2 Installation
Install the digital TV receiver, limited by the specifications shown in the table
below.
Maximum power consumption
Size
Weight
Operating temperature
Storage temperature
On the rear, this digital TV receiver has several connectors:
• Satellite dish connectors
• Aerial connectors
• AV connectors for a TV and an AV receiver
• USB ports for removable storage devices
• An Ethernet port for internet connection
• An eSATA port for a removable hard drive
The
RS-232C
port may be used only by an engineer for installation or service.
14
55 W when in operation
1 W when in standby mode
340 mm × 60 mm × 245 mm
2 kg (without hard drive)
0–45°C, 32–113°F
−10–70°C, 14–158°F
