Mobi Technologies DualScan Prime 3 User Manual

Mobi DualScan Prime 3 Thermometer
Thank you for choosing our DualScan Prime 3 Thermometer from Mobi. This high-
tech instrument measures body temperature via reflected infrared waves from
within the ear canal or off the forehead, allowing you to determine this important
health stat very quickly, easy, and accurately. The DualScan ™ Prime 3 will also scan
and read temperature of food, baby bottles, or bath water. It even takes ambient
room temperature. Knowing whether or not a patient or a loved one is running
a fever can be critical, so to ensure proper use of this unit, please read the user's
manual carefully and keep it handy for future reference.

Package Contents

Quantity
1pc DualScan Prime 3 Thermometer
2pcs
1pc
Install Batteries
1. Open battery compartment
2. Place new batteries in compartment facing the right direction as stated
3. Replace cover and its ready to use
Note: Do not mix new batteries with old batteries.
Health Check Reminder Mode
1. Press "B" button to set a health check reminder mode
2. 1 st nd
press: activates function, 2
th
press: 60 minutes, 5 press: OFF.
3. After selecting a time for health check, it will begin to countdown .
4. When time is up, the thermometer will start to beep: indicating that it is
time to check temperature again.
Flashlight operation
Press and hold "D" button for 2 seconds to turn on/off flashlight operation. The
light will turn off after 30 seconds if not being used.
To check previous 19 temperature reading:
1. Press "D" button and release. With each additional press, unit will display
previous stored temperature readings.
For best results:
• Do not touch or breath into sensor: it may cause inaccurate measurement
• When the ambient temperature varies, thermometer should be placed in
the area for 30 minutes before using
• Do not use this thermometer for purposes other than intended
• Do not expose the thermometer to any chemical solvent, direct sunlight,
or fire/heat.
• Avoid using a mobile phone nearby when using the thermometer to mea-
sure temperature.
• Only clean the tip with a lightly dampened lint free cloth.
• Avoid measuring temperature when the skin or ear canal is wet such as
after swimming or bathing.
• Avoid measuring sites of scarred tissue or skin disorders.
Temperature measurement modes
1. Ear mode
2. Forehead mode
3. Object –measures room temperature or surface temperatures of objects
via reflected IR waves from within a few inches away
Normal Temperature Range based on Age
Age Range Normal temperature (°C)
6004116A306-01A 说明书.indd 1
Component
AAA batteries
User's Manual
rd
press: 30 minutes, 3 press: 45 minutes, 4
Normal temperature (°F)
Note:
A: Body temperatures scan button
B: Health check reminder mode button
D: Flashlight control & memory query button
Forehead Temperature
1. Press "A" button to turn unit on
2. Make sure probe cover is attached.
3. Gently place thermometer probe in the middle of forehead or side temples
4. Press and hold "A" button for 1 second then release
5. Temperature reading will be displayed on screen
6. Press "A" button to go back to home screen
Ear Temperature
1. Press "A" button to turn unit on
2. Remove probe cover before taking ear temperature
3. The ear icon will be displayed on screen automatically
4. Place thermometer probe inside ear
5. Press and hold "A" button for 1 second and release
6. The temperature will be displayed on screen
7. Press "A" button to go back to home screen
Object Temperature
1. Press "A" button to turn the unit on
2. Select icon for object temperature
3. Hold thermometer probe 1-2inches away from object
4. Press and release "B" button after 1 second
5. Temperature reading will be displayed on screen
6. Press "A" button to go back to home screen
°C/°F Switch Mode
1
*** Open battery compartment and press "E" button to change from °C to °F.
0-2 years old
3-10 years old
th
11-65 years old
＞ 65 years old
Trouble/Error Message
Battery depleted?
Battery in wrong polarity?
No response/automatically resets
Battery is wrong type?
Poor battery contact?
Is measurement affected by warm air flow?
"Hi" symbol showing
--in forehead and ear measurement mode-
- indicates measurement is greater than
109.0°F (42.9°C)
--in surface measurement mode—indi-
cates measurement is greater than 212.0°F
(100.0°C)
Is hair, sweat, or other moisture
on the boy or on the sensor af-
fecting the temperature reading?
"Lo' symbol showing
--in forehead and ear measure-
ment mode – indicates measure-
ment is less than 89.6°F (32.0°C)
--in the surface measurement
mode—indicates that measure-
ment mode is less than 32°F (0°C)
When the ambient temperature
"Err" symbol showing
is beyond the range of measure-
ment –between 50°F and 104°F
(10°C and 40°C)
Has the sensor or hardware been
damaged?
3
C: Object temperature scan button
E: C/F switch button
36.4-38.0 97.5-100.4
36.1-37.8 97.0-100.0
35.9-37.6 96.6-99.7
35.8-37.5 96.4-99.5
TROUBLESHOOTING
Check Situation Resolution
Replace with new battery
or take out the battery and
reinsert in correct (+up)
orientation and with good
contact
Wait for 30 minutes with
no use of the unit, then
measure again according
to the instruction in this
manual
Wait for 30 minutes
with no use of the
unit, then measure
again according to
the instruction in
this manual
Keep the thermom-
eter in the room
with a temperature
between 50°F and
104°F (10°C and
40°C) for 30 minutes
