- Page 1 ORION XC CATx DVI Matrix Switch 10707 Stancliff Road Phone: (281) 933-7673 Houston, Texas 77099 www.rose.com...
- Page 3 LIMITED WARRANTY Rose Electronics warrants the Orion™ XC to be in good working order for one year from the date of purchase from Rose Electronics or an authorized dealer. Should this product fail to be in good working order at any time during this one-year warranty period, Rose Electronics will, at its option, repair or replace the Unit as set forth below.
- Page 4 EUROPEAN UNION DECLARATION OF CONFORMITY This is to certify that, when installed and used according to the instructions in this manual, together with the specified cables and the maximum CPU- cable length <3m, the Units listed in Appendix B are shielded against the generation of radio interferences in accordance with the application of Council Directive 2004/108/EG as well as these standards: EN 55022:2006 + A1:2007 (Class A) EN 55024:1998 + A1:2001 + A2:2003...
-
Page 5: Table Of Contents
Package contents ............................ 4 Product registration ..........................4 System Overview ............................5 Synchronized switching ..........................5 Orion XC Model Description ........................6 Installation ..............................7 System Setup ............................7 Setup of the matrix ..........................7 Setup of Extenders ..........................7 Possible Orion XC Setups ........................ - Page 6 Loading of Configurations (external) ....................65 Export and Import Options ........................66 Export Options ........................... 66 Import Options ........................... 67 Firmware Update ........................... 67 Matrix Update ............................. 67 Extender Update ..........................69 License Management ..........................72 Operation ..............................73 Operation via 'Hot Keys' ........................73 Direct Switching ..........................
- Page 7 Figures Page # Figure 1. System Overview ......................... 5 Figure 2. Orion XC 8-port Model ......................... 6 Figure 3. Orion XC 16-port Model ....................... 6 Figure 4. Orion XC 32-port Model ....................... 6 Figure 5. Orion XC 48-port Model ....................... 6 Figure 6.
- Page 8 Figure 56.Saving external configuration through the Java Tool ..............64 Figure 57.Loading external configuration through the Java Tool ............... 65 Figure 58. Exporting Configuration Lists through the Java Tool ..............66 Figure 59. Importing Configuration Lists through the Java Tool ..............67 Figure 60.
- Page 9 Connector Pinouts ..........................101 Power Supply ............................102 Environmental Conditions ........................102 Size ..............................103 Shipping Weight ..........................103 Appendix B – Part numbers ........................104 Orion XC Unit ............................104 Orion XC Receivers ..........................104 Orion XC Transmitters ......................... 104...
-
Page 10: Disclaimer
KVM user stations. CATx is used to connect the computers and user stations to the Orion XC unit. Using CATx cabling the distance can be up to 460 feet (140m) on either side of the matrix. This greatly reduces the cable bulk and makes installation easier, quicker, and less expensive. -
Page 11: About This Manual
Intuitive OSD for easy use and configuration at each user station Each port on the Orion XC will automatically be configured as an input or output depending on the type of extender that is connected. If a transmitter is connected, the port becomes an input. If a receiver is connected, the port becomes an output. -
Page 12: Compatibility
1 x Serial Control Cable 1 x RJ45/RS232 adapter 1 x CATx network cable (crossover) Java Tool Manual Product registration Register your product for future updates at: www.rose.com/htm/online-registrationform.htm Orion XC Installation and Operations Manual... -
Page 13: System Overview
System Overview An Orion XC matrix system consists of an Orion XC matrix, one or more CPU Units, and one or more CON Units. The Orion XC matrix is connected to the CPU Units / CON Units by CATx interconnect cables. -
Page 14: Orion Xc Model Description
MODELS Orion XC Model Description The following views of the Orion XC matrix illustrate the available chassis types. Figure 2. Orion XC 8-port Model Figure 3. Orion XC 16-port Model Figure 4. Orion XC 32-port Model Figure 5. Orion XC 48-port Model Figure 6. -
Page 15: Installation
The installation section of this manual explains the basic System Setup. It then describes in detail how to set up the Orion XC as a KVM Matrix, as well as how to stack and cascade Orion XC switches. System Setup First time users are recommended to connect all of the system components in the same room initially, as a test setup. -
Page 16: Kvm Matrix
If a Single-Head console is used, it is possible to also get access to a Dual-Head or Quad-Head console. ????However, control is only possible at monitor 1. Video from a single source can be switched to any number of monitors simultaneously. Audio (optional) can also be switched in the same manner. Orion XC Installation and Operations Manual... -
Page 17: Parallel Operation (Stacking)
(stacking) of several Orion XC devices. One of the Orion XC matrices is configured as the master matrix. All the others must be configured as slave matrix, with the IP address of the master matrix entered in the Master IP Address field. The slaves must be connected to the master matrix via the network connector (RJ45) of the CPU board????, and the Enable LAN Echi???? option must be activated at the master matrix. -
Page 18: Cascading
For applications exceeding the number of available ports, the system can be extended by cascading. In this case, the Orion XC devices are connected by so-called "tie lines". The tie lines are dynamically configured to support connections in both directions. -
Page 19: Configuration
CONFIGURATION Configuration The Orion XC switch is easy to configure. This can be done through keyboard commands in Command Mode, invoking the On-Screen Display, or using the Java Tool. These options are described below. Command Mode The Orion XC has a Command Mode that allows several functions via keyboard command during normal use. -
Page 20: Control Options
<Right Shift> + <Del> within 5 seconds after switching on the CON unit or plugging in a keyboard. Control Options The Orion XC contains an internal CPU that allows control of all functions from any console without the need for an external CPU. -
Page 21: Figure 11. Osd Main Menu
In menus with input fields: Save data <Enter> In menus: Select menu item In menus with input fields: Cancel data input without saving <Esc> In menus with selection fields: Go back to the higher menu level Orion XC Installation and Operations Manual... -
Page 22: Figure 12. Login Menu
Access to the configuration menu requires administrator rights. User login is mandatory. Figure 12. Login menu Field Default Value User admin Password admin For security reasons, please change the administrator password as soon as possible. Orion XC Installation and Operations Manual... -
Page 23: Control Through The Java Tool
3. Enter the IP address of the matrix in the popup input field according to the network configuration of the Orion XC. 4. Enter the user name and password for the Orion XC. 5. Confirm the inputs with the OK button or reject with Cancel. -
Page 24: Figure 13. Java Tool Connect Menu
No more than twelve connections between the matrix and the Java tool can be established at the same time due to a limitation of available sockets. Menu structure Figure 14. Java Tool System Data Orion XC Installation and Operations Manual... - Page 25 Jump from tables into the previous field Various functions within the menus can be executed with keyboard commands listed to the right of the respective menu item (e. g. press <Ctrl> + <S> to execute Save). Orion XC Installation and Operations Manual...
- Page 26 Offline Configuration Configuration and system settings can be changed via the Java Tool in offline mode when there is not a direct connection between the tool and Orion XC. To activate a configuration in the matrix, proceed as follows: 1. Select File > Upload in the menu bar.
-
Page 27: Figure 15. Java Tool Online Configuration
To set font sizes for the Java tool, proceed as follows: 1. Select Extras > Options in the menu bar. 2. Open the Font tab. 3. Select the desired font size (normal or large). Orion XC Installation and Operations Manual... -
Page 28: Control Through The Serial Interface
Figure 16. Java Tool Configuration Report Control through the Serial Interface The Orion XC operating system has a number of functions that can be controlled via serial interface. There are telegrams for switching single or all connections available, both unidirectional and bidirectional. In addition, there are telegrams for an overall definition of the total switching status and for saving and loading such switching states. -
Page 29: Assignment
Assignment The Orion XC offers the possibility of a console specific or a CPU specific assignment. The first possibility is to assign virtual CPUs to real CPUs. The second possibility is to assign real consoles to virtual consoles. Virtual CPU Virtual CPUs can be assigned to real CPUs in this menu. -
Page 30: Figure 18. Virtual To Real Cpu Assignment Through Java Tool
The Java tool additionally offers the possibility to go directly from the Assignment menu to the Definition menu to check specific settings for the respective CPU. Use the right mouse button to select the CPU and select Open CPU Device. Orion XC Installation and Operations Manual... -
Page 31: Virtual Console
3. Select the virtual console in the Virtual Devices list that is to be assigned to the selected real console. 4. Press the Okay button to confirm the assignment. The assignment will be done. A virtual console can be assigned to more than one real consoles. Orion XC Installation and Operations Manual... -
Page 32: Figure 20. Virtual To Real Console Assignment Through Java Tool
The Java tool additionally offers the possibility to go directly from the Assignment menu to the Definition menu to check specific settings for the respective console. Use the right mouse button to select the respective console and select Open CON Device. Orion XC Installation and Operations Manual... -
Page 33: System Settings
System Settings System settings can be set up and modified on the Orion XC. The configuration of the system settings can only be done by users with administrator rights. System Data The system configuration is set up here. This can be done through either the OSD or the Java Tool. -
Page 34: Figure 21. Modifying System Settings Through Osd
Figure 21. Modifying System Settings through OSD Select between the following buttons: Button Function Cancel Reject changes Save Save changes Modifying System Data through the Java Tool Figure 22. Modifying System Settings through the Java Tool Orion XC Installation and Operations Manual... -
Page 35: Automatic Id
Modifying Automatic ID Settings through the OSD Select Configuration > System in the main menu. Figure 23, Modifying Automatic ID Settings through OSD Select between the following buttons: Button Function Cancel Reject changes Save Save changes Orion XC Installation and Operations Manual... -
Page 36: Figure 24. Modifying Automatic Id Settings Through The Java Tool
Modifying Automatic ID Settings through the Java Tool Select System > Automatic ID in the task area. Figure 24. Modifying Automatic ID Settings through the Java Tool Orion XC Installation and Operations Manual... -
Page 37: Access Control
OSD. Using the setting -1 allows the user to be logged in permanently, until a manual logout is executed. The timer is not active as long as the OSD is open. (default: 0 minutes) Orion XC Installation and Operations Manual... -
Page 38: Figure 25. Modifying Access Control Through Osd
Select between the following buttons: Button Function Cancel Reject changes Save Save changes Modifying Access Control through the Java Tool Select System > Access in the task area. Figure 26. Modifying Access Control through the Java Tool Orion XC Installation and Operations Manual... -
Page 39: Switch Settings
CPU have a video only status (default value: 10 seconds) If the Keyboard Connect and/or Mouse Connect options are activated, the Release Time number of seconds will have to elapse before a new user can gain control. Orion XC Installation and Operations Manual... -
Page 40: Figure 27. Modifying Switch Settings Through Osd
Select between the following buttons: Button Function Cancel Reject changes Save Save changes Modifying Switch Settings through the Java Tool Select System > Switch in the task area. Figure 28. Modifying Switch Settings through the Java Tool Orion XC Installation and Operations Manual... -
Page 41: Network
Activate error messages in Syslog (default: Yes) Activate the modified network parameters by doing a restart. Note: Consult your system administrator before modifying the network parameters. Otherwise unexpected results may occur, including failures with the network. Orion XC Installation and Operations Manual... -
Page 42: Figure 29. Modifying Network Settings Through Osd
Select between the following buttons: Button Function Cancel Reject changes Save Save changes Modifying Network Settings through the Java Tool Select System > Network in the task area. Figure 30. Modifying Network Settings through the Java Tool Orion XC Installation and Operations Manual... -
Page 43: Date And Time
Date and Time The Date and Time on the Orion XC are set in this menu. This menu can only be accessed in the OSD. The following settings can be modified. Field Selection Description Month 1-12 Enter month Date 1-31... -
Page 44: User Settings
User Settings The following user settings can be set up and modified on the Orion XC. User This menu is used to create new users and set up their access rights. This menu can be accessed in the OSD and the Java Tool. -
Page 45: Figure 32. Modifying User Settings Through Osd
Figure 32. Modifying User Settings through OSD Select between the following buttons: Button Function Create a new user Edit Edit an existing user Delete Delete an existing user Cancel Reject changes Save Save Changes Orion XC Installation and Operations Manual... -
Page 46: Figure 33. Modifying User Settings Through The Java Tool
9. Press the Apply button to save the new user settings. Select between the following keyboard commands Function Keyboard Command Add CPU to list Full Access <F> Add CPU to list Video Access <V> Add CPU to list No Access <N> Orion XC Installation and Operations Manual... -
Page 47: Favorite List Users
By pressing the <a> key, a CPU device will be moved to the favorite list and it will be removed by pressing <r>. 2. The order of the CPU devices within the favorite list can be changed by pressing the keys <+> and <->. 3. Press the Save button to save the settings. Orion XC Installation and Operations Manual... -
Page 48: Figure 35.Setting Up User Favorites Through The Java Tool
3. The position of a selected CPU device within the favorites list can be changed by pressing the <+> and <-> keys. 4. To remove marked CPU devices from the favorites list, press the < button. If the << button is pressed, all CPU devices will be removed from the favorites list. Orion XC Installation and Operations Manual... -
Page 49: User Macros
P1. The connection of console P1 remains unchanged (KVM or video only). CON or CPU Device Name of CON or CPU device CON or CPU Device Name of CON or CPU device Orion XC Installation and Operations Manual... -
Page 50: Figure 36. Setting Up User Macros Through Osd
4. Set the necessary parameters P1 and P2 (e.g. CON Devices or CPU Devices) for the selected macro command. 5. Confirm the inputs by pressing the <Enter> key and repeat the process for further macro commands, if necessary. Orion XC Installation and Operations Manual... -
Page 51: Figure 37. Setting Up User Macros Through The Java Tool
Copy Key Macros function. These macros can then be pasted from the cache into another key by using the Paste Key Macros function. All macros of a selected key can be reset by using the Reset Key Macros function. Orion XC Installation and Operations Manual... -
Page 52: Extender Settings
Figure 38. Managing Extender Settings through the OSD Select between the following buttons: Button Function Create a new extender unit Edit Edit an existing extender unit Delete Delete an existing extender unit Cancel Reject changes Save Save Changes Orion XC Installation and Operations Manual... -
Page 53: Creating Flex-Port Extender Units
The name of the USB 2.0 extender unit can also be changed (Name). 5. Press the Apply button to save the new extender unit. Created extender units are always set as fixed port extender. These configurations are required to switch USB 2.0 connections via the matrix. Orion XC Installation and Operations Manual... -
Page 54: Deleting Flex-Port Extender Units
Force switching to the respective CPU only in Private Mode Deactivated Function not active (default) Fix Frame Activated Force showing a red frame when switching to the respective CPU Deactivated Function not active (default) Orion XC Installation and Operations Manual... -
Page 55: Figure 40. Modifying Cpu Settings Through Osd
New R. Create a new real CPU device New V. Create a new virtual CPU device Edit Edit an existing CPU device Delete Delete an existing CPU device Cancel Reject changes Save Save changes Orion XC Installation and Operations Manual... -
Page 56: Figure 41. Modifying Cpu Settings Through The Java Tool
Note: A template can only be used, if there is at least one existing CPU device. 3. Press the OK button. 4. Determine all parameters that are relevant for the CPU. 5. To confirm the new CPU, press the Apply button. Orion XC Installation and Operations Manual... -
Page 57: Console Settings
If there is a loss of connection, the last picture shown will be still displayed and is surrounded by an orange frame When switching to a CPU without video signal, a blank screen will appear surrounded by an orange frame Deactivated Function not active (default) Orion XC Installation and Operations Manual... -
Page 58: Figure 42. Setting Up Con Devices Through Osd
Select between the following buttons: Button Function New R. Create a new real console New V. Create a new virtual console Edit Edit an existing console Delete Delete an existing console Cancel Reject changes Save Save changes Orion XC Installation and Operations Manual... -
Page 59: Figure 43. Setting Up Con Devices Through The Java Tool
Note: A template can only be used, if there is at least one existing CON device. 3. Press the OK button. 4. Determine all parameters that are relevant for the console. 5. To confirm the new console, press the Apply button. Orion XC Installation and Operations Manual... -
Page 60: Mouse And Keyboard
Set the OSD keyboard layout according to the used keyboard Video Mode Variable or specific resolution Resolution that is used by the OSD Note: The mouse and keyboard settings are console specific and can be separately set for every console. Orion XC Installation and Operations Manual... -
Page 61: Figure 44. Modifying Mouse And Keyboard Settings Through Osd
Modifying Mouse and Keyboard Settings through the OSD Select Configuration > EXT Units in the main menu. Figure 44. Modifying Mouse and Keyboard Settings through OSD Select between the following buttons: Button Function Cancel Reject changes Save Save changes Orion XC Installation and Operations Manual... -
Page 62: Extender Osd
If the Update Connections function is deactivated, the Extender OSD only appears when switching via OSD. This menu can be accessed from the OSD and the Java Tool. Orion XC Installation and Operations Manual... -
Page 63: Figure 46.Modifying Extender Osd Settings Through Osd
1. Select the console extender in the EXT-Units list whose Extender OSD settings has to be adjusted. 2. Confirm the selection by pressing the <Enter> key, and the respective console extender will be enabled for editing. Orion XC Installation and Operations Manual... -
Page 64: Console Favorites
This menu can be accessed in the OSD and the Java Tool. A favorites list can contain up to sixteen different CPUs. Switching between the favorites is done via 'Hot Key' using the keyboard. Orion XC Installation and Operations Manual... -
Page 65: Figure 48. Setting Up Console Favorites Through Osd
By pressing the <a> key, a CPU device will be moved to the favorite list and it will be removed by pressing <r>. 2. The order of the CPU devices within the favorite list can be changed by pressing the <+> and <-> keys. 3. Press the Save button to save the settings. Orion XC Installation and Operations Manual... -
Page 66: Console Macros
The macro commands are created for each console separately. A single macro can execute up to 16 switching commands successively. The execution of the macros is done via 'Hot Key' and the function keys <F1>-<F16>. Orion XC Installation and Operations Manual... -
Page 67: Figure 50. Setting Up Console Macros Through Osd
Setting up Console Macros through the OSD Select via Configuration > CON Macros in the main menu that console for which a console macro has to be created. Figure 50. Setting up Console Macros through OSD Orion XC Installation and Operations Manual... -
Page 68: Figure 51. Setting Up Console Macros Through The Java Tool
Copy Key Macros function. The macros can be pasted from the cache into a key by using the Paste Key Macros function, and all macros of the selected key can be reset by using the Reset Key Macros function. Orion XC Installation and Operations Manual... -
Page 69: Saving And Loading Of Configurations
It is possible to save the created configuration to eight storage locations in the matrix (File #1 - File #8). Additionally a configuration can also be saved as default configuration. Figure 52. Saving internal configuration through OSD Active shows the current configuration’s name and description. This configuration can be saved now. Orion XC Installation and Operations Manual... -
Page 70: Figure 53. Saving Internal Configuration Through The Java Tool
2. Enter the IP address of the matrix, your user name and password and confirm the inputs with the Next button. 3. Select the storage location in which the configuration has to be saved (default or config01 - config08) and confirm with the OK button. Orion XC Installation and Operations Manual... -
Page 71: Loading Of Configurations (Internal)
To load the configuration from the internal matrix memory, proceed as follows: 1. Select Configuration > Open in the main menu. 2. Select the desired configuration. 3. Load the configuration by pressing the <Enter> key. Orion XC Installation and Operations Manual... -
Page 72: Saving Of Configurations (External)
Created configurations can be saved as a file and so become transportable and independent of the individual matrix. This menu can only be accessed in the Java Tool. Figure 56.Saving external configuration through the Java Tool Orion XC Installation and Operations Manual... -
Page 73: Loading Of Configurations (External)
Enter the necessary parameters. 5. Select Administration > Activate Configuration and select the configuration that has to be activated. 6. Confirm the process with the Activate button. The opened configuration is activated now and can be used. Orion XC Installation and Operations Manual... -
Page 74: Export And Import Options
Export and Import Options The Orion XC offers the possibility to read out available configuration lists (extender, CPUs, consoles and users) for exporting and importing via the Java tool. Exported configuration lists are always saved in .csv format that allows offline editing with common spreadsheet applications. -
Page 75: Import Options
3. Select the directory of the list to import. 4. Confirm the import with the Finish button. Firmware Update This includes updating the firmware on the Orion XC matrix and the extenders. Firmware update is only available through the Java Tool. Matrix Update The firmware of the matrix can be updated in this menu. -
Page 76: Figure 60. Matrix Update Through The Java Tool
3. Restart the Matrix after the update by pressing the Restart matrix button in the lower part of the working area. For a complete initialization of the matrix, a cold start (power cycle) is recommended. Orion XC Installation and Operations Manual... -
Page 77: Extender Update
While performing the upload process, no update files will be installed. The update process can be performed at a later time. If all I/O cards are not selected, the upload of the update files will be performed in sequence. Orion XC Installation and Operations Manual... -
Page 78: Figure 62. Extender Update In Standard Mode Through The Java Tool - Step 2 (Update Firmware)
5. Start the actual update process by pressing the Update button. Note: Just before the update process, all affected I/O boards will be set into Service Mode and retrieved gradually after finishing the respective updates. Orion XC Installation and Operations Manual... -
Page 79: Figure 63. Extender Update In Expert Mode - Step 1 (From The Java Tool)
CON device indicating Service Mode is active. Additionally, the Service Mode is indicated by a red tool icon in the lower part of the working area. Figure 64.Extender Update in Expert Mode – Step 1 (from the Service Mode of the OSD) Orion XC Installation and Operations Manual... -
Page 80: License Management
2. Enter the license key in the working area under Activate Bundles in the License Key field. 3. In order to activate the license key press the Activate button. The new functions will be immediately enabled, and a restart of the matrix is not necessary. Orion XC Installation and Operations Manual... -
Page 81: Operation
From an external computer running the Java tool (network connection required) via a media controller (network or serial connection required) Operation via 'Hot Keys' Several operations on the Orion XC can be performed using just the ‘Hot Keys’ on the keyboard, as described below. Direct Switching Direct switching by 'Hot Keys' on a keyboard is the quickest way to switch your console between different CPUs. -
Page 82: Scan Mode
Command Mode is closed and the stored command sequence for the appropriate function key is executed. For macros, there is no need to use the <Enter> key for confirmation. Orion XC Installation and Operations Manual... -
Page 83: Addressing Of Main And Sub Matrices
Addressing of Main and Sub Matrices The Orion XC can be cascaded to two levels. Commands (including opening the OSD) can be optionally sent to the main or the sub matrix. When command mode is active, select <m> if the commands should be handled in the main matrix or <s>... -
Page 84: Kvm Switching
1. Select from the CPU Devices list on the left side the one to be connected to the CON device. 2. Confirm the desired connection type with the appropriate keyboard command. Switching operations from the CON device can only be done to CPU devices that are available in the CPU Devices list. Orion XC Installation and Operations Manual... -
Page 85: Extended Switching
Real CPU device that is assigned to a virtual CPU device CON connected Currently connected CON device CPU status Current connection status (CPU device) EXT list List of all available physical extender units (CPU units) Orion XC Installation and Operations Manual... -
Page 86: Figure 68. Extended Kvm Switching Through Java Tool - Method 1 (From Extended Switch Option)
Disconnect the CON device from the CPU device. <Backspace> KVM Switching through the Java Tool There are two methods to perform switching operations for the Orion XC via the Java Tool, as described below. Method 1: Select Control > Extended Switch in the task area. -
Page 87: Figure 69.Extended Kvm Switching Through Java Tool - Method 2 (From Matrix View Option)
Note: If there is a red X on a port when switching by using the Matrix View, the console to be connected does not have access rights to the CPU at that port. Orion XC Installation and Operations Manual... -
Page 88: Usb 2.0 Switching
When switching USB 2.0 equipment, wait until the CPU enumeration of USB 2.0 devices has been completed before switching to the next CPU (approximately. 5-15 seconds). Failure to allow enough time for USB 2.0 device enumeration can negatively affect the stability of the connection. Orion XC Installation and Operations Manual... -
Page 89: Presets
2. Activate the selected switch macro by pressing the Send button on the bottom right of the working area. Only switch macros that are compliant with the hardware and the configuration of the current matrix can be executed. Orion XC Installation and Operations Manual... -
Page 90: Serial Interface
This section deals with Power functions of the Orion XC. Restart The Orion XC can be restarted through the OSD and the Java Tool. Restarting through the OSD 1. Select Configuration > Restart Matrix or Restart IO Board in the main menu to restart either the matrix or the I/O boards. -
Page 91: Diagnostics And Status
STATUS INDICATORS Diagnostics and Status This section describes the diagnostics that are available on the Orion XC. Status indicators, both physically on the unit as LED indicators, and in the software, are discussed here. Status LEDs The Orion XC components are fitted with the following LEDs for overall status indication. -
Page 92: I/O Ports Status Leds
Figure 74. Power Supply Unit Status LEDs Status LEDs of the Power Supply Units: Pos. LED Status Description Status PSU 1 Operating condition (green) Power supply unit off Status PSU 2 Operating condition (blue) Power supply unit off Orion XC Installation and Operations Manual... -
Page 93: Fan Status Leds
Left Fan Status 1 Error Indication (red) Operating Condition Left Fan Status 2 Operating Condition (red) Fan Off Right Fan Status 2 Operating Condition (green) Fan Off Right Fan Status 1 Error Indication (red) Operating Condition Orion XC Installation and Operations Manual... -
Page 94: Port Status
This menu can only be accessed from the Java Tool. Viewing Port Status with the Java Tool The current port configuration of the Orion XC is illustrated in this menu. Select Status > Matrix View in the task area in online mode. - Page 95 The Matrix View can be reloaded using the following means: Press the <F5> key of a connected keyboard Execute Edit > Reload in the menu bar Press the Reload button in the tool bar Orion XC Installation and Operations Manual...
-
Page 96: Extender Osd
Extender OSD All extenders used with the Orion XC are provided with their own OSD to display the connection status of their console. Figure 78.Extender OSD The following information is shown in the OSD information screen: Field Description Name of the console... -
Page 97: Network Status
Information about the gateway address as provided manually or via DHCP MAC ID Information about the MAC address in the matrix Viewing Network Status through the OSD Select Status > Network in the main menu. Figure 79. Viewing Network Status through OSD Orion XC Installation and Operations Manual... -
Page 98: Firmware Status Matrix
The following information is shown in this menu: Field Description Name Description of the modules Type Type number Ports Number of ports Version Complete description of the firmware version Date Date of the firmware version Status Module status Orion XC Installation and Operations Manual... -
Page 99: Figure 81. Viewing Firmware Status Through Osd
Status to File... To read out the overall status of the matrix and store it locally (file extension .zip), select Matrix > Save Status to File... or press the respective button in the symbol bar. Orion XC Installation and Operations Manual... -
Page 100: Firmware Status Extender
Figure 83. Viewing Firmware Status on the connected Extenders through the Java Tool Trace Function All events, e.g. activities and switching operations of the Orion XC matrix, are logged and displayed in this menu. This function is used for diagnostic purposes. This menu can be accessed only from the OSD... -
Page 101: Syslog Monitoring
Syslog Monitoring Logging of the Orion XC matrix activities, including switching operations and the performance of function critical components like fans or power supply units, is done with this menu. It can only be accessed from the Java Tool. To start Syslog Monitoring proceed as follows: ... -
Page 102: Snmp
Filter Function To filter relevant messages of a number of logged activities of the Orion XC, the Syslog Monitoring offers various filter options. To set and activate a filter, proceed as follows: 1. Set the desired filter option(s) by activating the respective checkbox(es). -
Page 103: Service Information
Houston, Texas 77099 USA Technical Support If you are experiencing problems, or need assistance in setting up, configuring or operating your Orion XC unit, consult the appropriate sections of this manual. If, however, you require additional information or assistance, please contact the Rose Electronics Technical Support Department at: Phone: (281) 933-7673 E-Mail: TechSupport@rose.com... - Page 104 The Orion XC has been tested for conformance to safety regulations and requirements, and has been certified for international use. Like all electronic equipment, the Orion XC should be used with care. To protect yourself from possible injury and to minimize the risk of damage to the Unit, read and follow these safety instructions.
-
Page 105: Maintenance
MAINTENANCE Maintenance The Orion XC contains no user-serviceable parts inside. Please contact Rose Electronics if a fault or problem is encountered. Note: For a 24/7 operation, it is recommended to keep available as spare parts all relevant components of the matrix, including a chassis. -
Page 106: Troubleshooting
TROUBLESHOOTING Troubleshooting This section deals with troubleshooting possible problems on the Orion XC matrix. The solutions outlined here are contingent on having a functional extender route. Please ensure before running the extenders with the matrix that they work in a peer-to-peer connection. This can be accomplished by the use of a Cat X or fiber coupler. -
Page 107: Blank Screen
CPU unit connectors. (No cable, cable break, CPU/CON unit offline, CPU/CON unit connected to the wrong port Check power supply units and LED 3 off Power supply the connection to the power network Orion XC Installation and Operations Manual... -
Page 108: Appendix A - General Specifications
APPENDICES Appendix A – General Specifications This section gives the general specifications for the Orion XC connectors, pinouts, cables and dimensions. Interfaces The different types of possible connections, and any restrictions on them, are discussed here. RJ45 (Network) The communication of the Cat X devices requires a 1000BASE-T connection. -
Page 109: Figure 86. Rj45 Serial Connector Pinouts
460 ft (140 m) AWG24 Cat X Patch Cable 230 ft (70 m) AWG26/8 Connector Pinouts This section shows the pinouts for the connectors on the Orion XC. RJ45 (SerialD) Figure 86. RJ45 Serial Connector Pinouts Pin Signal Pin Signal DCD+ n.c. -
Page 110: Power Supply
Power Supply Voltage Orion XC 80-port 2.3 A, 100-240 VAC, 50/60 Hz Orion XC 64-port 2.3 A, 100-240 VAC, 50/60 Hz Orion XC 48-port 2.3 A, 100-240 VAC, 50/60 Hz Orion XC 32-port 2.3 A, 100-240 VAC, 50/60 Hz Orion XC 16-port 2.3 A, 100-240 VAC, 50/60 Hz Orion XC 8-port 0.7 A, 100-240 VAC, 50/60 Hz... -
Page 111: Size
Shipping Box 13.0 lb (5.9 kg) Orion XC 16 port Matrix 8.6 lb (3.9 kg) Shipping Box 12.8 lb (5.8 kg) Orion XC 8 port Matrix 1.9 lb (0.9 kg) Shipping Box 7.5 lb (3.4 kg) Orion XC Installation and Operations Manual... -
Page 112: Appendix B - Part Numbers
Orion XC, 16 Port Matrix Switch, CATx, Redundant PSU OXS-XC-008-TP Orion XC, 8 Port Matrix Switch, CATx, Redundant PSU SW-OXS-JT Orion XC, Option Bundle 1: Java Tool + Extended Switching + Presets SW-OXS-JT+API Orion XC, Option Bundle 2: Bundle 1 + API SW-OXS-XC-SNMP+SL Orion XC, Option Bundle 3: SNMP &...
Need help?
Do you have a question about the ORION XC and is the answer not in the manual?
Questions and answers
