Specifications

SPeCifiCAtionS
tStBM3H2CPH6W-A thermostat
The display range of temperature
The control range of temperature
Load rating
Display accuracy
Swing (cycle rate or differential)
Power source
Operating ambient
Operating humidity
Dimensions of thermostat
Frequency
Base Module
Load rating
Power source
Operating ambient
Operating humidity

trouBleSHooting

troubleshooting the thermostat communication with the base module or remote sensors:
If the thermostat is not
communicating with the
base module, follow
these steps:
If the outdoor
temperature sensor or
remote room
temperature sensor are
not communicating with
the thermostat, follow
these steps:
Revised 02-13
41ºF to 95ºF (5ºC to 35ºC)
44ºF to 90ºF (7ºC to 32ºC)
1 amp per terminal, 1.5 amp maximum all terminals combined
± 1ºF
Heating is adjustable from 0.2ºF to 2.0ºF
Cooling is adjustable from 0.2ºF to 2.0ºF
18 to 30 VAC, NEC Class II, 50/60 Hz for hardwire (common wire)
32ºF to +105ºF (0º to +41ºC)
90% non-condensing maximum
4.7"W x 4.4"H x 1.1"D
916 MHz
1 amp per terminal, 1.5 amp maximum all terminals combined
18 to 30 VAC, NEC Class II, 50/60 Hz
32ºF to +150ºF (0º to +65ºC)
90% non-condensing maximum
1. Reestablish the communication following the steps on page 13
2. Confirm that the base module has power from the air handler unit by
observing that the LED lights are visible. If LED lights are off, verify that there
is power to the air handler and the wiring between the air handler unit and
base module are correct.
3. Ensure that the thermostat has good battery power by checking if the battery
icon is present or not. If the battery icon is present on the thermostat display,
replace the batteries and perform the communication setup as described on
page 13 again.
1. Reestablish the communication for that particular device following the steps
in the manual for that component.
2. Ensure that the remote sensor has good battery power by checking if the
battery icon is present or not. The thermostat will also display "bA" next to the
components name if the sensor's batteries are low. If the battery icon is
present on the sensor's display, replace the batteries and perform the
communication setup as described in that sensor's manual.
Subject to change without prior notice
