Selecting the Shutter Setting
The Shutter Setting push switch on the rear of the Controller sets the shutter hold
Caution
voltage. Each shutter type, internal or external, requires a different setting. Consult the
table below for the proper setting for your shutter. The Shutter Setting is correctly set at
the factory for the camera's internal shutter if one is present.
To Select the Shutter Setting:
1. Verify that the Controller power is OFF.
2. Refer to Table 3 when looking at the rear of the
Controller.
3. If the setting is not correct, press the "-" or the "+"
button until the correct setting is displayed in the
window.
Connecting the TAXI
Turn the Controller power OFF (OFF = 0, ON = |) and the Computer power OFF before
connecting or disconnecting the Controller-Computer (TAXI) cable.
To Connect the TAXI Cable:
1. Verify that the Controller power is OFF.
2. Verify that the Computer power is OFF.
3. Connect one end of the TAXI cable to the 9-pin port on the Interface card.
4. Tighten down the screws to lock the connector in place.
5. Connect the other end of the cable to the "Serial Com" port on the rear of the
Controller.
6. Tighten down the screws to lock the connector in place.
MicroMAX System User Manual
Shutter Setting*
1
2
4
5
* Shutter settings 0, 3, and 6-9 are unused and are reserved for future use.
Table 3. ST-133A Shutter Setting Selection
®
(Controller-Computer) Cable
Shutter Type
25 mm Roper Scientific supplied External shutter
(typically an Entrance slit shutter)
25 mm Roper Scientific Internal shutter
35 mm Roper Scientific Internal shutter (requires 70 V
Shutter option)
40 mm Roper Scientific Internal shutter (supplied with
LN camera having a 1340 × 1300 or larger CCD)
Version 5.A
SHUTTER CONTROL
-
2
+
REMOTE
SETTING
Figure 8. Shutter Setting for
25mm Internal Shutter
