Lamp Maintenance - Martin Ego 01 User Manual

1 Disconnect the fixture from power and allow the components to cool
completely.
2 Remove the fixture cover. You may want to remove the lamp for cleaning
(see the related steps in "Installing a lamp in the Ego" on page 14).
3 Vacuum or gently blow away dust and loose particles with compressed air.
4 Remove stuck particles with an unscented tissue or cotton swab
moistened with glass cleaner or distilled water. Do not rub the surface: lift
the particles off with a soft repeated press.
5 Remove smoke and other residues with cotton swabs or unscented
tissues moistened with isopropyl alcohol. A commercial glass cleaner may
be used, but residues must be removed with distilled water. Clean with a
slow circular motion from center to edge. Dry with a clean, soft and lint-
free cloth or compressed air.
6 Replace the fixture cover and tighten the access screws, taking care not to
trap any loose wires.
L A M P M A I N T E N A N C E
The following lamp types are supported:
• Philips ELC/5H, 24 V / 250 W, 500 hour halogen lamp (included)
• Osram ELC-7/X, 24 V / 250 W, 700 hour halogen lamp
• Philips ELC/8H, 24 V / 250 W, 800 hour halogen lamp
• Osram ELC, 24 V / 250 W, 50 hour halogen lamp
Installing any other lamp may damage the fixture!
Allow the lamp to cool for at least 5 minutes before packing and moving
the fixture. To avoid possible damage, remove the lamp when shipping the
fixture.
Warning! Always disconnect the fixture from AC power and allow it to
cool for 5 minutes before installing the lamp.
I ns ta ll in g a lamp i n the E g o
1 Disconnect the fixture from AC power. If replacing a lamp, allow it to cool
for at least 5 minutes before removing the lamp-access cover. The lamp
cools faster with the cover in place. It can take up to 15 minutes for the
fixture to cool completely.
2 Remove the six access screws from the cover and lift it off.
14 Ego user manual
