http://www.myronanddavis.com

Installation Instructions

Subaru Forester
NV7SFT1
INSTALLATION INSTRUCTIONS AND USE
The Myron & Davis In-Dash Navigation System Includes
a built in DVD player that should not be viewed by the
driver while driving to avoid violation of State and Local
Laws. This product should be installed by a professional
to ensure proper installation and operation.
Myron & Davis is not responsible for any potential accidents,
property damage or bodily harm that might result from improper
installation or operation.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Subaru Forester NV7SFT1 and is the answer not in the manual?

Questions and answers

Scott
January 23, 2025

Calibration instructions

User image 6792b9bfcf433

Subscribe to Our Youtube Channel

Summary of Contents for Myron & Davis Subaru Forester NV7SFT1

  • Page 1: Installation Instructions

    http://www.myronanddavis.com Installation Instructions Subaru Forester NV7SFT1 INSTALLATION INSTRUCTIONS AND USE The Myron & Davis In-Dash Navigation System Includes a built in DVD player that should not be viewed by the driver while driving to avoid violation of State and Local Laws.
  • Page 2 - Read the entire installation instructions prior to performing any work. - Before installation, check to see that all parts are not damaged or defective. 1 - Ensure all appropriate materials are available These are some of the common installation items you will need: - Digital Multi –...
  • Page 3: Installation Guide

    Installation Guide 2- Caution -Battery Check the battery to ensure it’s fully charged NOTE: Some new vehicles batteries are not fully charged and may cause improper operation 3 - Warning - Remove the key from the ignition - Disconnect the negative battery terminal - Care must be used working with vehicles with airbags to prevent: - injury - damage to or malfunction of the airbag system...
  • Page 4 4 – Removal of the Dash Trim Cont’d. Step 4 - Remove AC control Step 1. Remove the trim around the Step 3. Center console trim cont. Step 1a. The trim pulls straight o . knobs radio Step 4. Remove the trim from around Step 5.
  • Page 5 5 – Remove Factory Radio Remove the OEM Radio and prepare the Myron and Davis Unit for installation by following the steps below. Note: Inspect all fasteners and brackets for damage. Replace as necessary before the installation process is started Step 1a.
  • Page 6 6 - GPS Antenna, Optional Satellite Radio, and iPod interface The GPS and Optional Satellite Radio Antenna should be mounted on the exterior of the vehicle and optional iPod interface connector in a user friendly location within the vehicle cabin. Follow the steps below for proper installation. Note: Avoid routing the GPS harness near other power sources to ensure peak operation...
  • Page 7 7 - Connect and Install the Myron & Davis unit Follow the steps below to ensure proper installation and connection of the Myron and Davis unit. Note: To ensure that the video cannot be viewed while the vehicle is in motion, connect the (blue/white) Brake Wire to the Emergency Brake Switch (grounded when engaged) Note:...
  • Page 8 Forester Built-in navigation antenna interface GPS ANT Radio Antenna USB Cable Connected to Factory Harness Yellow : CDC BATT Red : CDC ACC Black : CDC GROUND Blue : Reverse Blue/White : Foot Brake...
  • Page 9 White 1 out of 3 Yellow Connected to Factory Aux Input and Steering Wheel Control Male radar Female lens Optional Yellow One of Two Multi-function compound interface...
  • Page 10 Multi-function compound interface Connected to tire pressure monitoring module(optional) TPMS tire pressure monitoring system FL OUT White FR OUT RL OUT White RR OUT White C OUT Black SW OUT Yellow SPDIF AMP C L OUT White R OUT Yellow V1 OUT Yellow V2 OUT...
  • Page 11 http://www.myronanddavis.com 1425 Cooley Court, San Bernardino, CA 92408 Fax: 909.799.7300 Toll Free: 886.335.6789...
