P o w e r S u p p l y
Quality Power. Incredible Value.
The ideal choice in high-quality and value-priced power supplies, Antec's Basiq 430 is the perfect power supply for
the entry-level power user. A quiet-running 80mm fan provides superior cooling with minimal noise. The Basiq also
boasts dual 12V rails, ensuring greater stability for your system.
UCC13# 0761345-23400-9 US
UCC13# 0761345-06358-6 EC
UCC13# 0761345-06359-3 GB
Specifications:
•
ATX12V version 2.2
•
80mm cooling fan
•
Dual +12V output circuits
•
Safety protection circuitry prevents damage
resulting from short circuits, over current,
and over voltage
www.antec.com
1-800-22ANTEC (US) / +31 (0) 10 462-2060 (EU)
Basiq 430
Protections:
Short Circuit Protection, Over Current Protection,
Over Voltage Protection
Input
Voltage Range
Normal Frequency Range
Efficiency
Environmental:
Operating Temperature
Safety approval
Size
•
Universal input with active PFC
•
PCI-E graphics card power connector
•
SATA connectors for Serial ATA drives
•
MTBF: 100,000 hours
90Vac-264Vac
47Hz-63Hz
70% Min. @115Vac/60Hz
with full load
10° TO 50°
CCC, CE, UL/CUL, C-Tick,
TÜV, CB, FCC
3.4" (H) x 5.9" (W) x 5.5" (D) /
8.6cm (H) x 15cm (W) x 14cm (D)
Quiet
computing
™
