- Page 1 www.phoenixgold.com AMPLIFIER MANUALP...
- Page 2 Congratulations on purchasing one of the finest amplifiers available in the car audio marketplace today. The Xenon amplifiers were designed and engineered with the spirit of the original Phoenix Gold MS and M series to deliver bulletproof performance at any impedance while delivering unbelievable sound quality.
- Page 3 Audiophile 24dB Linkwitz-Riley crossover controls provide state of the art slope control. The Xe.tune system allows users to perfectly adjust crossover slope every time without errors or guess work. Every Xenon amplifier has a separately defeatable continuously variable high and low pass filter for maximum processing flexibility Now that’s total control!
- Page 4 SUBSONIC CLICKS 5-55Hz Speaker Outputs Used to connect the amplifier to speakers. The separate + and – terminals are internally wired in parallel. Minimum speaker cable size is 12 gauge. Lowest recommend impedance is 1 ohm. LOWPASS 30-300Hz <10 <10 <10 <10 <10...
- Page 5 AUX OUTPUT A L PL4 4 www.phoenixgold.com PORTRe m o t e...
- Page 6 HIGHPASS CLICKS 40-400Hz BRIDGED Speaker Outputs Used to connect the amplifier to speakers. Use the left + and right – terminals for bridged mode. Minimum speaker cable size is 16 gauge. Use 12 Gauge for bridged operation. Minimum imped- ance is 2 ohm bridged or 1 ohm stereo.
- Page 7 AUX OUTPUT AUX OUTPUT B+ R B– B+ This must be connected to the fused positive terminal (+12V) of the car’s battery. X100.2 = 8 Gauge X200.2 = 4 Gauge REMOTE This must be connected to switched +12V, usually a trigger wire coming from the head unit or ignition.
- Page 8 Speaker Outputs Used to connect the amplifier to speakers. Use the left + and right – terminals for bridged mode. Minimum speaker cable size is 16 gauge. Use 12 Gauge for bridged operation. Minimum imped- ance is 2 ohm bridged or 1 ohm stereo.
-
Page 9: Status Led
AUX OUTPUT AUX OUTPUT Provides a full range signal This port is for connecting for an additional amplifier. the optional LPL44 Remote Lowpass Level Control knob allowing up to 20dB of volume adjust- ment. The LPL44 will only work when the lowpass crossover is on. - Page 10 www.phoenixgold.com...
-
Page 11: Limited Warranty
Phoenix Gold, or damage that is attributable to Acts of God. It does not cover costs of transportation to Phoenix Gold or damage in transit. This warranty will become void if the serial number identification has been wholly or partially removed, altered or erased. - Page 12 PHOENIX GOLD INTERNATIONAL, Inc. 9300 North Decatur Portland, OR 97203 Tel: 503.286.9300 Fax: 503.978.3380 www.phoenixgold.com rev A 1/04 www.phoenixgold.com...
