Ultra-thin indoor amplified hdtv antenna

Advertisement

FCC Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B Digital Device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on another circuit.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate this equipment.
Industry Canada Regulatory Information
CAN ICES-3 (B)/NMB-3 (B)
Avis d'Industrie Canada
CAN ICES-3 (B)/NMB-3 (B)
Congratulations on your purchase of the ANT1150F Ultra-Thin Indoor Amplified HDTV
Antenna. This antenna's paper-thin design lets you hang it virtually anywhere on walls
or windows. Its 12-foot cable gives you room to roam to find the best spot for optimum
reception, with an multi-directional reception pattern that gets signals from every direction.
And this antenna's new amplifier design outperforms all other brands.
Multi-Directional Antennas
An RCA multi-directional antenna is able to receive signals from any direction. Useful
for both analog and digital reception, the ANT1150F has a paper-thin design that hangs
virtually anywhere. The patented multi-directional technology ensures that the antenna
does not need to be adjusted according to the location of the transmitting signal.
ANT1150F
Ultra-Thin Indoor Amplified HDTV Antenna
User's Guide / Guide de l'utilisateur / Guía del Usuario
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ANT1150F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for RCA ANT1150F

  • Page 1 Multi-Directional Antennas An RCA multi-directional antenna is able to receive signals from any direction. Useful for both analog and digital reception, the ANT1150F has a paper-thin design that hangs virtually anywhere. The patented multi-directional technology ensures that the antenna does not need to be adjusted according to the location of the transmitting signal.
  • Page 2 The ANT1150F Ultra-Thin Indoor Amplified HDTV Antenna is packed with features that make it a great addition to your home theater. Because the ANT1150F is multi-directional, there is no need to constantly turn the antenna to improve reception. And, with its ultra- thin design, the ANT1150F hangs virtually anywhere, disappearing into any decor.
  • Page 3 It is highly recommended that the flat surface of the antenna should face the broadcast tower or as close as practical. Because of its multi-directional capabilities, the ANT1150F receives UHF, VHF, and local high-definition broadcasts, providing quality reception from most locations.
  • Page 4 Connecting the ANT1150F to Your TV 1. Make sure your TV is turned off. 2. Connect the ANT1150F’s built-in cable to the antenna input on your TV. Important: Make sure you uncoil the antenna’s coaxial cable completely. Leaving it coiled will reduce reception performance.
  • Page 5 Mounting the Antenna to the Wall Once you’ve confirmed the best location for your antenna and scanned for channels, you’re ready to mount the antenna to that location, using the mounting strips included. If you decide to move the antenna after you’ve mounted it, no problem: the mounting strips detach from the wall easily, without harming your wall’s surface, and are easily replaceable at most retail and drug stores.
  • Page 6 4. Remove the black liner for each strip. 5. Line up the antenna where you want to put it, then press it against the wall for 10 seconds. 6. Stop pressing the antenna against the wall and confirm that it’s firmly attached to the wall.
  • Page 7 To remove the antenna (and mounting strips) from the wall: 1. Hold the antenna against the wall gently to keep it in place. DO NOT press the antenna against wall. 2. Find the tab for the single mounting strip at the bottom of the antenna (on the metal part).
  • Page 8 Coaxial Cable Installation Precautions • Do not bend coaxial cables into less than a three-inch radius. Tighter bends can cause shorts and can change a cable’s impedance. • Do not install a coaxial cable where it will have a pulling tension greater than 15 pounds during installation.
