Charcoal Grill 625

Product Guide
Model 13301565
IMPORTANT: Fill out the product record information below.
Model Number
Date Purchased
WARNING
CARBON MONOXIDE HAZARD
Burning charcoal inside can kill you. It gives off carbon
monoxide, which has no odor. NEVER burn charcoal
inside homes, vehicles, or tents.
WARNING
Failure to follow all manufacturer's instructions could
result in serious personal injury and/or property
damage.
INSTALLER/ASSEMBLER:
Leave this manual with consumer.
CONSUMER:
Keep this manual for future reference.
If you have questions or need assistance during assembly, please call 1-800-241-7548.
To insure your satisfaction and for follow-up service, register your appliance online at www.charbroil.com/register
FOR OUTDOOR USE ONLY
Tools needed for assembly:
Phillips Screwdriver
Two adjustable wrenches
CAUTION
Read and follow all safety statements, assembly
instructions, and use and care directions before
attempting to assemble and cook.
CAUTION
Some parts may contain sharp edges! Wear
protective gloves if necessary.
CAUTION
THIS UNIT IS HEAVY! DO NOT attempt to assemble
without a helper.
42804840 - 09/20/12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 13301565 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Char-Broil 13301565

Summary of Contents for Char-Broil 13301565

  • Page 1: Product Record Information

    Charcoal Grill 625 Product Guide Model 13301565 IMPORTANT: Fill out the product record information below. Model Number Tools needed for assembly: Phillips Screwdriver Date Purchased Two adjustable wrenches FOR OUTDOOR USE ONLY WARNING CAUTION CARBON MONOXIDE HAZARD Read and follow all safety statements, assembly Burning charcoal inside can kill you.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING Product Record Information ......1 FAILURE TO READ AND FOLLOW INSTRUCTIONS FOR Safety Symbols.

  • Page 3: Preparing To Use Your Grill

    Re-season your grates frequently, particularly when new. If rust occurs, it is an indication that the grates have not been seasoned enough or the seasoning has been burned off. Clean with a heavy brush like Char-Broil’s Brush Hawg. Reapply vegetable shortening and heat as indicated above to re-season the grates.

  • Page 4: Cooking Tips

    COOKING TIPS Building Your Fire Stack charcoal briquettes or wood into a pyramid-shaped pile on top of the charcoal grate. We recommend using 4 pound (approximately 60 briquettes) to start your fire, adding more as needed. If using lighter fluid, saturate the charcoal briquettes with lighter fluid and let it soak in for approximately 5 minutes.
  • Page 5 Direct and Indirect Grilling Direct Grilling - For most grilling, the ignited coals are spread in a single layer under the food. This is called direct grilling and is appropriate for relatively quick-cooking items such as hamburgers, steaks and most seafood. The single layer of coals emits even, steady heat, whether the grill lid is open or closed, and represents the way most people grill.

  • Page 6: Limited Warranty

    LIMITED WARRANTY This warranty only applies to units purchased from an authorized retailer. Manufacturer warrants to the original consumer-purchaser only that this product shall be free from defects in workmanship and materials after correct assembly and under normal and reasonable home use for the periods indicated below beginning on the date of purchase*.

  • Page 7: Parts List/ Parts Diagram

    PARTS LIST Key Qty Description Temperature Gauge Key Qty Description Wheel Lid Assembly Storage Rack Swing-Away Grate Lid Hinge Pin Kit Cooking Grate Smoke Stack Fire Grate Hanger Handle Barrel Spring Butterfly Damper Lid Handle Ash Pan/Fire Grate Side Shelf Front Shelf Bracket, RH Firebox Front Shelf Bracket, LH...

  • Page 8: Assembly

    ASSEMBLY FIRST, GET A HELPER! This unit is heavy and requires a second person for lifting and moving. NEXT, pick a suitable location to work. Open the carton and slit the corners so that the carton lays flat. This will give you a protective surface during assembly.
  • Page 9 Lay the leg assembly on its side with cart braces pointing upward. insert the storage rack hooks into leg holes and swing rack upward, parallel to leg braces. Storage Rack With aid of a helper, place leg holes of remaining leg assembly over storage rack and rotate leg assembly unitl it meets the cart braces.
  • Page 10 Insert a small Hitch Pin Clip into the hole at one end of the axle and bend the ends of the pin back so that it cannot be removed. Slide a wheel onto the axle. Slide the axle through the holes at the ends of the short legs. Slide the remaining wheel onto the axle and secure with the remaining Hitch Pin Clip.
  • Page 11 • Attach LH and RH Front Shelf Brackets to the firebox using 4 each 1/4-20" Shoulder Bolts and 4 each 1/4-20 flange nuts. • After the front shelf brackets are secured, attach the front shelf slats to the brackets using 4 each 1/4-20x1 1/4 screws and 4 each 1/4-20 flange nuts.
  • Page 12 Place Grill Lid on top of firebox assembly. Align hinge holes on back of unit. With the aid of a helper, attach Grill Lid to firebox using 2 each Hinge Pins. Once Hinge Pins are in place, insert Large Hitch Pin Clip into hole in Hinge Pin.
  • Page 13 Insert the Ash Pan/Fire Grate into the firebox as shown below. The charcoal tray hanger will rest on the hanger tabs on the firebox. Next remove the wingnut from the Temperature Gauge and insert the gauge through the hole in the Grill Lid.

  • Page 14: Hardware List

    HARDWARE LIST Hardware is shown actual size. You may have spare hardware after assembly is complete. 1/4-20 1/4-20 1/4” 1/4” Shoulder Bolt Flange Nut Lock Washer Flat Washer Qty. 4 Qty. 33 Qty. 3 Qty. 2 1/4-20x1/2” 1/4-20x3/4” 1/4-20x1 1/4” 1/4-20x1 3/4”...

  • Page 15: Registration Card

    Mail to: / Enviar a: / Envoyer à : Quel produit enregistrez-vous? 1. Gas Grill | Parrilla a gas | Gril au gaz Char-Broil Warranty Registraon 2. Electric Grill | Parrilla eléctrica | Gril électrique 3. Smoker | Ahumador | Fumoir P.O.

  • Page 16: Thank You

    THANK YOU FOR YOUR RECENT PURCHASE FROM CHECK OUT THESE GREAT FEATURES ON OUR WEBSITE Valuable product information • Inspiring grilling accessories • Reliable customer support • Delicious recipes and tips from chefs • Exciting events and promotions • And much more! •...
