Ethernet Smart Cable
User Manual
Introduction
Zilog's Ethernet Smart Cable, part number ZENETSC0100ZACG, allows you to connect
®
Z8 Encore!
, Z8 Encore! XP
Zilog Developer Studio II (ZDS II) host system using an Ethernet connection.
This user manual provides instructions for installing the Ethernet Smart Cable hardware.
Instructions are also provided for Ethernet-equipped host PCs that are not network-con-
nected. After the Ethernet Smart Cable is connected, proceed with debugging as described
in the documentation specific to your development kit.
Kit Contents
To determine the contents of your kit, refer to the Ethernet Smart Cable Packing List
(PAK0019), a paper insert included with your kit.
Software and Hardware Requirements
The requirements for using the Ethernet Smart Cable are:
•
A host PC with ZDS II v4.10.0 or later for Z8 Encore!, eZ80Acclaim!, or ZNEO. To
determine ZDS II requirements for your host system, refer to the quick start guide for
your specific development kit. The latest version of ZDS II is available as a free down-
load from
the Zilog
•
An available 10/100 Mbps Ethernet connection.
Note:
If you are using ZDS II – eZ80Acclaim! versions earlier than 4.10.0, see the
Using the Ethernet Smart Cable on ZDS II – eZ80Acclaim! Versions Earlier
than 4.10.0
®
™
, ZNEO
and eZ80Acclaim!
Store.
section on page 11.
®
Copyright ©2012 Zilog
www.zilog.com
®
development boards to a
, Inc. All rights reserved.
UM020705-1012
Advertisement
Table of Contents
Related Manuals for ZiLOG ZENETSC0100ZACG
Summary of Contents for ZiLOG ZENETSC0100ZACG
-
Page 1: Kit Contents
Ethernet Smart Cable User Manual UM020705-1012 Introduction Zilog’s Ethernet Smart Cable, part number ZENETSC0100ZACG, allows you to connect ® ® ® ™ Z8 Encore! , Z8 Encore! XP , ZNEO and eZ80Acclaim! development boards to a Zilog Developer Studio II (ZDS II) host system using an Ethernet connection. -
Page 2: Supported Target Environments
Ethernet Smart Cable User Manual Supported Target Environments The supported target environments are described in the following table. System Clock Power Supply Minimum Maximum Minimum Maximum Current* Development Board Z8 Encore! 32 kHz 20 MHz 2.7 V 3.6 V 2 mA ZNEO 10 kHz 20 MHz... -
Page 3: Connecting The Ethernet Smart Cable To A Dhcp-Based Network
Ethernet Smart Cable User Manual Connecting the Ethernet Smart Cable to a DHCP-Based Network The following considerations must be determined prior to connecting the Ethernet Smart Cable to a DHCP-based network: • An active Ethernet connection must be available, such as from an Ethernet hub •... -
Page 4: Connecting The Ethernet Smart Cable Directly To A Host Pc
Ethernet Smart Cable User Manual 3. Launch ZDS II. 4. Navigate via the menu in ZDS II to open one of the projects listed in the samples File directory of your ZDS II installation. Project Settings 5. Select to display the Project Settings dialog. - Page 5 Ethernet Smart Cable User Manual 2. Use the Ethernet crossover cable supplied with the Ethernet Smart Cable to connect the Ethernet Smart Cable to the host PC’s Ethernet port. 3. Connect the 5 V DC power supply to the Ethernet Smart Cable power connector. As a result, the green PWR and RUN LEDs will illuminate.
- Page 6 Ethernet Smart Cable User Manual 5. In the panel labeled , double-click the LAN or High-Speed Internet Local Area Con- nection icon. The Local Area Connection Status dialog box will appear, as shown in Figure 3. Figure 3. The Local Area Connection Status Dialog 6.
- Page 7 Ethernet Smart Cable User Manual Figure 4. The Local Area Connection Properties Dialog 7. In the panel labeled , select the This connection uses the following items: Internet Protocol (TCP/IP) item to highlight it, and click the Properties button (see Figure 4 for an example).
-
Page 8: Changing The Default Settings Of The Ethernet Smart Cable
Ethernet Smart Cable User Manual Figure 5. The Internet Protocol Properties Dialog 8. Enter an IP address of and a subnet mask of . These 192.168.1.21 255.255.255.0 values place the PC on the same network as the Ethernet Smart Cable, and do not con- flict with the IP address of the Ethernet Smart Cable. - Page 9 Ethernet Smart Cable User Manual cable’s IP address, which can be obtained from ZDS II in the ZDS II win- Project Settings dow; see Steps 5 through 9 on page 4). Observe the following steps to change the Ethernet Smart Cable’s default settings: 1.
-
Page 10: Restoring The Ethernet Smart Cable Factory Settings
Ethernet Smart Cable User Manual Figure 7. Ethernet Smart Cable Password Web Page 3. After the configuration in the tab are changed, click the button. A Settings Submit message acknowledging that changes have been made will appear beneath the web page. -
Page 11: Connecting To The Target Board
Observe the following procedure to obtain the IP address of the Ethernet Smart Cable when configured for DHCP. 1. Download the ESCScan utility installation file from the Zilog Store; simply click the category, in which you’ll find ESCScan listed as Product ID Downloadable Software SD0012. -
Page 12: Troubleshooting Tips
If a hardware failure is suspected, contact support.zilog.com for assistance. However, before submitting a problem report to Zilog Customer Support, follow the instructions in this section. ZDS II Cannot See the Ethernet Smart Cable If ZDS II cannot detect the Ethernet Smart Cable, try the following workarounds: •... - Page 13 Z8 Encore!, Z8 Encore! XP, ZNEO and eZ80Acclaim! are trademarks or registered trade- marks of Zilog, Inc. All other product or service names are the property of their respective owners. UM020705-1012...
- Page 14 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: ZiLOG ZUSBOPTSC01ZACG ZENETSC0100ZACG...
