LITE II
650/850 VA
UNINTERRUPTIBLE POWER SUPPLY
UPS
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LITE II 650 VA and is the answer not in the manual?

Questions and answers

Related Manuals for Tuncmatik LITE II 650 VA

Summary of Contents for Tuncmatik LITE II 650 VA

  • Page 1 LITE II 650/850 VA UNINTERRUPTIBLE POWER SUPPLY USER MANUAL...
  • Page 2 This UPS is specially designed for Personal Computers with multi-functions. lts light weight, compact design perfect fits to the limited working environment. The line of UPS is equipped with boost and buck AVR to stabilize input voltage range. lt is also built-in with DC start function.
  • Page 3 SMART BUTTON TECHNOLOGY ALARM SILENCE FUNCTION Smart On/Off Button Technology (Alarm Silence Function) Press the smart button for minimum 1 second to turn the UPS unit on. If mains is cut off when UPS is working, UPS starts working in battery mode and gives audible alarm.
  • Page 4 3. Placement Install the UPS unit in any protected environment that provides adequate airflow around the unit, and is free from excessive dust, corrosive fumes and conductive contaminants. Do not operate your UPS in an environ- ment where the ambient temperature or humidity is high. On the other hand, place the UPS away from the monitor at...

  • Page 5: Safety Warning

    SAFETY - WARNING This UPS utilizes voltages that may be hazardous. Do not attempt to disassemble the unit. The unit contains no user serviceable parts. Only factory service personnel may perform repairs. Internal battery voltage is 12Vdc. Sealed, lead-acid, 6 cells battery. Connection to any other type of receptacle other than a two-pole, three-wire grounded receptacle may result in shock hazard as well as violate local electrical codes.

  • Page 6: Troubleshooting

    TROUBLE SHOOTING Use the table below to solve m nor problems. Possible Cause Problem Solutions No LED display on Low battery Charge the UPS at least 6 hours the front panel Battery fault Replace the battery with the same type of battery (Please see Safety-Warning page) The UPS is not turned on Press the On/Off button at least 1...

  • Page 7: Technical Specifications

    TECHNICAL SPECIFICATIONS Lite II 650 VA Lite II 850 VA MODEL Capacity 650 VA / 360 W 850 VA / 480 W INPUT 220/230/240 VAC Voltage 162-265 VAC Voltage Range OUTPUT ±10% Voltage Regulation Transfer Time Typical 2-6 ms, 10 ms max.

  • Page 8: Uninterruptible Power Supply

    LITE II 650/850 VA UNINTERRUPTIBLE POWER SUPPLY ISO 9001 ISO 14001 OHSAS 18001 R e g i s t e r e d R e g i s t e r e d R e g i s t e r e d...

This manual is also suitable for:

Lite ii 850 va
