PC9155 Wireless Alarm System
[ ][1] – Bypass/Re-activate Stay/Away and Night Zones
Press [ ][1] to enter Bypass mode. If the Code Required for Bypass option is enabled, enter a valid user code. The keypad displays 'Scroll to
Bypass Zones'. The keypad displays the programmed zone labels and includes the letter 'O' in the bottom, right corner if the zone is violated or
the letter 'B' if the zone is bypassed. Scroll to the appropriate zone and press the [ ] key to change the bypass status (or enter the 2-digit zone
number). Once the correct zones are bypassed, press [#] to exit.
Additional Bypass Commands
Bypass Recall:
Clear Bypass:
Save Bypass:
Recall Save:
Re-activate Stay/Away and Night Zones:
Press [ ][1] when the system is armed in the Stay mode to change the armed status to Away mode or Night mode. The system will add the Stay/
Away zones back into the system after the exit delay time expires.
i
If any zones are programmed as night zones (zone definition 37) pressing [ ][1] when the system is in Stay
mode activates Night mode instead of Away mode. Only night zones are bypassed. The stay and away zones
are added back into the system.
[ ][2] – Trouble Display
Refer to Chapter 6: Testing & Troubleshooting, for troubleshooting assistance and a detailed description of all trouble conditions.
[ ][3] – Alarm Memory Display
Pressing the scroll <> keys display an "Alarms in Memory" message if an alarm occurred during the last armed period. Pressing [ ][3] displays
the message "Scroll to view Alarms". To clear the memory, arm then disarm the system.
[ ][4] – Door Chime Enable/Disable
Press [ ][4]. The keypad emits 3 rapid beeps to indicate that the door chime feature is enabled or a steady 2-second tone if disabled. The same
function can be performed by pressing and holding the Chime function key for 2 seconds.
[ ][5] – Program User Codes
The following table identifies available user codes:
Code
[01] – [16]
[40]

Programming User Codes

Press [ ][5] followed by the master code. The keypad displays the first user (user 01) and includes the letter 'P' if the user code is programmed.
Scroll to the appropriate user and press the [ ] key to program the user (or enter the 2-digit user number). Enter a new 4 or 6-digit user code or
press [ ] to delete the user code. After the user code is programmed or deleted, scroll to another user or press [#] to exit.
Proximity tags can be assigned to a programmed user code on WT5500P keypads. After assigning a user code,
i
the display prompts for the tag to be swipped. This assigns a proximity tag to the user code. The user code will
have a T in the lower right hand corner indicating that a tag is associated with that code. To delete a proximity
tag, the user code must be deleted. Refer to the Proximity Tag Installation Sheet for details. The proximity tag
can be used in place of the access code for any of the instructions referred to in the Operation section of this
manual.
Programming User Attributes
Press [ ][5] followed by the master code or supervisor code. Press [9] followed by the 2-digit user number to view user attributes.
To change user attributes, press the number corresponding to the attribute or scroll to the desired attribute and press [ ]. When the correct attri-
butes are assigned to the user, press [#] to exit. To change the attributes for another user, press [9] followed by the 2-digit user number. When fin-
ished, press [#] to exit.
• These attributes affect the operation of wireless keys.
i
• Wireless key numbers (01-16) correspond with user access codes (01-16).
• Duress codes are not valid when entering [*][5], [*][6] or [*][8] sections.
• Duplicate codes and codes that are +/- 1 of an existing code can not be programmed.
In Bypass mode, press [99]. The keypad recalls the last group of zones that were bypassed.
Press [00]. The keypad clears the bypass on all zones.
Press [95]. The keypad saves zones which are manually bypassed.
Press [91]. The keypad recalls the bypassed zones that were saved.
Type Function
General User Codes Determined by attributes programmed below
Master Code All attributes described below
3-2
