  • Page 1: User Manual

    NEWTECH PRO 10-20 KVA (3/1) ONLINE UNINTERRUPTIBLE POWER SUPPLY USER MANUAL info@tuncmatik.com / www.tuncmatik.com...
  • Page 3 Please comply with all warnings and operating instructions in this manual strictly. Save this manual properly and read carefully the following instructions before installing the unit. Do not operate this unit before reading through all safety information and operating instructions carefully.

  • Page 4: Table Of Contents

    Table of Contents 1. SAFETY AND EMC INSTRUCTIONS ....................4 1-1. T ....................... 4 RANSPORTATION AND TORAGE 1-2. P ............................4 REPARATION 1-3. I ............................4 NSTALLATION 1-4. O ............................5 PERATION 1-5. S ............................5 TANDARDS 2. INSTALLATION AND OPERATION ....................6 2-1.

  • Page 5: Safety And Emc Instructions

    1. Safety and EMC instructions Please read carefully the following user manual and the safety instructions before installing the unit or using the unit! 1-1. Transportation and Storage Please transport the UPS system only in the original package to protect against shock and impact.

  • Page 6: Operation

    1-4. Operation Do not disconnect the earth conductor cable on the UPS or the building wiring terminals in any time since this would cancel the protective earth of the UPS system and of all connected loads. The UPS system features its own, internal current source (batteries). The UPS output sockets or output terminal blocks may be electrically live even if the UPS system is not connected to the building wiring outlet.

  • Page 7: Installation And Operation

    2. Installation and Operation There are two different types of online UPS: standard and long-run models. Please refer to the following model table. Model Type Model Type 10KL Standard Long-run 15KL model model 20KL We also offer optional parallel function for these two types by request. The UPS with parallel function is called as “Parallel model”.
  • Page 8 Diagram 4: 10K/10KL Input/Output Terminal Diagram 3: 15K/20K Rear Panel Diagram5 :15KL/20KL Input/Output Terminal Diagram 6: 15K/20K Input/Output Terminal Diagram 7：15K/20K Grounding Terminal...

  • Page 9: Single Ups Installation

    1. RS-232 communication port 2. USB communication port 3. Emergency power off function connector (EPO connector) 4. Share current port (only available for parallel model) 5. Parallel port (only available for parallel model) 6. Intelligent slot 7. Charger fan 8. Power stage fan 9.
  • Page 10 use 6AWG or thicker wire for safety and efficiency. NOTE 4: The selections for color of wires should be followed by the local electrical laws and regulations. Remove the terminal block cover on the rear panel of UPS. Then connect the wires according to the following terminal block diagrams: (Connect the earth wire first when making wire connection.
  • Page 11 NOTE 1: Make sure that the wires are connected tightly with the terminals. NOTE 2: There are two kinds of outputs: output terminal/outlets and programmable terminal. Please connect non-critical devices to the programmable terminal and critical devices to the output terminal/outlets. During power failure, you may extend the backup time to critical devices by setting shorter backup time for non-critical devices.

  • Page 12: Ups Installation For Parallel System

    2-4. UPS Installation for Parallel System If the UPS is only available for single operation, you may skip this section to the next. 1) Install and wires the UPSs according to the section 2-3. 2) Connect the output wires of each UPS to an output breaker. 3) Connect all output breakers to a major output breaker.

  • Page 13: Software Installation

    Wiring diagram of parallel system for 15K(L)/20K(L) 2-5. Software Installation For optimal computer system protection, install UPS monitoring software to fully configure UPS shutdown.

  • Page 14: Operations

    3. Operations 3-1. Button Operation Button Function  Turn on the UPS: Press and hold the button more than 0.5s to turn on the UPS. ON/Enter Button  Enter Key: Press this button to confirm the selection in setting menu. ...
  • Page 15 LCD Panel: Display Function Backup time information battery discharge time Indicates the in numbers H: hours, M: minutes, S: seconds Fault information Indicates that the warning and fault occurs. Indicates the fault codes, and the codes are listed in details in section 3-9. Mute operation Indicates that the UPS alarm is disabled.

  • Page 16: Audible Alarm

    Indicates the Battery capacity by 0-25%, 26-50%, 51-75%, and 76-100%. Indicates the battery is unconnected Indicates low battery level and low battery voltage. Input & Battery voltage information Indicates the input voltage or frequency or battery voltage. Vac: Input voltage, Vdc: battery voltage, Hz: input frequency 3-3.

  • Page 17: Single Ups Operation

    UPS Model abnormal 3-4. Single UPS Operation 1. Turn on the UPS with utility power supply (in AC mode) 1) After power supply is connected correctly, set the breaker of the battery pack at “ON” position (the step only available for long-run model). Then set the input breaker at “ON” position. At this time the fan is running and the UPS enter to power on mode for initialization, several seconds later, UPS operates in Bypass mode and supplies power to the loads via the bypass.
  • Page 18 battery capacity is more than 25%, the buzzer will beep once every 4 seconds; If the battery voltage drops to the alarm level, the buzzer will beep quickly (once every sec) to remind users that the battery is at low level and the UPS will shut down automatically soon. Users could switch off some non-critical loads to disable the shutdown alarm and prolong the backup time (the UPS would cut off the programmable output terminal automatically when the programmable timer function is enabled).

  • Page 19: Parallel Operation

    in chapter 4 for details. 2) Please check the loads, wiring, ventilation, utility, battery and so on after the fault occurs. Don’t try to turn on the UPS again before solving the problems. If the problems can’t be fixed, please contact the distributor or service people immediately.

  • Page 20: Abbreviation Meaning In Lcd Display

    Each UPS should be connected to its battery pack. b) Turn on any UPS. A few seconds later, the UPS will enter to battery mode. c) Then, turn on another UPS. A few seconds later, the UPS will enter to battery mode and add to the parallel system.

  • Page 21: Lcd Setting

    Disable Auto Battery Normal mode (not CVCF mode) CVCF mode Subtract Not allowed Allow Reserved Neutral line loss Check OP.V Output voltage Parallel, 001 means the first UPS 3-7. LCD Setting There are three parameters to set up the UPS. Refer to following diagram. Parameter 1: It’s for program alternatives.
  • Page 22 17 programs available list for parameter 1: Bypass / CVCF Battery Battery Code Description No Output mode mode mode mode mode Test Output voltage Output frequency Voltage range for bypass Frequency range for bypass ECO mode enable/disable Voltage range for ECO mode ECO mode frequency range setting Bypass mode setting Battery backup time setting...
  • Page 23 Parameter 3: Frequency mode Setting output frequency at CVCF mode or not CVCF mode. You may choose following two options in parameter 3: CF: Setting UPS to CVCF mode. If selected, the output frequency will be fixed at 50Hz or 60Hz according to setting in parameter 2. The input frequency could be from 46Hz to 64Hz.
  • Page 24 07: Frequency range for ECO mode  Interface Setting Parameter 2: Set low voltage point for ECO mode. 50 Hz system: Setting range is from 46.0Hz to 48.0Hz. 60 Hz system: Setting range is from 56.0Hz to 58.0Hz. The default value is 48.0Hz/58.0Hz. Parameter 3: Set high voltage point for ECO mode.
  • Page 25 11: Shutdown point for programmable output  Interface Setting Parameter 2: 001. Set shutdown time for programmable output. Parameter 3: Shutdown time in minutes. Setting range is from 0 to 300. When shutdown time arrives, the programmable output terminal will be cut off. The default value is 30 minutes.

  • Page 26: Operating Mode/Status Description

    15: Inverter voltage adjustment  Interface Setting Parameter 2: you may choose Add or Sub to adjust inverter voltage Parameter 3: the voltage range is from 0V to 9.9V, the default value is 0V. 16: Output voltage calibration  Interface Setting Parameter 2: it always shows OP.V as output voltage.
  • Page 27 Operating mode/status UPS Power On Description When UPS is powered on, it will enter into this mode for a few seconds for initializing the CPU and system. LCD display No-output description When L1 is out of acceptable range or bypass is disabled (or forbidden), UPS mode will enter into no-output mode if powering on or turning off the UPS.
  • Page 28 ECO mode Description When the input voltage is within voltage regulation range and ECO mode is enabled, UPS will bypass voltage to output for energy saving. LCD display CVCF mode Description When input frequency is within 46 to 64Hz, the UPS can be set at a constant output frequency, 50 Hz or 60 Hz.
  • Page 29 Battery mode Description When the input voltage is beyond the acceptable range or power failure, UPS will backup power from battery and alarm will beep every 4 seconds. LCD display Bypass mode Description When input voltage is within acceptable range and bypass is enabled, turn off the UPS and it will enter Bypass mode.

  • Page 30: Fault Code

    Fault status Description When UPS has fault happened, it will display fault messages in LCD panel. LCD display 3-9. Fault Code Fault code Fault event Icon Fault code Fault event Icon Bus start failure None Negative power fault None Bus over None Battery SCR short circuited None...

  • Page 31: Warning Indicator

    3-10.Warning Indicator Warning Icon (flashing) Alarm Battery low Beeping every second Overload Beeping twice every second Battery unconnected Beeping every second Over charge Beeping every second EPO enable Beeping every second Fan failure/Over temperature Beeping every second Charger failure Beeping every second I/P fuse broken Beeping every second Overload 3 times in 30min...

  • Page 32: Trouble Shooting

    4. Trouble Shooting If the UPS system does not operate correctly, please solve the problem by using the table below. Symptom Possible cause Remedy No indication and alarm in the front The AC input power is not Check if input cable firmly display panel even though the mains is connected well.

  • Page 33: Storage And Maintenance

    5. Storage and Maintenance 5-1. Storage Before storing, charge the UPS at least 7 hours. Store the UPS covered and upright in a cool, dry location. During storage, recharge the battery in accordance with the following table: Storage Temperature Recharge Frequency Charging Duration -25°C - 40°C Every 3 months...

  • Page 34: Specifications

    6. Specifications CAPACITY* 10000VA / 8000W 15000VA / 12000W 20000VA / 16000W INPUT 110 VAC(L-N) ± 3 % at 50% Load Low Line Loss 176 VAC(L-N) ± 3 % at 100% Load Voltage Low Line Comeback Low Line Loss Voltage + 10V Range High Line Loss 300 VAC(L-N) ±...
  • Page 35 37-100303-XXG...
