ANT1250_IB
7/19/01
High Power Amplified TV
Antenna
Thank you for choosing the RCA Amplified TV Antenna. You have
selected a fine product designed to provide years of performance.
Before attempting to use your antenna, please remove all parts from
the box and read the installation and use instructions carefully.
• Integrated 6 ft. Coaxial Cable
• 120 VAC, 60Hz to 12VDC, 200mA Wall Adapter
Five Year Limited Warranty
9:12 AM
Page 1
V I D E O
ANT1250
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for RCA ANT1250
Summary of Contents for RCA ANT1250
- Page 1 9:12 AM High Power Amplified TV Antenna Thank you for choosing the RCA Amplified TV Antenna. You have selected a fine product designed to provide years of performance. Before attempting to use your antenna, please remove all parts from the box and read the installation and use instructions carefully.
-
Page 2: Important Safeguards
• To reduce the risk of electric shock, do not remove the cover or back of the AC adapter or antenna. There are no user serviceable parts inside. • If you spill liquid on the AC adapter or antenna, disconnect the AC adapter’s power cord from the AC outlet to prevent possible fire or shock hazard and consult authorized service personnel. - Page 3 Do not expose the AC adapter and antenna to moisture of any kind. Use of any AC adapter not included with the antenna or recommended or sold by the antenna manufacturer may result in a risk of fire, electric shock, or injury and will void your warranty.
- Page 4 Coaxial Cable Hook-up 1. Locate the “Antenna In” connector on the back of your TV or VCR. 2. Screw the end of the antenna cable to the “Antenna In” connector on the back of your TV or VCR. 75/300 ohm Matching Transformer Hook-up 1.
- Page 5 Your cable, satellite, or DBS Satellite System can be directly connected to the Antenna allowing access to off-air local programming. By a simple flick of a switch on the back of the antenna, you can switch from your local off-air programming to cable, satellite or DBS Satellite System programming.
- Page 6 Take the following steps to tune and adjust your antenna. 1. Select the channel you want to watch. 2. Turn the antenna power on by switching the 3 position switch to the appropriate position. 3. Move the extended dipoles (channels 2-13) or the loop (channels 14 and higher) until you get the best picture possible.
- Page 7 Several accessories are available that will enable you to expand your home video system. To order any that are listed below or to find out what other accessories are available contact your local RCA dealer, complete the order form, or call 1-800-338-0376.
- Page 8 ANT1250_IB 7/19/01 9:12 AM Accessory Order Form See Your Local RCA Dealer Or Order By Phone • Have Your Credit Card Ready TO ORDER BY MAIL Model # Description RCU800 Universal Remote Control SCP40 Surge Suppressor • Prices are subject to change without notice.
