SENS part number:
Document revision:
DCN number:
Date:
Installation or service questions? Call SENS at 1-800-742-2326 (303-678-7500) between 8 a.m.
and 5 p.m. (Mountain Time) Monday through Friday, or visit our website.
DCT SERIES
CASE SIZE 2A
FILTERED BATTERY CHARGER
12V/100A
24V/75-100A
32V/50-100A
48V/50-75A
120V/25-35A
240V/12A
OPERATION & MAINTENANCE
Copyright © Stored Energy Systems LLC 2006
GUIDE
101137-2
B
105286
1/17/2007
1840 Industrial Circle
Longmont, CO 80501
Fax: (303) 678-7504
Tel: (303) 678-7500
Email: service@sens-usa.com
www.sens-usa.com
Web:
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sens DCT Series
Summary of Contents for Sens DCT Series
- Page 1 Fax: (303) 678-7504 Tel: (303) 678-7500 Email: service@sens-usa.com www.sens-usa.com Web: Installation or service questions? Call SENS at 1-800-742-2326 (303-678-7500) between 8 a.m. and 5 p.m. (Mountain Time) Monday through Friday, or visit our website. Copyright © Stored Energy Systems LLC 2006...
-
Page 2: Important Safety Instructions
DCT Series Charger Manual IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS This manual contains important safety and operating instructions for Stored Energy Systems (SENS) model DCT. Before using the battery charger, read all instructions and cautionary markings on the battery charger, battery and equipment connected to the battery system. - Page 3 DCT Series Charger Manual This manual covers installation, operation and troubleshooting of SENS model DCT filtered battery charger in case size 2A. Overview READ THIS FIRST Please follow the installation and use instructions. They are vital to the satisfactory operation of the charger.
- Page 4 DCT Series Charger Manual FIGURE 2.1 Lifting Instructions WHEN INSTALLING DO NOT LIFT UNIT FROM MIDDLE OF LOWER COVER - THE COVER WILL BEND. USE A SPREADER PLATE EQUIVALENT TO 1" THICK PLYWOOD ACROSS THE BOTTOM OF THE UNIT WHEN LIFTING The charger can be mounted either on a wall or in a standard 19”...
- Page 5 DCT Series Charger Manual FIGURE 2.2a Power Connections - 240 Volts AC Input or Lower AC INPUT DC OUTPUT 240 VAC OR LESS MAKE INPUT & OUTPUT CONNECTIONS DIRECT TO CIRCUIT BREAKERS AS SHOWN. FIGURE 2.2b Power Connections - 277, 380, 415 or 480 VAC...
- Page 6 DCT Series Charger Manual TABLE 2.2 AC Input Circuit Breaker Ratings Charger output Breaker Breaker 115 V 230 V amps amps same 24 100 same same same Caution: Do NOT connect the battery backwards; charger damage may result. The voltmeter will show battery voltage as soon as the DC connection is completed. Check the voltmeter as soon as the DC connection has been made.
- Page 7 DCT Series Charger Manual TABLE 2.4 Charger Part Number Suffix and Alarms Configuration -4042, -6042, -4642, -6642, -7042, -8042 -7642, -8642 Alarms “0” Alarms “6” Charger alarm system code Indication None Float or boost mode None AC fail LED & Form C contact...
- Page 8 DCT Series Charger Manual The two leads of the optional RTS are connected to a port on the control board as follows: Connect the yellow lead of the sensor to J7 “YEL” and the violet lead to J7 “VIO”. If the sensor is connected properly “RTS OFF”...
- Page 9 DCT Series Charger Manual BOOST This voltage is slightly higher than the float setting. Boost slightly overcharges the battery in order to ensure that all the cells of a battery are fully charged to the same voltage. Continued operation in boost is not recommended because the high charging voltage will cause battery electrolyte to boil away quickly.
- Page 10 DCT Series Charger Manual FIGURE 3.4 LED Indicators on Charger Front Panel LAMP TEST AC ON AC FAIL CHGR FAIL + GROUND LOW DC - GROUND BOOST HIGH DC FLOAT SHUTDOWN AC ON Indicates that AC power is being supplied to the charger.
- Page 11 DCT Series Charger Manual HIGH DC SHTDN Indicates that the charger has been shut down by the high output voltage shutdown circuit. Probable causes of a high DC shutdown are as follows: a) The float or boost voltages have been increased above the pre-set shutdown voltage.
- Page 12 DCT Series Charger Manual 4. Adjust the FLOAT pot until the desired voltage is achieved. Adjustment of the BOOST voltage is similar to adjustment of FLOAT, except that you adjust the BOOST pot instead of the FLOAT pot. Be sure that the charger front panel mode switch is in BOOST when you make adjustments.
- Page 13 DCT Series Charger Manual CHART 4.2 Graph of Factory-Set Output, Alarm and Shutdown Voltages 2.55 VRLA Float 2.45 VRLA Boost 2.35 Flooded Float 2.25 Flooded Boost 2.15 HV Alm VRLA 2.05 HV Shtdn VRLA 1.95 HV Alm Flooded 1.85 HV Shtdn Flooded 1.75...
- Page 14 DCT Series Charger Manual Troubleshooting Table If there is a problem and you suspect the charger is at fault, turn off the AC mains supply before Trouble- proceeding. Ensure that the following are correct: AC input wiring, battery and/or load connections shooting and PC card connectors.
- Page 15 DCT Series Charger Manual Component Diagnostic Tests Test #1: With transformer leads disconnected, energize the transformer with the normal AC supply voltage. Measure entire secondary voltage. It should be 1.5 to 2 times the nominal battery voltage. Test #2: With one or both leads disconnected from the inductor, measure the resistance across the inductor terminals.
- Page 16 DCT Series Charger Manual Diagram of Automatic Boost Operation (Optional Feature) Appendix Boost voltage Float voltage Battery voltage Point at which charger changes from current limit to voltage limit Volts Point at which AUTOBOOST returns charger to float voltage 100% charger...
- Page 18 FAIL FAIL FAIL NOTES: 1. INPUT VOLTAGES OF 277VAC & GREATER WILL REVERSE THE CONTRACT NO. SENS STORED ENERGY SYSTEMS Longmont, CO POSITION OF BREAKERS. DRAWN DATE TITLE CHECKED DCT 1 & 2A CASE 2. A3 OPTIONAL ONLY IF UNIT IS...
