OPTIONAL ACCESSORIES NOW AVAILABLE
1. 958 FOOT PEDAL
This controller can be used to control the volume of the output, pitch of the oscillators, or
the cutoff frequency of the filter (timbre). Up to three may be used simultaneously to
control all of these functions.
2. 959 X-Y CONTROLLER
This "joystick" simultaneously controls any two of the functions mentioned above. For
instance, it can be used to produce vowel-like sounds by controlling the filter and pitch.
3. SEQUENTIAL CONTROLLER SYSTEM
a. 960 Sequencer
b. 961 Interface (optional)
c. 962 Sequential Switch (optional)
d. 910 Power Supply for above units
e. Cabinet (portable or walnut console)
This system will automatically and simultaneously control all three functions (pitch, tim-
bre, and volume) in a repeating eight-event sequence. It also triggers the contour genera-
tors at the onset of each event. The 962 allows one to extend a sequence of one function
to up to 24 events (example: 24 note repeating bass line). The 961 extends flexibility in
triggering the contour generators and can be used to synchronize the MINI MOOG with
external equipment (example: tape recorded click track).
1. FOOT SWITCH
A pair of these will allow the performer to engage momentarily GLIDE and DECAY
functions.*
2. DUAL FOOT PEDAL
Essentially this device will contain two 958 Foot Pedals for simultaneous control of tim-
bre and volume.
* With a different plug the foot switch will supply an external S-Trigger.
FOR USE WITH MINI MOOG MODEL D
AVAILABLE SOON
July, 1971
70-016
