Sanyo SHA TM64 AGB Instruction Manual page 17

Schedule Timer
Schedule Timer and Air Conditioner Operation
Air conditioners operate either according to operations programmed from the schedule timer (starting/stopping and remote con-
trol operation enable/disable) or according to a connected remote controller or system controller.
Schedule timer settings (Example)
Operation without system controller operation
If remote controller operation is enabled, the air conditioner can be started/stopped from the remote controller.
(The air conditioner responds to the most recently pressed button.)
Air conditioner
operation
3
Remote controller
operation
Operation with system controller operation
If remote controller operation is enabled, the air conditioner can be started/stopped from the remote controller.
(The air conditioner responds to the most recently pressed button.)
The remote controller operation enable/disable set from the system controller (Centralized control 1 to 4) is canceled accord-
ing to programmed operations.
Air conditioner
operation
Remote controller
operation
8:00
Stopped
Running
Enabled
*1
*1 Whether remote controller operation is enabled or disabled depends on the setting of the
previous day.
*2 Since remote controller operation is disabled, operation remains disabled.
*3 The remote controller remains disabled the next day and thereafter until it is enabled in the
remote controller operation enable/disable setting.
Operation from the system controller
[Stop + RC operation disable]
8:00
Stopped Running Stopped
Disabled
Enabled
*1
*1 Whether remote controller operation is enabled or disabled depends on the setting of the
previous day.
.
12:00 13:00
Stopped
Running
Disabled
[Stop + RC operation enable]
12:00 13:00
Running Stopped
Enabled
17:00 18:00 20:00
Stopped
Enabled Disabled
*3
*2
17:00 18:00 20:00
Disabled Disabled
Enabled
