Cuisinart Gourmet 600S Assembly Manual

Cuisinart Gourmet 600S Assembly Manual

Hide thumbs Also See for Gourmet 600S:

Advertisement

Quick Links

Download this manual
Cuisinart
Gourmet 600S
®
READ AND SAVE MANUAL FOR FUTURE REFERENCE.
Missing or damaged parts should be claimed within 30 days of purchase.
For product inquiries, parts, warranty and troubleshooting support, please call 1-800-309-3452.
LIMITED 5-YEAR WARRANTY
Assemble your grill immediately.
www.cuisinartbbqs.com
ASSEMBLY
MANUAL
85-3078-6 (G41803) Propane
85-3079-4 (G41804) Natural Gas
Manual Revision #: 28112012 PD

Advertisement

loading
Need help?

Need help?

Do you have a question about the Gourmet 600S and is the answer not in the manual?

Questions and answers

Related Manuals for Cuisinart Gourmet 600S

Summary of Contents for Cuisinart Gourmet 600S

  • Page 1 ASSEMBLY MANUAL 85-3078-6 (G41803) Propane Cuisinart Gourmet 600S ® 85-3079-4 (G41804) Natural Gas READ AND SAVE MANUAL FOR FUTURE REFERENCE. Assemble your grill immediately. Missing or damaged parts should be claimed within 30 days of purchase. For product inquiries, parts, warranty and troubleshooting support, please call 1-800-309-3452.

  • Page 2: Hardware Pack

    HARDWARE PACK Tools Needed for Assembly No. Description Part Number Qty. 1/4"-20UNCX13 Screw 20120-13013-250 • #2 Phillips screwdriver (long and short) 1/4"-20UNCX38 Screw 20120-13038-250 • ¼” Slotted screwdriver (long and short) Φ7 Lock Washer 41400-07000-250 • Adjustable wrench Φ7 Washer 40300-07000-250 •...
  • Page 3 PARTS LIST (PROPANE) FOR 85-3078-6 (G41803) EXPLODED DIAGRAM (PROPANE) FOR 85-3078-6 (G41803) Item No. Qty. Description Part No. Item No. Qty. Description Part No. Top Lid G418-2000-01 Side Shelf Table, Left G525-0700-01 Lid Handle G412-0035-02 Side Shelf Fascia, Left G418-0600-01 Thermometer G512-0085-01 Towel Bar...
  • Page 4 PARTS LIST (NATURAL GAS) FOR 85-3079-4 (G41804) EXPLODED DIAGRAM (NATURAL GAS) FOR 85-3079-4 (G41804) Item No. Qty. Description Part No. Item No. Qty. Description Part No. Top Lid G418-2000-01 Side Shelf Table, Left G525-0700-01 Lid Handle G412-0035-02 Side Shelf Fascia, Left G418-0600-01 Thermometer G512-0085-01...

  • Page 5: You Will Need

    ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Separate the 2 different types of wheels: 2 c. Assemble the Lower Back Panel (BI) to the Locking Wheels (EE) and 2 regular Wheels (EF). Left Cart Side Panel (EA) and Right Cart Side Panel (EB). Insert the U Pin (#7) into one of the regular Wheels (EF), as shown in image B.
  • Page 6 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS THIS STEP REQUIRES 3 OR MORE a. Open the lid. Assemble the Left Side Shelf PEOPLE. DO NOT ATTEMPT ALONE. (DA and DB) to the Cart Assembly by inserting EXTREMELY HEAVY. the Side Shelf tabs into the holes on the Burner Box Asembly (A and B).
  • Page 7 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS a. Assemble the Towel Bar (DC) to the Control a. Open the lid. Assemble the Right Side Panel (CF) and Left Side Shelf Table (DA), as Shelf (DE and DF) to the Cart Assembly by shown in figure A & B. inserting the Side Shelf tabs into the holes on the Cart Assembly, as shown in figure A.
  • Page 8 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS a. Assemble the side burner control knob bezel a. Position the Side Burner (DH) through the opening in the Side Burner Drip Pan (DG). (#13) to the right side shelf fascia (DF) as shown in figures A. YOU WILL NEED: b.
  • Page 9 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS d. Attach the end of the Side Burner Electrode a. Insert the Heat Shield (CG) into the Cart Assembly, as shown in figure A. Wire (DI) to the underside of the Side Burner (DH), as shown in figure E. Ensure that the wire is pushed in firmly.
  • Page 10 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS a. Remove the Electronic Ignition Battery Cap a. Insert the Grease Tray (CH) into the opening (CD2) and the plastic nut from the Electronic in the Upper Back Panel (BG), making sure to Ignition Box (CD1). engage tracks located under the Burner Box Assembly (BA).
  • Page 11 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS a. Assemble the Door Assembly (EC), to the a. Place the Flame Tamers (BD) into the Burner bottom Shelf (ED) by inserting the fixed pin Box (BA). (bottom of door) into the hole provided as shown in Figure B. b.
  • Page 12 Manifold Assembly (CA), as shown. a. Position the Regulator hose (CB) through the hole in the Right Cart Side Panel (EB). b. Perform Leak Test. See page 6 of the Cuisinart Safety and Care Manual. ® ATTENTION: In order to complete installation of your Natural Gas BBQ a 1/2”...
  • Page 13 Visit www.cuisinartbbqs.com to complete product registration. Cuisinart Gourmet Barbecues Customer Service: ® 1-800-309-3452 Join the conversation facebook.com/cuisinartbbqs twitter.com/cuisinartbbqs Cuisinart is a registered ® trademark used under license © 2013 Trileaf Distributions Trifeuil...
