Page 1: User Manual
Devine USB-1 Condenser Microphone User manual Any information and illustrations shown in this user manual are subject to change without further notice. User manual version: 1.0 Creation date + author initials: 27-01-2014 DK Revision date + author initials: 27-01-2014 DK... - Page 2 Introduction Thank you for purchasing this Devine USB-1 Condenser Microphone. Before you unpack all the received items, carefully read this manual to become familiar with the functions of the microphone. Also check the contents of the box to make sure all necessary parts are included.
- Page 3 Warning! - To avoid electric shocks, do not open the microphone housing. There are no user serviceable parts inside. - Keep the microphone away from intense sunshine, humidity, dust and liquids. - Make sure the microphone is placed on a stable microphone stand while used. - To avoid interference, keep the microphones away from devices like large power supplies, power transformators, radarstations and at a safe distance from computers.
- Page 4 Features - Professional studio condenser microphone - compatible with Mac and PC computers - High speed AD/DA convertion technology - Sampling Rate: 16bit/48kHz - Utilizes a high quality condenser capsule - Suitable for vocal and instrument recording - Works with every recording software or DAW (e.g. Audacity) - Can be used in Windows2000/XP/Vista and more recent versions - Installation of drivers not required - Strong output...
- Page 5 Description The Devine USB-1 is a newly designed Plug & Play condenser microphone which does not require the manual installation of drivers. This microphone utilizes a high performance USB processing chip and a high quality cardioid pickup pattern condenser capsule. The microphone produces an excellent and gentle sound.
- Page 6 Remember: less is more! Due to the extremely linear frequency response and the high sonic resolution of the USB-1, there is no need for high-frequency "EQing" that can heavily influence the signal and unnecessarily increase the noise level.
-
Page 7: Troubleshooting
Troubleshooting Problem Possible Cause Solution No sound, or very low sound USB cable not connected Connect the USB cable to your signal (properly) computer / make sure the cable is connected properly Volume set too low Increase incoming volume and gain on your mixer, interface or other sound processing device Microphone positioned too far... -
Page 8: Technical Specifications
Technical specifications Studio USB condenser microphone Ideal for recording individual instruments, vocals and speech Works on Windows and Mac computers Installs drivers automatically Element: 14 mm back electret condenser Polar Pattern: Uni-directional Connection: USB Plug-and-Play (USB A-USB B) Frequency Response: 20 Hz-17 kHz Sensitivity: -34±2dB (0dB=1V/Pa at 1KHz) Output Impedance: 1000 Ohms Load impedance: 100 Ohms (30% at 1kHz)
