I N S T A L L A T I O N G U I D e
for the
SB-GM-SLVCRW/10W1v2
1999 - 2006 Chevrolet Silverado / GMC Sierra
Crew Cab
Thank you for choosing a JL Audio Stealthbox
With proper installation, your new vehicle-specific enclosed subwoofer system
will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthbox
JL Audio dealer. The installation professionals employed by your dealer have the necessary
tools and experience to disassemble and reassemble your vehicle properly. Also, keep in
mind that your warranty coverage extends to two (2) years if your system is installed
or approved by your authorized JL Audio dealer. If you prefer to perform your own
installation, please read this installation guide completely before beginning the process.
for your automotive sound system.
®
installed by your authorized
®
If you choose to perform the installation yourself, it is absolutely vital that
the Stealthbox ® be properly mounted to the vehicle according to these
instructions. Failure to mount the enclosure properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the enclosure
caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a collision
or sudden deceleration.
C
A
B
SB-GM-SLVCRW/10W1v2_INSTR_SKU#011173
INSTALLATION
D I F F I C U L T Y :
5
eSTIMATeD TIMe:
2-3 HOURS
S T e P 1
Lower both sides of the rear seating.
Remove the jack (A), jack tools (B) and the rear window
sill plate (C).
S T e P 2
With a Phillips screw driver, remove the two screws that
secure the passenger's side c-pillar to the rear wall.
S T e P 3
Pull off the passenger's side rear door sill plate.
Continued on Next Page
