Princeton Instruments MicroMAX System User Manual page 162

USB 2.0 Interface Addendum
4. Open WinView or WinSpec and, from Setup|Hardware..., run the Hardware
5. When the PVCAM dialog box (Figure 6) is displayed, click in the Yes radio
To Run the Application Program:
1. Verify that the ST-133A is turned on.
2. Start the application software (WinView/32 or WinSpec/32).
3. Select Hardware... from the Setup menu and on the Controller/CCD (this page
may be labeled Controller/Detector or Controller/Camera) tab page, check the Use
PVCAM checkbox
unchecked
4. Run the software in focus mode to verify communication between the ST-133A and
the host computer.
June 17, 2003
Figure 2. RSConfig dialog box
Wizard.
button, click on Next and continue through the Wizard. After the Wizard is
finished, the Controller/Camera tab card will be displayed with the Use
PVCAM checkbox selected. You should now be able to set up experiments and
acquire data.
Figure 3. Hardware Wizard: PVCAM dialog box
.
. Data transfer will be disabled if this box is left
6 of 14 Roper Scientific
E:\Manuals\USB 2.0 Installation\USB Addendum to Manual.doc
