Ford F-150 1999 Workshop Manual

1999 F-150/250 Workshop Manual

SECTION 310-01A: Fuel Tank and Lines

REMOVAL AND INSTALLATION

Tank—Fuel

Special Tool(s)

Fuel Line Removal Tool
310-052 (T93T-9550-AH)

Removal

WARNING: Do not smoke or carry lighted tobacco or open flame of any type when working on or near any fuel related component. Highly flammable mixtures are always
present and may be ignited, resulting in possible injury.
WARNING: Fuel in the fuel system remains under high pressure even when the engine is not running.
1. Relieve the fuel pressure; refer to Section 310-00A
2. Disconnect the battery ground cable (14301). For additional information, refer to
3. Raise and support the vehicle; refer to
4. If equipped, remove the fuel tank skid plate.
1. Remove the bolts.
2. Lower the fuel tank skid plate.
5. Drain the fuel from the fuel tank (9002); refer to
6. Remove one hose clamp on the fuel tank filler pipe support.
7. Disconnect the fuel tank to filler pipe hose (9047) from the fuel tank.
8. Disconnect the fuel tank filler pipe vent hose from the fuel tank.
http://www.fordtechservice.dealerconnection.com/pubs/content/~WSX1/~MUS~LEN/20/S...
(Gasoline) or Section 310-00B (NGV).
Section
Section 100-02.
Section 310-00A (Gasoline) or Section 310-00B
414-01.
(NGV).
4
1999 F-150/250 Workshop Manual
Procedure revision date: 02/03/1999
