Safety instructions Care and cleaning
– Carefully read the instruction manual and the information enclosed, and act accordingly.
– Keep the machine's documentation for future reference.
Risk of electric shock! – Never pull the cable to disconnect the mains plug!
– Never insert/disconnect the mains plug with damp hands.
Danger to life! For worn-out appliances:
– Disconnect the mains plug.
– Sever the mains cable and discard along with the plug.
– Destroy the lock on the washing machine door. This will prevent children from
locking themselves in and risking their lives.
Danger of suffocation! – Keep packaging, film and packaging parts out of the reach of children.
Risk of poisoning! – Keep detergents and care products out of the reach of children.
Risk of explosion! – Items of laundry pretreated with cleaning agents containing solvents, e.g. stain
remover/cleaning solvent may lead to an explosion after being loaded into the
1.
washing machine.
2.
Rinse items of laundry thoroughly by hand beforehand.
3.
Risk of injury! – The washing machine door may become very hot. 4.
5.
– Be careful when draining hot detergent solution.
6.
– Do not climb onto the washing machine.
– Do not lean on the open washing machine door.
– Do not reach into the drum if it is still rotating.
– Be careful when opening the detergent drawer while the machine is in operation.
Consumption values
depending on model
***
Electricity
Additional Programme
Programme Load Water*** Water inlet temperature
function duration ***
cold 40 °C
algod. (Cottons) (cold) 7 kg 60 l 0.24 kWh 0.24 kWh 145 min
algod. (Cottons) 30 °C** 7 kg 59 l 0.37 kWh 0.37 kWh 145 min
algod. (Cottons) 7 kg 59 l 0.98 kWh 0.64 kWh 155 min
40 °C**
algod. (Cottons) 60 °C** 7 kg 59 l 1.15 kWh 0.88 kWh 165 min
algod. (Cottons) 90 °C 7 kg 69 l 2.10 kWh 1.66 kWh 155 min
algod. (Cottons) 60 °C + eco * 7 kg 42 l 1.05 kWh 0.85 kWh 180 min
sintéticos 3.5 kg 53 l 0.62 kWh 0.43 kWh 87 min
40 °C** 1.
2.
rápido mix 40 °C** 3.5 kg 47 l 0.54 kWh 0.41 kWh 60 min
3.
delicados 30 °C 2 kg 34 l 0.19 kWh 0.19 kWh 41 min
delicados (cold) 2 kg 35 l 0.05 kWh 0.05 kWh 41 min
Information on the display panel
lana/lã 30 °C 2 kg 39 l 0.17 kWh 0.17 kWh 40 min
flashes
lana/lã 2 kg 39 l 0.03 kWh 0.03 kWh 40 min
(cold)
:
* Programme setting for testing and energy labelling in accordance with EU directive 92/75/EEC.
:
** Programme setting for testing in accordance with valid standard EN60456.
:
Note on comparative tests: For testing the test programmes, wash the specified load using the maximum spin speed.
As a short programme for coloureds, select the programme rápido mix (Quick Mix) 40 °C with the maximum spin
speed. :
*** The values deviate from the indicated values depending on water pressure, hardness, and inlet temperature, ambient tem-
:
perature, type, amount and soiling of the laundry, detergent used, fluctuations in the power supply and selected additional
functions.
7 8 8
– Risk of electric shock! Disconnect the mains plug.
Maintenance
– Risk of explosion! Do not use solvents.
Before the first wash
Detergent solution pump
Do not put laundry in the machine! Turn on the tap. Put into compartment II:
Turn the programme selector to
– approx. 2 litres of water
the mains plug.
– detergent (measure according to the manufacturer's instructions for lightly soiled laundry and water hardness)
(Start/Reload)
Turn the programme selector to sintéticos (Easy-Care) 60 °C and press . At the end of the programme, 1. Using a screwdriver or the insert for liquid detergent
turn the programme selector to o (stop).
(depending on model), open and remove the service flap.
Machine housing, control panel 2. Remove the folding gutter and place a large enough container underneath.
3. For models with a drainage hose: Remove the drainage hose from the retainer and pull it
– Wipe with a soft, damp cloth.
from the housing.
– Do not use any abrasive cloths, scourers or cleaning agents (stainless steel cleaners).
Remove the sealing cap, allow the detergent solution to flow out into the container. Replace
– Remove detergent and cleaning agent residue.
the sealing cap and place the drainage hose in the retainer.
– Do not wash the machine with a jet of water!
Cleaning the detergent drawer ...
3* For models without a drainage hose: Carefully unscrew the pump cover 180° or until the
detergent solution begins to flow out on the folding gutter. When the container is full, close
... if it contains detergent or fabric softener residues.
the pump cover and empty the container. Repeat the above steps until all the detergent
Pull out, press insert down and remove drawer completely.
solution has completely drained out.
To remove the insert: press upwards from below with your finger.
For models with insert for liquid detergent:Slide the insert upwards and remove it from the back.
Clean the detergent dispenser tray and inserts with water and a brush and dry them.
Attach the insert and engage (connect the cylinder to the guide pin).
4. Carefully unscrew the pump cover (there may be residual water).
Push in the detergent drawer.
5. Clean the interior, pump cover thread and pump housing (the impeller in the detergent
solution pump must rotate).
Leave the detergent drawer open so that any residual water can evaporate. 6. Replace the pump cover and screw it tightly.
7. Return the drainage hose (depending on model) and the folding gutter to their start position.
Drum 8. Place the service flap back on and close.
To prevent unused detergent from flowing straight into the drain during the next wash:
Leave the washing machine door open so that the drum can dry out.
For rust stains, use chlorine-free cleaning agent, not steel wool. Pour 2 litres of water into compartment II and then start the
Drainage hose at the siphon
Descaling Ensure there is no laundry in the machine!
This will not be necessary if the correct dosage of detergent is used. If it is, descale the appliance according to the Turn the programme selector to
manufacturer's instructions. Descaling products can be acquired on the website or from customer services Installation
1. Loosen the hose clamp, carefully remove the drainage hose (residual water).
instructions.
2. Clean the drainage hose and siphon connecting piece.
Emergency release
(e.g. in the event of a power cut)
3. Reattach the drainage hose and secure the connection with the hose clamp.
The programme continues to run when the power has been restored. However, if the laundry has to be removed, the
Filter in the water supply
washing machine door can be opened as follows:
Risk of electric shock!
Risk of scalding!
Do not immerse the Aqua-Stop safety device in water (contains an electric valve).
The detergent solution and laundry may be hot. Let it cool.
Do not reach into the drum if it is still rotating.
Do not open the washing machine door if water can be seen through the glass.
Reduce the water pressure in the supply hose:
Turn the programme selector to o (stop) and disconnect the mains plug. 1. Turn off the tap.
Drain the detergent solution page 10. 2. Select any programme (except
Pull the emergency release downwards with a tool and release.
3. Choose (Start/Reload). Let the programme run for approximately 40 seconds.
The washing machine door can then be opened.
4. Turn the programme selector to
Clean the filter:
depending on model
5. Disconnect the hose from the tap.
Close the washing machine door properly; laundry may be caught.
Clean the filter using a small brush.
, and/or for Standard and Aqua-Secure models:
Turn on the tap fully, supply hose kinked or trapped;
Remove the hose on the rear of the appliance.
Clean the filter page 10, water pressure too low.
Remove the filter with pliers and clean.
Detergent solution pump blocked; Clean the detergent solution pump page 10.
Drainage hose / waste pipe blocked; Clean the drainage hose at the siphon page 10. 6. Connect the hose and check for leaks.
Water in the base tub, appliance leaking. Call customer services!
Not a fault. Entry of unused hot water. Check hot water tap.
Childproof lock activated: to deactivate page 5 .
9 9
– Risk of burning!
What to do if...
Allow the detergent solution to cool.
– Turn off the tap.
Water is leaking out – Attach/replace the drainage hose correctly.
– Tighten the screw connection of the supply hose.
o (stop) and disconnect
No water supply. – (Start/Reload) not selected?
Detergent not dispensed. – Tap not turned on?
– Filter blocked? Clean the filter
– Supply hose kinked or trapped?
The appliance door will not – Safety function active. Programme stopped?
open. – (without final spin) selected?
– Can be opened by emergency release only?
– Door locked after the washing machine is switched off: Switch on the washing
machine and wait for 5 seconds.
The selected programme does – (Start/Reload) or
not start. – Washing machine door closed?
– Childproof lock active? Deactivate
Detergent solution is not – (without final spin) selected?
drained. – Clean the detergent solution pump
– Clean the waste pipe and/or drainage hose.
No water can be seen in the – Not a fault. Water remains inside below the visible area.
drum.
Spin result not satisfactory. – Not a fault. Spin control system has stopped the spin cycle. Uneven distribution of
Laundry wet/too damp. laundry.
Distribute large and small items of laundry evenly in the drum.
– menos (Reduced Ironing) selected?
– Selected speed too low?
Programme duration changes – Not a fault. The program time can vary according to the distribution of laundry, with
suddenly during operation. it therefore being possible for the display panel to show adjustments in the
(Empty) programme.
duration.
Spin cycle performed several – Not a fault. The balance control system has detected an imbalance and is
times. attempting to redress this by repeating the spin.
o (stop) and disconnect the mains plug.
Residual water in the – Not a fault: the action of the care product is not affected.
compartment for care products. – Clean the compartment if necessary
Odour formation in the washing – Run programme algod. (Cottons) 90 °C without laundry. Use standard detergent.
machine.
Status display flashing. – Too much detergent used?
Appliance has detected a If foam is escaping from the detergent drawer: mix 1 tablespoon of fabric softener
detergent overload. with ½ litre of water and pour into compartment II (not with outdoor or down
fabrics).
– Reduce the detergent dosage for the next wash cycle.
Intense noise formation, – Are the appliance feet fixed?
vibrations and "wandering" Secure the appliance feet
(Rinse)/ (Spin) // (Empty)).
during the spin cycle. – Transportation safety devices removed?
Remove transportation safety devices
o (stop). Disconnect the mains plug.
Display panel/indicator lamps – Energy-saving mode
remain turned off while the – Power cut?
machine is working. – Fuses triggered? Reset/change the fuse.
– If the fault occurs repeatedly, call customer services.
Programme sequence longer – Not a fault. Unbalanced load detection system adjusts imbalance by repeatedly
than usual. distributing the laundry.
– Not a fault: foam detection system active; adds an additional rinse cycle.
Detergent residues on the – Occasionally, phosphate-free detergents contain water-insoluble residues.
laundry. – Select (Rinse)/
If you cannot correct a fault yourself or if a repair is necessary:
o
– Turn the programme selector to (stop) and remove the mains plug from the socket.
– Turn off the water supply and call customer services
10
Read these instructions and the separate
page 10.
installation instructions before operating
the washing machine.
page 4.
page 3, 4.
page 9.
(h) (Ready in) time selected?
page 5.
page 3, 4.
page 10.
page 5.
page 5.
page 9.
Washing
Machine
Installation instructions.
Instructions for use en
Installation instructions.
page 5.
(Spin) or brush out the laundry after washing.
Observe the safety instructions on
page 8!
Installation instructions.
