- Page 1 Installation Guide CLR2160 — Clear Ice Maker ® CLRCO2175 Combo — Clear Ice Maker/Refrigerator www.U-LineService.com Phone (414) 354-0300 • FAX (414) 354-7905 Service & Parts Tech Lines Phone (800) 779-2547 • FAX (414) 354-5696 OnlineService@U-Line.com ©2008 U-Line Corporation 03/2008...
-
Page 2: Table Of Contents
Contents Contents ........2 1-Follow Safety Precautions . -
Page 3: 2-Inspect And Plan
Note: Items with an “*” in front of them may have been shipped inside your unit. If not, these items can be purchased in a kit from your dealer. Order U-Line Part No. U-CLRDRAINKIT and this kit will contain all these items. -
Page 4: Exterior Cleaning
For best results use Claire Stainless Steel Polish and Cleaner, which can be purchased from U-Line Corporation. (The part number is 173348.) Comparable products are acceptable. Frequent cleaning will remove surface contamination that could lead to rust. -
Page 5: 3-Prepare Site
3 Prepare Site Your U-Line product has been designed for either free- standing or built-in installation. When built-in, your unit does not require additional air space for top, sides or rear. However, the front grille must NOT be obstructed and clearance is required for water, drain and electrical connections in the rear. -
Page 6: Cut-Out Dimensions Clrco2175
Cut-Out Dimensions CLRCO2175 See Electrical Specifications for Power Supply 34-1/4" 35-1/8" 8" 24-3/16" Figure 4 Follow the cut-out drawing in Figure 4. The 24-3/16" width allows 1/4" for ease in installation and removal of the unit. The 24" depth is the cabinet depth in most installations. -
Page 7: Reversing The Door
Reversing the Door (Black and White Units Only) All U-Line units (except Stainless Steel models) may be left- or right-hand opening. The door opening is easily reversed by moving the hinge hardware to the opposite side. The top hinge hardware will be used on the... -
Page 8: Other Site Requirements
Drain can NOT be located directly below unit. Unit has a solid base that will not allow unit to drain below itself. Environmental Requirements Many U-Line models are designed to operate in harsh outdoor environments. Special considerations include the following: •... -
Page 9: Side-By-Side Installation Instructions Clrco2175
Side-By-Side Installation Instructions CLRCO2175 For a complete refreshment center, install your CLRCO2175 Clear Ice Maker/Refrigerator beside a U-Line Drawer or Wine Captain Model (see Figure 15 for typical cut-out). Note that each Side-By-Side Installation will be different. • Cut-out width for a side-by-side installation is the total of the widths listed under Cut-Out Dimensions in each unit’s Installation Guide. -
Page 10: Full Overlay Door Panel
Full Overlay Door Panel Door Panel Preparation A full overlay door panel completely covers the doorframe and handle to give a built-in appearance. See your U-Line dealer for the optional Full Overlay Door Panel Kit. 2175 Models: P/N U-OL2175B -- Black P/N U-OL2175W -- White 2115 &... - Page 11 2. Create a relief (Figure 19) for pivot plate by cutting notch in top corner of overlay panel. Refer to Figure 20 for exact specifications. 15/32" ø 0.177" (#16 Drill) 11/16" Deep 3/8" 31/32" .125" 11/16" 1/4" Ref 3/4" Min Ref 3/8"...
- Page 12 Tape Back of Wood Panel 1-3/4" Top Top of Wood Panel 3/8" Figure 23 Both Sides Drill ø 5/32" x 3/8" Deep 7 Places Model 2175 6 places Model 2115 and CLR2160 For use with #10 x 5/8" Wood Screw and Nylon Spacer 1"...
- Page 13 4. Attach Top Pivot Plate to door handle, on side where hinges will be. Use the two #8-32 x 1/2" Flat Head Phillips screws (Black) supplied with kit (see Figure 28). #8-32 x 1/2" Flat Head Screws Black, Two Places 3/4"...
-
Page 14: 5-Adjust Door
5 Adjust Door Checking Door Alignment The unit’s door is aligned at the factory before shipment. However, its alignment could have been disturbed during shipment or during door panel installation. IMPORTANT Properly aligned, the door should be 1/8" below the top of the unit’s cabinet, NOT flush with the top (see Figure 31). -
Page 15: 6-Prepare Plumbing
Figure 35 03/2008 CLR2160/CLRCO2175 Ice Makers 2. Locate the U-Line supplied garden hose fitting. Ensure the end of the copper tubing has been cut straight and free of burrs. Slide the compression nut and ferrule onto the copper tubing as shown (see Figure 36). Push the assembly completely into the the garden hose fitting and tighten using the two wrenches. - Page 16 Gravity Drain, you may have ordered the CLR2160 or CLRCO2175 with a U-Line P60 Drain Pump. See Figures 42, 43 and 44 for typical installations requiring a Drain Pump. If you need to install a P60 Drain Pump into your unit, see Locally-Installed Drain Pump on Page 17.
- Page 17 In the event of a power outage, restricted drain or pump ULIN_0575_A failure, the failure to use the U-Line P60 drain pump or a pump with the above listed specifications, could result in substantial water leakage and pooling with severe and costly water damage and related consequential damages and harm.
-
Page 18: Final Water/Drain Connection
Stand Pipe P60 Pump Required Waste Figure 42 Disposal Assembly P60 Pump Required Air Gap (Optional Hook-Up) Figure 43 Y-Branch Tailpiece P60 Pump Required Air Gap (Optional Hook-Up) Figure 44 WARNING To prevent accidental electrocution, make certain that the floor surfaces surrounding the unit are dry whenever power is removed from, or applied to, the unit. - Page 19 3. Attach the copper water line to the back of the unit using the supplied clamp and the back panel screw (see Figure 46, CLR2175 model shown). This will prevent rotation of the line when moving the unit. 4. Plug in the unit and put unit into OFF mode by holding the power key for 10 seconds.
-
Page 20: Electrical Specifications
7 Prepare Power Supply Electrical Specifications CAUTION Electrical installation must observe all state and local codes. This unit requires connection to a grounded (three- prong), polarized receptacle that has been placed by a qualified electrician. The unit requires a grounded and polarized 115 VAC, 60 Hz, 15A power supply (normal household current). -
Page 21: Installation Tip
2. If the ice maker is not level, adjust the feet on the corners of the unit as necessary (see Figure 50). Turn Foot to Adjust Figure 50 3. Check the levelness after each adjustment and repeat the previous steps until the unit is level. Go on to 9 Install the Unit. -
Page 22: Relocating The Shelves (Clrco2175)
Relocating the Shelves (CLRCO2175) Both the glass shelves in the refrigerator and the inner door shelves can be moved to accommodate your bottles, cans and containers. Glass Shelves on Right-Hand Hinge Units 1. Open door fully, grasp shelf firmly, lift front edge slightly and pull straight out. -
Page 23: 10-Start-Up For The First Time
Once installation and leveling is complete, the unit is ready for initial start-up and operation. The display panel is located inside the unit, on the top of the refrigerator side (see Figure 53, 1). The LED display shows the temperature set point and is calibrated in degrees Fahrenheit. -
Page 24: Start-Up Troubleshooting
See the Use and Care Guide’s Troubleshooting Guide for more solutions. For more than four decades, U-Line has distinguished itself as the leader in built-in undercounter ice making, refrigeration and wine storage appliances. U-Line Corporation, located in Milwaukee, WI, is a family operated manufacturer of built-in undercounter icemakers, Combo refrigerators, refrigerated drawers and refrigerator/freezers.
