Campbell Hausfeld SB514000 Operating Instructions Manual

See Warranty on page 10 for important information about commercial use of this product.
Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Table of Contents
Description . . . . . . . . . . . . . . . . . . . . . .1
Unpacking . . . . . . . . . . . . . . . . . . . . . . .1
Safety Guidelines . . . . . . . . . . . . . . . . .1
Important Safety Instrucgtions . . . . . .2
Tool Components and Specifications . .2
Operating the Tool . . . . . . . . . . . . . . . .4
Fasteners . . . . . . . . . . . . . . . . . . . . . . . .7
Troubleshooting Chart . . . . . . . . . . . . .8
Warranty . . . . . . . . . . . . . . . . . . . . . . .10
Description
This tool is designed for decorative trim,
molding, window casings, furniture
trim, picture frame assembly, cabinetry,
casebacks, and crafts . Features include:
convenient top loading magazine
which holds up to 100 brads or staples,
adjustable depth control, adjustable
exhaust nose .
Unpacking
After unpacking the unit, inspect
carefully for any damage that may
have occurred during transit . Make sure
to tighten fittings, bolts, etc ., before
putting unit into service .
ReaD & FOllOW all INSTRUCTIONS
Save TheSe INSTRUCTIONS
DO NOT DISCaRD
© 2009 Campbell Hausfeld/Scott Fetzer
Figure 1 - Model SB514000
Safety Guidelines
This manual contains information
that is very important to know and
understand . This information is
provided for SAFETY and to PREVENT
EQUIPMENT PROBLEMS . To help
recognize this information, observe the
following symbols .
hazardous situation which, if not
avoided, WILL result in death or serious
injury.
hazardous situation which, if not
avoided, COULD result in death or
serious injury.
REMINDER: Keep your dated proof of purchase for warranty purposes!
Attach it to this manual or file it for safekeeping.
For parts, product & service information
visit www.chpower.com
2 inch 2-in-1
Nailer/Stapler
hazardous situation which, if not
avoided, MAY result in minor or
moderate injury.
information, that if not followed, may
cause damage to equipment.
NOTe: Information that requires special
attention .
Danger indicates
an imminently
Warning indicates
a potentially
Caution indicates a
potentially
SB514000
Notice indicates
important
Locate model and date code on
tool magazine and body, and
record below:
Model No . ______________________
Date Code ______________________
Retain these numbers
for future reference.
IN721702AV 11/09
