WARNING:
Cleaner
assembly
may
include small parts. Small
parts can present a choking
hazard.
Español - página E1
OWNER'S MANUAL
Operating and Servicing
Instructions
• Please read these
instructions carefully before
using your Commercial
Upright.
• Let us help you put your
vacuum together or answer
any questions, call:
1-800-321-1134
(USA & Canada)
www.royalvacuums.com
For quick reference, please record your
vacuum information below.
Model #:
Mfg. Code:
(Mfg. code located on the lower backside of cleaner)
©2005 All rights reserved # 1-113186-000
12/05

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vacuum Cleaner and is the answer not in the manual?

Questions and answers

Related Manuals for Royal Vacuum Cleaner

Summary of Contents for Royal Vacuum Cleaner

  • Page 1 OWNER’S MANUAL Operating and Servicing Instructions • Please read these instructions carefully before using your Commercial Upright. • Let us help you put your vacuum together or answer any questions, call: 1-800-321-1134 (USA & Canada) www.royalvacuums.com WARNING: For quick reference, please record your vacuum information below.

  • Page 2: Safety Instructions

    • Do not use to pick up flammable or combustible liquids, such as gasoline, or use in areas where they may be present. • Look on your vacuum cleaner and follow all label and marking instructions. • Use only a 17 gauge or higher 3-wire SJT extension cord with this cleaner. Using a cord of different type or AWG may result in increased risk of fire or electric shock.

  • Page 3: Save These Instructions

    Keep your hands, feet, hair and clothing away from moving parts; especially the revolving brush. • Do not use the vacuum cleaner without dust bag and/or filters in place. • Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.

  • Page 4: Table Of Contents

    Troubleshooting Guide....... . . Page 9 LIMITED WARRANTY To the consumer, Royal Appliance Mfg. Co. warrants this vacuum cleaner to be free of defects in material or workmanship commencing upon the date of the original purchase. Refer to your vacuum cleaner carton for the length of warranty and save your original sales receipt to validate start of warranty period.

  • Page 5: Features

    FEATURES FRONT BACK FRONT BACK 9. Upper Cord Wrap 1. Handle Grip 10. Pigtail Power Cord 2. ON/OFF Switch 11. Cord Lock 3. Upper Handle 12. Collars 4. Zipper 13. Carry Handle 5. Outer Cloth Bag 14. Lower Cord Wrap 6.

  • Page 6: How To Assemble

    HOW TO ASSEMBLE NOTE: To ensure proper operation of the cleaner, verify that the rubber O-ring is in place and tighten all collars. To attach the bag, hold the handle and firmly To attach the lower handle, align with nozzle push into lower handle (Diagram 2).

  • Page 7: Paper Bag: Removal & Replacement

    HOW TO OPERATE: CONTINUED CORD STORAGE Tilt the cleaner back before For tidy cord storage, you start vacuuming. At the wrap cord around same time, use your foot to upper and lower cord press the nozzle down onto wraps on back of the carpet.

  • Page 8: Belt Or Brushroll: Removal & Replacement

    BELT OR BRUSHROLL: REMOVAL & REPLACEMENT TOOL REQUIRED: PHILLIPS OR FLATHEAD SCREWDRIVER WARNING: TO REDUCE THE RISK OF INJURY FROM MOVING PARTS - UNPLUG BEFORE SERVICING. BELT STYLE For Belt Style 18 replacements, please call 1-800-321-1134 or visit our website at www.royalvacuums.com to locate a dealer nearest you.

  • Page 9: Edge Cleaning Bristles: Removal & Replacement

    Pg. 7. ANY OTHER SERVICING SHOULD BE DONE BY AN AUTHORIZED SERVICE REPRESENTATIVE CUSTOMER SERVICE (1-800-321-1134) In the event that further assistance is required, see your Yellow Pages for an authorized Royal Dealer. Costs of any ® transportation to and from any place of repair are to be paid by the owner. The service parts used in this unit are easily replaced and readily available from an authorized Royal ®...
  • Page 10 MANUAL DEL PROPIETARIO Instrucciones de Funcionamiento y Servicio • Por favor lea estas instrucciones con cuidado antes de usar su aspiradora vertical Commercial. • Permítanos ayudarle a ensamblar su aspiradora o a contestar sus preguntas, llame al: 1-800-321-1134 (EE.UU. y Canadá) www.royalvacuums.com ADVERTENCIA: Para tener una referencia rápida, anote por...

  • Page 11: Instrucciones De Seguridad Importantes

    (1-800-321-1134) todas las partes del cuerpo. • Apague todos los controles antes de desconectar. En caso de necesitar más ayuda, vea en las Páginas Amarillas para encontrar a un Distribuidor Autorizado Royal ® • Tenga más cuidado cuando aspire escaleras.
  • Page 12 Levante boquilla, quite los dos (2) tornillos cerca de las ruedecillas y retire el cepillo giratorio. 1. Use siempre partes de repuesto genuinas Royal ® (Diagrama 1). Suelte la protección de la boquilla tirando de Deseche la banda vieja.
  • Page 13 Royal Appliance Mfg. Co. garantiza al consumidor que esta aspiradora no tiene defectos ni de material ni de mano de obra. La garantía comienza en la fecha de compra original. Vea la caja para información de la duración de la garantía y guarde el recibo de compra original para hacer válido el inicio del período de garantía.
  • Page 14 CARACTERÍSTICAS CÓMO ENSAMBLAR NOTA: Para garantizar un funcionamiento apropiado de la aspiradora, verifique que la junta tórica esté en su sitio y PARTE FRONTAL PARTE POSTERIOR ajuste todos los collares. Para colocar la bolsa, empuje el asa con Para fijar el asa inferior, alinéela con la firmeza en el asa inferior (Diagrama 2).
