Additional Keypad Functions - Alexor PC9155-433/868 Installation Manual

2-way wireless security suite, series 2-way wireless keypad

Table of Contents

[1]

Supervisor's Code: This attribute is used for validation when entering the [ ][5] User Code Programming section and [ ][6] User

Functions section. Note, the supervisor's code can only validate programming for codes with equal or lesser attributes. The

supervisor's code also allows this user to create bypass groups if an access code is required to enter into [ ][1] Bypassing.

[2]

Duress Code: Duress codes are standard user codes that transmit the Duress Alarm Reporting Code whenever the code is entered to

perform any function on the system.

[3]

Bypass Zones: The user can manually bypass zones if bypassing requires an access code.

[4-6]

Future Use

[7]

Bell Squawk On Arming/Disarming: The panel squawks the bell when the user arms using the away function key and a user code,

or if the away function key is pressed on an identified wireless key.

[8]

One-time Use Code: The one-time-use code allows unlimited arming but only permits a single disarming once a day. The Disarm

function is restored at midnight.

[ ][6] – User Functions

To access the User Functions section, press [ ][6] followed by the master or supervisor code. Select one of the functions described below by

pressing the corresponding number or scrolling to the desired option then pressing [ ].

[1]

Program Time and Date: Enter the time and date using the following format [HH:MM] [MM/DD/YY]. Program the time using

military standard (e.g., 8:00 pm = 20:00 hours).

[2]-[3]

Future Use

[4]

System Test: The system activates the siren output on medium volume for 2 seconds followed by full volume alarm for 2 seconds.

All display lights and LCD pixels turn on.

[5]

Enable DLS: The panel will temporarily enable DLS double-call for 6 hours.

[6]

User Initiated DLS: The panel attempts to call the DLS computer.

[7]

Future Use

[8]

User Walk Test Mode: Walk Test mode allows the operation of each detector in the system to be tested. Press [*][6][Master

Code][8] to initiate Walk Test mode. While in Walk Test mode, the Ready, Armed, and Trouble LED's flash to indicate that the

walk test is active. Re-entering [*][6][Master Code][8] exits Walk Test mode. The system will also automatically terminate the

Walk Test on completion; it will sound an audible warning (5 beeps every 10 seconds), beginning 5 minutes before the termination

of the test.

[9]

Late to Open Control: This feature notifies a user if their alarm system is not disarmed by a programmed time of day (see Late to

Open Time of Day). It is typically used to track children after school. For example, if the parents get home from work at 5pm, and a

child gets home at 4pm, the programmable timer could be set for 4:15. If the system is not disarmed at this time an alert is sent to the

monitoring station. The keypad displays "Late to Open is Enabled" and sounds a beep if [9] is pressed within the User Functions

menu when this feature is off. The LCD keypad displays "Late to Open is Disabled" and sounds an error tone if [9] is pressed within

the User Functions menu when this feature is on.

[0]

Late to Open Time of Day: This attribute sets the time for Late to Open Control programmed for attribute [9] operation. Valid

entries for these sections are 00:00 - 23:59. Entering 99:99 disables the late to open feature for that day. After the [0] key is pressed

in the [ ][6] menu, acknowledge beeps are sounded and the message Press (*) for <> Sunday is displayed on the keypad. Pressing

the [>] key scrolls through each day of the week from Sunday to Saturday. While in the Late to Open menu, entering keys 1-7 also

selects each day from Sunday to Saturday.
