Installation Of Connected Schedule Timers; Wiring The Schedule Timer - Sanyo SHA TM64 AGB Instruction Manual

Schedule Timer

Installation of Connected Schedule Timers

When installing schedule timers (remote controller switches, system controllers, etc.) onto the wall, use the method shown in
Figs. 3-71 and 3-72.
More than
95 mm
(From wall)
Remote controller
wiring outlet
JIS C8340
Switch box for 1
switch (no cover)

Wiring the Schedule Timer

3
Before beginning wiring
2
– Use 0.5 – 2 mm
– For inter-unit control wiring, use signal wires that allow the
remote controller wiring to be differentiated from the power
wiring, and take care to prevent miswiring. (Miswiring will
damage the schedule timer.)
– Check that the schedule timer communications wiring and
power wiring are connected correctly. (Fig. 3-73)
<Basic Wiring Diagram>
Route the A/C inter-unit control wiring for central control
as shown in the fi gure at right.
The maximum number of indoor units that can be con-
nected to a single system is 64. The maximum number of
outdoor units is 30.
The maximum number of schedule timer units that can be
connected is 8. (A maximum of 10 schedule timer units
and other central control devices can be connected.)
More than 125 mm
(For connected
installation)
Fig. 3-71
wires for fi eld supply wiring.
.
More than
95 mm
(From wall)
Remote controller
wiring outlet
JIS C8340
Switch box for 2
switches (no cover)
* For maintenance reasons, leave a gap of 25 mm or more between the
remote controller switch and schedule timer if they are arranged in
parallel above/below each other.
Communications wiring
(Inter-unit control wiring)
Do not allow a screwdriver or other
Pre-
metal object to touch the PCB
cautions
terminals when the power is ON
Communi-
cations
terminal
Connected device
1
Inter-unit
communication
Timer group setting
2
3
1Gr
fixed
Schedule timer address
5
6
7
1
System 1 System 2
Inter-unit control
wiring
1-1 1-2 1-3 2-1
Depending on the model of A/C, a local adapter
NOTE
may be required.
3-104
More than
125 mm
(For connected
installation)
Fig. 3-72
Power wiring
Remote controller
wiring outlet
(remote
Power
controller
terminal
terminal)
All switches are
Permitted items for
OFF when the unit
controller operation
is shipped.
1
: OFF
Permit a l modes Perm t the below tems only
: ON
Proh bited items for controller operation
2
Remote controller
3
(4 wires)
4
2Gr 3Gr Manual
assignment
fixed fixed
Current- ime synchro-
nization communication
5 6 8
2 3 4 7
Fig. 3-73
System
3
2-3 3-1
2-2
Schedule timer
Fig. 3-74
