The One
Limited Edition Amplifier
Serial# ___________
QC Tested By: ____________________________
QC TEST DA TE: ____________________________
Features:
• Limited Edition Production Run featuring each unit number laser cut into the heatsink
• Six Massive Unregulated Power Supplies with Hand Wound Transformers
• Three Ounce Gold Plated Circuit Board
• High Efficiency Class D Topology that operates at up to 16 volts
• Three 1/0 Gauge Direct Insert Power Terminals
• Temperature Controlled Fan Cooling System
• 24dB Variable Low Pass and Subsonic Crossovers
• Two units are "strappable" or linkable for insane power into a single subwoofer
• Hand Crafted Wood Shipping Crate
• LPL44 - Low Pass Level Control Ready
• RMD - Remote Monitoring Display Port
Amplifier Manual
© 2010 Phoenix Gold • www.phoenixgold.com
Advertisement
Table of Contents
Related Manuals for Phoenix Gold The One Limited Edition Amplifier
Summary of Contents for Phoenix Gold The One Limited Edition Amplifier
- Page 1 • Two units are “strappable” or linkable for insane power into a single subwoofer • Hand Crafted Wood Shipping Crate • LPL44 - Low Pass Level Control Ready • RMD - Remote Monitoring Display Port © 2010 Phoenix Gold • www.phoenixgold.com...
-
Page 2: Serial Number
Phoenix Gold is not responsible for speaker failures or damage. Phoenix Gold has taken special care to make sure each amplifier is of the highest quality possible. After the electrical components are pre-tested and inserted into the circuit boards then each amplifier is carefully hand assembled one by one. - Page 3 3mm thick high current Three high current 1/0 power custom made buss bars terminals are ready to pass up to 900 amps continuously 3 Ounce Gold Plated Circuit Board © 2010 Phoenix Gold • www.phoenixgold.com...
- Page 4 18000 x 1 @ 1 ohm Minimum Power/Ground Wire Size: 1/0 Gauge x 3 36000 x 1 @ 2 ohm (Strapped) Dimensions: 38.6” L x 12.2” W x 3.0” H 980mm x 310mm x 77mm © 2010 Phoenix Gold • www.phoenixgold.com...
- Page 5 TERMINALS, IT CAN DAMAGE THE AMPLIFIER. unit or ignition. This must be connected to the negative terminal of the car’s battery or bolted to a clean, unpainted part of the chassis of the vehicle. 1/0 gauge wire is required. © 2010 Phoenix Gold • www.phoenixgold.com...
- Page 6 The One requires a massive electrical system to power it correctly. The below system is the MINIMUM REQUIREMENT. Each vehicle will vary so please contact your local dealer or Phoenix Gold for questions about the proper electrical system before attempting installation.
- Page 7 CAUTION: This is an insane amount of power into a single voice coil. PG is not responsible for speaker failures or damage. FROM HEADUNIT OUTPUT MASTER SINGLE CHANNEL INPUT USED SLAVE Slave amplifier’s pre-amp section is disabled © 2010 Phoenix Gold • www.phoenixgold.com...
- Page 8 LIMITED WARRANTY ON AMPLIFIERS Phoenix Gold warrants this product to be free of defects in materials and workmanship for a period of one (1) year from the original date of purchase. This warranty is not transferable and applies only to the original purchaser from an authorized Phoenix Gold dealer in the United States of America only. Should service be necessary under this warranty for any reason due to manufacturing defect or malfunction, Phoenix Gold will (at its discretion), repair or replace the defective product with new or remanufactured product at no charge.
