Summary of Contents for Baumatic BWM50
- Page 1 BWM50 5 kg BWM70 7 kg Top loading washing machine...
- Page 3 USER MANUAL FOR YOUR BAUMATIC BWM50 5 kg BWM70 7 kg Top loading washing machine NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference;...
-
Page 4: Table Of Contents
Contents Environmental note Important safety information 6 – 8 Specifications 8 – 12 Dimensions Control panel Detergent drawer Bleaching agents Softener Preparing the wash cycle 12 - 13 Preparing your garments for washing 12 - 13 A selection of wash care symbols Selecting a wash program 14 –... -
Page 5: Environmental Note
Environmental note... -
Page 6: Important Safety Information
General Safety o Repairs to your appliance must only be carried out by a Baumatic engineer or one of its authorised service agents. Any attempt by an inexperienced person to repair the appliance, could result in injury or damage to your washing machine. - Page 7 Baumatic cannot be held responsible for any damage that may result. o The lid should not be opened when the machine is spinning. The machine will stop spinning when the lid is opened but the tub will not stop turning immediately.
-
Page 8: Specifications
5 programs o 5 kg wash load (BWM50) o 7 kg wash load (BWM70) o 720 rpm maximum spin speed (BWM70) o 660 rpm maximum spin speed (BWM50) o LED display o Delay start o Wash temperature control o Safety lock... -
Page 9: Dimensions
BWM70 Appliance dimensions Height: 920 mm Width : 560 mm Depth: 565 mm BWM50 Appliance dimensions Height: 900 mm Width: 540 mm Depth: 545 mm For future reference please record the following information which can be found on the rating plate and the date of purchase which can be found on your sales invoice. -
Page 10: Control Panel
Control panel 1) Water level button: Use this button to select the appropriate water level according to the volume of laundry. 2) Process button: Press this button to set the features of the wash program. Each press of the button will scroll through the following choices. -
Page 11: Detergent Drawer
Detergent drawer o Open the washing machine lid and pull out the detergent drawer to add detergent powder to the wash program. Then push the drawer back in before introducing laundry into the machine and setting the wash program. Only powder detergents should be placed in the drawer. -
Page 12: Softener
Softener o An automatic softener input device is not available with this machine, so if you would like to use it, you should pause the wash program before the last bleaching operation and introduce softener manually. o You should always follow the manufacturer’s directions when using softener to avoid damage to clothing. -
Page 13: A Selection Of Wash Care Symbols
o Woollens and knitted coloured fabrics should be turned inside out before being washed in the appliance. o Small delicate items (tights, baby socks) should be placed in either a washing net or a zipped pillow case. o Curtains should be handled with particular care. All plastic hooks or metal strips must be removed before being washed in the appliance. -
Page 14: Selecting A Wash Program
Selecting a wash program Detergent o If you are placing detergent directly into the drum, you should dilute it first (See ‘Detergent Drawer’ section). o Alternatively, put detergent powder into the detergent drawer. Please see the table on page 14 for recommended amounts according to the water level and weight of laundry. -
Page 15: Setting The Program Features
(1). Please see the table below for a guide to the appropriate water level for different load sizes and the required amount of detergent. BWM50 Water Laundry Water... -
Page 16: Washing Load Size
4-5.5 2.5-4 1-2.5 Less than 1 IMPORTANT: A high water level should not be selected for a washing load below 1 kg as water can splash during the cycle. Washing load size o The water level and amount of detergent required largely depends on the size of the wash load. -
Page 17: Delay Start
Delay start You are able to delay the start of a wash cycle so the laundry is finished at a time that is most convenient to you. o You should introduce the detergent into the detergent drawer or drum and then add the laundry as normal. You can then select your required wash program following the instructions outlined in the previous section. -
Page 18: Imbalance Control
Imbalance control o If the laundry load is unbalanced when the washing machine begins to spin, the cycle will stop while more water is added to redistribute the load. This process may be repeated until the load is sufficiently balanced for the spin to continue. o If there is excessive vibration during the spin part of the program, you should open the lid and wait until the drum stops moving. -
Page 19: Detergent Drawer
Detergent drawer Occasionally the detergent drawer should be cleaned, to remove any detergent residue that has built up. o Remove the drawer and wash in warm, soapy water. o Detergent can also accumulate inside the detergent drawer recess, so you should also clean this out using a brush. o Once you have finished cleaning the detergent drawer and recess, you should slide the drawer back into its original position. - Page 20 o Detach the filter from the drum wall. o Wash the filter and filter cover in warm soapy water before drying thoroughly. o Clip filter back into position on the drum wall. o Reattach the filter cover by sliding it back down into its original position.
-
Page 21: Removing Stains
Removing stains Garments that are covered in stains, grease or are heavily soiled may need to be pre-washed or soaked before being placed inside of the washing machine. o Soaking helps to remove protein-type stains, like blood, milk or grass. o Pre-washing by hand helps to loosen soil before the main wash. - Page 22 Tomato Scrape the dried pieces without ruining the material, then paste leave in cold water for about 30 minutes and wash by rubbing with detergent. Meat broth/ Eliminate the dried stain residues and wipe with a sponge or soft cloth wetted in cold water. Rub with detergent and wash with diluted lye.
-
Page 23: Poor Wash Results
Poor wash results My garments are looking grey and there are limescale deposits present in the drum of my washing machine. o There is not enough detergent being added. o The incorrect detergent is being used. o Stains are not being pre-treated. o The correct wash program or wash temperature was not selected. -
Page 24: Installation
Installation IMPORTANT: THIS INSTALLATION MUST COMPLETED BY A SUITABLY QUALIFIED PERSON. BAUMATIC ONLY SANCTION INSTALLATION GIVEN THIS INSTRUCTION MANUAL. SHOULD KEEP THE TRANSIT PACKAGING, IN CASE YOU NEED TO TRANSPORT THE MACHINE IN THE FUTURE. Locating your washing machine o Before commencing installation, check the location where you intend to install the appliance. -
Page 25: Adjusting The Height Of The Appliance
Adjusting the height of the appliance o Place the machine on a solid and level floor surface. o If the floor is uneven, the appliance should be adjusted otherwise the washing machine will not function properly. The uneven surface also vibrates the machine and causes it to move from its original position while in use. -
Page 26: Installing The Bottom Cover
Installing the bottom cover o The bottom cover should be placed between the machine case and the foam lining. o After unpacking the machine, turn the appliance upside down gently onto a soft surface such as a towel or blanket. o Insert the bottom cover in the groove on the base from the back of the machine and fasten it in place with the self-tapping screws supplied. -
Page 27: Connecting To The Mains Water Supply
Connecting to the mains water supply IMPORTANT: The washing machine should never be connected to the water mains using an existing inlet hose, YOU MUST utilise the inlet hose that is provided with the appliance. Your appliance should be connected to a cold and hot water supply. o Ensure that a washer is placed inside the inlet pipe joint,... -
Page 28: Connecting To The Water Outlet
Connecting to the water outlet o Remove the accessories which will include a drainage pipe, clamp and sealing ring. o Position the clamp over the drainage pipe. o Fix the sealing ring onto the water outlet port. o Attach the drainage pipe over the sealing ring onto the water outlet port. -
Page 29: Power Supply
o The drain hose should not be positioned any higher than 90 cm as this will cause drainage problems. o You can place the end of the drain hose in your drain pipe. Push it a short way down into your drain pipe. o IMPORTANT: Do not insert the drain hose too deeply into the water pipe, as this may cause siphoning. -
Page 30: Before First Use Maintenance Wash
o The moulded plug that is supplied with the appliance must be placed into an earthed and insulated socket. o Broken or damaged power leads must only be replaced by a suitably qualified person. A power lead of a similar type must be used in replacement. - Page 31 You should turn the washing machine off using the POWER button. Disconnect the appliance from your mains supply. Then arrange for an engineer to attend the appliance. You should contact Baumatic Customer Care Department on 1800 444 357. ENGINEER ATTENDS...
-
Page 32: General Troubleshooting
General troubleshooting Problem Possible solution o When the machine o The washing machine will start from starts from the the SPIN process in order to spin RINSE function, the out the water and detergent from washing machine the clothes, then input the water (if does not add water. - Page 33 Or any installation other than the one specified by Baumatic Ltd. has been completed. Please refer to the conditions of guarantee that appear on the warranty card that you receive with the appliance.
-
Page 34: Contact Details
Service Telephone 1800 444 357 Website www.thinkappliances.com Applico Ltd. P.O. 92900 Onehunga, Auckland, New Zealand 1061 Website www.applico.nz United Kingdom Baumatic Ltd., Baumatic Buildings, 6 Bennet Road, Reading, Berkshire RG2 0QX United Kingdom Sales Telephone (0118) 933 6900 Website: www.baumatic.co.uk...
