypass mode or bypass mode can be set by front panel. Alarm is sounding every 10 second. Standby mode UPS is powered off and no output supply power, but still can charge batteries. -
Page 37: Troubleshooting
4. Troubleshooting If the UPS system does not operate correctly, please solve the problem by using the table below. Symptom Possible cause Remedy No indication and alarm even The AC input power is not Check if input power cord though the mains is normal. connected well. - Page 38 Symptom Possible cause Remedy Fault code is shown as 1, 2, 3, 4, A UPS internal fault has Contact your dealer 11, 12, 13 and 41 on LCD display occurred. There are two and alarm is continuously possible results: sounding. 1.
-
Page 39: Storage And Maintenance
5. Storage and Maintenance Operation The UPS system contains no user-serviceable parts. If the battery service life (3~5 years at 25°C ambient temperature) has been exceeded, the batteries must be replaced. In this case, please contact your dealer. Be sure to deliver the spent battery to a recycling facility or ship it to your dealer in the replacement battery packing material. -
Page 40: Specifications
6. Specifications MODEL Newtech ECO 1kVA Newtech ECO 2kVA Newtech ECO 3kVA CAPACITY* 1000 VA / 800 W 2000 VA / 1600 W 3000 VA / 2400 W INPUT 160VAC/140VAC/120VAC/110VAC ± 5% or 80VAC/70VAC/60VAC/50 VAC ± 5% Low Line Transfer ( based on load percentage 100% - 80 % / 80 % - 70 % / 70 - 60 % / 60 % - 0) 168VAC/148VAC/128VAC/118VAC ±...
