- Don't use the product for other purposes then those propose herein.
- This is not a waterproof device. Clean it only with dampened cloth gently.
- It is unsafe and hazardous to leave the product exposed to any chemical solvent,
direct sunshine or high temperature.
- Don't drop, handle roughly, or cause any vibration or impact to the product.
- Don't use a mobile phone nearby when the thermometer is in use.
- Regarding disposal of batteries, please comply with environmentally safe methods
and legal battery disposable means and laws.
- Take out the batteries if you are not going to use the unit for an extended time.
Ear Probe
(cover removed)
Ear
Button
Settings/Memory
Button
RECOMMENDATIONS

INTERFACE LAYOUT

Red LED Forehead
(fever) Button
LCD
Display
Heart Rate
Button/Sensor
Green LED
(no fever)
Flashlight Flashlight
Button Button
Talk
Button
Forehead Probe
(cover remains)
LED
Flashlight
Battery
Compartment
4
