OWNER'S MANUAL
Operating and Servicing
Instructions
• Please read these
instructions carefully before
using your Lightweight
Upright.
• Let us help you put your
vacuum together or answer
any questions, call:
1-800-321-1134
(USA & Canada)
www.royalvacuums.com
For quick reference, please record your
vacuum information below.
Model #:
Mfg. Code:
(Mfg. code located on the lower backside of cleaner)
©2006 All rights reserved # 1-113858-000
7/06
