ZyXEL Communications Prestige 660HW Series Installation Manual

Adsl router with wireless + firewall
Hide thumbs Also See for Prestige 660HW Series:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
ZyXEL Prestige 660HW Series
ADSL Router with Wireless + Firewall
Version 3.40
5/2005

Installation Guide

Advertisement

Table of Contents
loading

Related Manuals for ZyXEL Communications Prestige 660HW Series

Summary of Contents for ZyXEL Communications Prestige 660HW Series

  • Page 1: Installation Guide

    ZyXEL Prestige 660HW Series ADSL Router with Wireless + Firewall Installation Guide Version 3.40 5/2005...

  • Page 2: Hardware Connections

    P-660HW Series Quick Start Guide Overview The P-660HW is an ADSL Internet gateway with IEEE 802.11g wireless capability and a 4-port built-in switch. You may need your Internet access information. The P-660HW is referred to as “the Prestige” in this guide. See your User’s Guide for background information on all features.

  • Page 3: Configuration For Internet Access

    P-660HW Series Quick Start Guide 1 DSL: Connect the Prestige to a telephone jack using a telephone wire. 2 LAN: Use an Ethernet cable to connect a computer to a LAN 10/100M port for initial configuration and/or Internet access. 3 POWER: Use the included power adaptor to connect the POWER socket to an appropriate power source (see the User’s Guide for power adaptors specifications by region).

  • Page 4: Zero Configuration

    P-660HW Series Quick Start Guide • Configuration Genie • Zero Configuration • Web Configurator Internet Access Wizard 2.1 Configuration Genie • From the included CD, click “Multimedia Auto Provisioner” (the installation and configuration assistant) and then click “Installation Tutorial”. After you’ve viewed the tutorial, click “Configuration Genie” at the end of the installation tutorial or from “Multimedia Auto Provisioner”...
  • Page 5 P-660HW Series Quick Start Guide 4 In the MAIN MENU screen, click WIZARD SETUP. 2.3.1 Internet Access Setup Note: Enter the Internet access information given to you by your ISP exactly in each wizard screen and then click Next to continue or click Back to return to the previous screen. Screen information is not saved when you click Back.
  • Page 6 P-660HW Series Quick Start Guide 2 The next wizard screen varies depending on the Encapsulation you chose in the first wizard screen. From the Network Address Translation drop-down list box, select SUA Only if you have one public IP address, Full Feature if you have more than one public IP address (for translation) or None to disable NAT.

  • Page 7: Wireless Configuration

    P-660HW Series Quick Start Guide 3 Verify your 4 Click Save Settings in the screen shown in step LAN and 3 to go to the final wizard screen.The Prestige automatically tests the connection to the settings. computer(s) connected to the LAN port. To test the connection from the Prestige to the ISP, click To change the Start Diagnose.
  • Page 8 P-660HW Series Quick Start Guide 1 Click the Wireless LAN link under 2 Click 802.1x/WPA. Advanced Setup. Select Authentication Required, then select WPA- PSK and then type a Pre- shared Key. 3 Click Advanced Setup, Wireless LAN, Wireless. In the ESSID field, enter up to 32 printable characters to uniquely identify the Prestige.
  • Page 9 P-660HW Series Quick Start Guide Click If you have Advanced servers on your Setup and LAN, configure then NAT to an SUA server open the set to have NAT-Mode them visible to screen. the outside. Select SUA From the NAT - Only if you Mode screen have one public IP address and Full Feature if...

  • Page 10: Troubleshooting

    P-660HW Series Quick Start Guide 6 Troubleshooting PROBLEM CORRECTIVE ACTION None of the LEDs turn on when Make sure that you have the correct power adaptor connected to the Prestige, it you connect the Prestige’s is plugged into an appropriate power source and the Prestige is turned on. power.
  • Page 11 P-660HW Series Quick Start Guide 4 Select Internet Protocol (TCP/IP) (under the General tab in Windows XP) and click Properties. 5 The Internet Protocol TCP/IP Properties screen opens (the General tab in Windows XP). 6 Select the Obtain an IP address automatically and Obtain DNS server address automatically options.
