Page 1: Installation Manual
Installation Manual ADAMO Split System Wall Type MCW Series 50 Hz January 2003 MS-SVN003-EN... -
Page 2: General Information
Trane MCW series offer wall mounted For installing the unit to operate installation to leave the floor space Your personal safety and the proper... -
Page 3: Table Of Contents
Contents General Information Typical Installation Location and Preparation of Unit Unit Installation Wiring Diagram Dimensional Data Notes MS-SVN003-EN... -
Page 4: Typical Installation
1 Wall Bracket : For indoor unit installation 4 Tapping Screw (Large) : For wall bracket installation Figure 1 2 Tapping Screw (Small) : For remote control mounting bracket installation 1 Remote Control Holder : For remote control unit holder MS-SVN003-EN... -
Page 5: Location And Preparation Of Unit
25 cm. or more where it is extremely dusty. • Do not install the unit where people pass in front of the fan discharge 30 cm. or more grille. 120 cm. or more Figure 3 MS-SVN003-EN... -
Page 6: Unit Installation
(Figure 7). 3. Insert the indoor unit piping into the wall hole and bind the drain hose and pipe together with Marking-off Line vinyl tape (Figure 8). Counter Weight Thread MS-SVN003-EN... -
Page 7: Indoor Unit Wiring
(bottom) of at least 3 mm. in all poles must the two bottom hooks while lowering the be incorporated in the field wiring. unit and pushing it against the wall. Figure 9 Figure 8 MS-SVN003-EN... -
Page 8: Outdoor Unit Installation
(Figure 18). downward and be sure that no not bend the tube at a radius 11. Repeat the process above for the copper scraps fall into the tube. curvature of less than 100 mm. remaining line. MS-SVN003-EN... -
Page 9: Remote Control Installation
, - cm Remote Control 6.35 mm (1/4”) dia. 150~200 130~170 Unit 9.53 mm (3/8”) dia. 350~400 300~340 12.7 mm (1/2”) dia. 500~550 430~470 15.88 mm (5/8”) dia. 600~650 520~570 Tapping Screw (small) Remote Control Holder Wireless Remote Control Figure 19 MS-SVN003-EN... -
Page 10: Outdoor Unit Wiring
• Add refrigerant through the charging valve after the completion of removing the blanking caps and fully open the service valves. Gas Leakage Inspection After charging with refrigerant, check the joints for gas leakage with gas leak detector or a soap bubble solution. MS-SVN003-EN... -
Page 11: Customer Guidance
Drain hose 2. Replacement Clamp After securing the front panel tabs into the holes in the body, fasten the bottom of the front panel with Lifted up the three screws removed in step 1. Wave End in water Figure 24 MS-SVN003-EN... -
Page 12: Wiring Diagram
Wiring Diagram MS-SVN003-EN... -
Page 13: Dimensional Data
Dimensional Data MODEL DIMENSIONS (MM.) CLEARANCE (MM.) WEIGHT (KG.) MCW 5097BA00 900.00 180.00 265.00 10.00 MCW 5127BA00 900.00 180.00 265.00 100.00 50.00 500.00 10.00 MCW 5187BA00 1,165.00 180.00 310.00 14.00 MCW 5247BA00 1,165.00 180.00 310.00 14.00 MS-SVN003-EN... -
Page 14: Notes
Notes MS-SVN003-EN... - Page 15 Notes MS-SVN003-EN...
- Page 16 35 À¡Ÿ à 8 ∂.ªŸ É ‡ ®â “ ¡‘ ß æ√“¬ µ. ”‚√ß„µâ Õ.æ√–ª√–·¥ß ®. ¡ÿ ∑ √ª√“°“√ 10130 Samrong Tai, Samutprakarn 10130 Since The Trane Company has a policy of continuous product and product data improvement, http://www.trane.com it reserves the right to change design and specifications without notice.
