4. ACCESSORY CONNECTORS
2 Pin Valet/Program/Override Push-Button Button: (Blue Connector)
The BLACK & BLACK/WHITE twin lead wires loaded in the two pin blue connector are the ground supply
and program/valet/override input of the Remote Start unit. Drill a 9/32" hole and mount this switch in an
easily accessible location under the driver's dashboard.
4 Pin Antenna/Receiver Connector: (Black Connector)
Mount the supplied antenna/receiver to a clear spot on the vehicle's windshield that will not block the
driver's vision. A good location is usually high on the windshield near the rear view mirror. Be careful not
to mount the antenna/receiver on any metallic window film, as this will effect system range. Route the
antenna/receiver cable to the control module and plug in to the 4 pin black connector.
2 Pin LED Harness: (White Connector)
The Red & Blue wires loaded into the two pin mini white connector control the anode and cathode of the
dash mounted LED. Drill a 1/4" hole and mount the LED in an easy to see location on the dashboard.
Be careful to check to make sure that there is enough clearance behind the panel you are drilling into.
4 Pin Data Bus Interface Port: (Brown Connector)
This 4 pin port is used for Code Alarm Door Lock and Transponder Databus Interfaces to communicate
with the vehicle's Databus. When using the DBI port to control the Code Alarm Door Lock and
Transponder Interface modules the following options may be available. Please refer to the D2D (Data to
Data) function list available per vehicle on the tech service web site.
Door Trigger
Door Lock Control
Dome Light Supervision
Trunk/Hatch Open
Factory Alarm Arm / Disarm
Manual Arm / Disarm Inputs (factory keyless controls system)
15
