Summary of Contents for Topcon GRS-1

  • Page 3 Rev A ©Copyright Topcon Positioning Systems, Inc. April, 2009 All contents in this manual are copyrighted by Topcon. All rights reserved. The information contained herein may not be used, accessed, copied, stored, displayed, sold, modified, published, or distributed, or otherwise reproduced without express written consent from Topcon.
  • Page 4 ECO#3525...

  • Page 5: Table Of Contents

    Calculating Differential Positions ...... 1-5 Essential Components for Quality Surveying ..1-6 Conclusion ............1-7 GRS-1 Overview ............1-7 Getting Acquainted with the GRS-1 ........ 1-8 Rechargeable and Backup Batteries ......1-9 GRS-1 Front .............. 1-10 GRS-1 Back .............. 1-13 GRS-1 Ports ..............
  • Page 6 Topcon Receiver Utility (TRU) ........3-6 Surveying with the GRS-1 ......... 3-6 Surveying with the GRS-1 and an External Antenna 3-7 Surveying with the GRS-1 and a Beacon Receiver ... 3-8 Surveying with the GRS-1 and an External GPS Receiver ............3-9 Chapter 4 Using the GNSS Compass, Camera ....
  • Page 7 Resetting the Software ............. 7-3 Restoring Bluetooth Module Defaults ......7-4 Resetting the Hardware ............ 7-4 Format Reset ..............7-5 Charging/Powering Problems .......... 7-6 GRS-1 Problems .............. 7-7 Bluetooth Problems ............7-8 Obtaining Technical Support ........... 7-10 Phone ................. 7-10 E-mail ................ 7-11 Website ..............
  • Page 8 Table of Contents Appendix A Specifications ............A-1 GRS-1 Specifications ............A-2 General Details ............A-2 GPS Details ..............A-6 Bluetooth Details ............A-7 Connector Specifications ..........A-8 Serial Connector ............A-8 USB Connector ............A-9 Appendix B Safety Warnings ........... B-1 General Warnings ............

  • Page 9: Terms And Conditions

    Preface Preface Thank you for purchasing this Topcon product. The materials available in this Manual (the “Manual”) have been prepared by Topcon Positioning Systems, Inc. (“TPS”) for owners of Topcon products, and are designed to assist owners with the use of the receiver and its use is subject to these terms and conditions (the “Terms and Conditions”).
  • Page 10 Preface GRS-1, MG-A8, PG-A1, PG-A5, RH-1, BH-1, BR- TRADEMARKS 1, Topcon Receiver Utility (TRU), TopSURV, TopGIS, Field Tools for ArcPad, Pocket-3D, Pocket Layout, Topcon and Topcon Positioning Systems are trademarks or registered trademarks of TPS. Microsoft, Windows Mobile, and the Windows logo are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries.
  • Page 11 Terms and Conditions and Conditions in this Manual and an agreement to abide by these Terms and Conditions. The user is granted a personal, non-exclusive, non-transferable license to use such Software under the terms stated herein and in any case only with a single receiver or single computer. You may not assign or transfer the Software or this license without the express written consent of TPS.

  • Page 12: Manual Conventions

    Supplementary information that can have an affect on system operation, system performance, NOTICE measurements, or personal safety. Notification that an action has the potential to adversely affect system operation, system CAUTION performance, data integrity, or personal health. GRS-1 Operator’s Manual viii...
  • Page 13 Manual Conventions Notification that an action will result in system damage, loss of data, loss of warranty, or personal WARNING injury. Under no circumstances should this action be DANGER performed. P/N 7010-0926...
  • Page 14 Preface Notes: GRS-1 Operator’s Manual...

  • Page 15: Chapter 1 Introduction

    The GRS-1 can received and process both L1 and L2 signals, improving the accuracy of your survey points and positions. The GPS+ component of GRS-1 receivers means you can access both the...

  • Page 16: Principles Of Operation

    The casing is durable and built for rugged use. As a field controller, the GRS-1 can run a full suite of field software for working with total stations and RTK GPS systems.

  • Page 17: Gnss Overview

    Principles of Operation channels can be used to track any one of the GPS or GLONASS signals. The number of channels available allows the receiver to track all visible GPS and Glonass satellites at any time and location. An internal GPS+GLONASS L1 antenna equipped with a low noise amplifier (LNA) and the receiver’s radio frequency (RF) device are connected with a coaxial cable.

  • Page 18: Calculating Absolute Positions

    To provide fault tolerance using only GPS or only GLONASS, the receiver must lock onto a fifth satellite. Six satellites will provide fault tolerance in mixed scenarios. GRS-1 Operator’s Manual...

  • Page 19: Calculating Differential Positions

    Principles of Operation Calculating Differential Positions DGPS, or Differential GPS, typically uses the measurements from two or more remote receivers to calculate the difference (corrections) between measurements, thus providing more accurate position solutions. With DGPS, one receiver is placed at a known, surveyed location and is referred to as the reference receiver or base station.

  • Page 20: Essential Components For Quality Surveying

    – Five or more visible satellites for only GPS or only GLONASS; six or more satellites for mixed scenarios. – Wide Area Augmentation Systems (WAAS, EGNOS, etc.) creates and transmit, along with DGPS corrections, data integrity information (for example, satellite health warnings). – Current ephemerides and almanacs. GRS-1 Operator’s Manual...

  • Page 21: Conclusion

    Topcon sensors or wireless networks. The casing is durable and built for rugged use. As a field controller, the GRS-1 can run a full suite of field software for working with total stations and RTK GPS systems.

  • Page 22: Getting Acquainted With The Grs-1

    Getting Acquainted with the GRS-1 The GRS-1 is an integrated field controller and 72-channel GPS receiver with an internal electronic compass and digital camera. USB and serial ports, along with Bluetooth® and Wireless LAN provide...

  • Page 23: Rechargeable And Backup Batteries

    • Hand strap, neck strap, and soft case • Software CD and operator’s manual CD • One-year warranty card For more details on accessories and options available for the GRS-1, contact your local Topcon dealer. Rechargeable and Backup Batteries The GRS-1 comes equipped with a rechargeable battery (Figure 1-2) for powering the unit.

  • Page 24: Grs-1 Front

    Battery Figure 1-2. GRS-1 Battery GRS-1 Front The front of the GRS-1 (Figure 1-3 on page 1-12) is the primary interface with its components and installed software. • The internal GPS antenna detects signals from GPS+ satellites and sends them to the GPS receiver board for processing.
  • Page 25 Getting Acquainted with the GRS-1 – Blue blink: Bluetooth is on. – Red blink: wireless LAN is on. – Violet blink: notification from Windows. – No light: the module is off. • The charging LED indicates the level of charge in the battery: –...
  • Page 26 Introduction Internal Antenna Display and Touch Panel Speaker Escape Key Enter Key Cell Phone LED Bluetooth/WLAN LED Recharging LED Microphone Power Key Connector Cap Figure 1-3. GRS-1 Front GRS-1 Operator’s Manual 1-12...

  • Page 27: Grs-1 Back

    Getting Acquainted with the GRS-1 GRS-1 Back The back of the GRS-1 holds the stylus used for tapping on the display screen. An elastic strap provides comfortable security while using the GRS-1. A cover accesses the rechargeable battery and backup battery.

  • Page 28: Grs-1 Ports

    • Serial – used for communication between the internal GPS module (port A of the module) and an external device. • Power – used to connect the GRS-1 to an external power source. This port can also be used to charge the batteries.

  • Page 29: Integrated Camera

    Getting Acquainted with the GRS-1 Located above the card slot is the software reset button for restarting the operating system if the software is not responding. Software Reset Button SD Card Slot Figure 1-6. SD Card Slot Integrated Camera The integrated 2 megapixel camera can be used for taking pictures.

  • Page 30: External Gps Antenna Connector

    External GPS Antenna Connector The external GPS antenna connector allows an optional external antenna to be connected to the controller for RTK and post-process survey applications. External GPS Antenna Connector Figure 1-8. GRS-1 External GPS Antenna Connector GRS-1 Operator’s Manual 1-16...

  • Page 31: System Cables

    System Cables System Cables The GRS-1 package includes standard communication and power cables for communicating with the GRS-1 and providing a power source. Table 1-1 lists the cables included in the standard GRS-1 package. Table 1-1. GRS-1 Package Cables Cable Description...

  • Page 32: Optional Accessories

    (TRU)” on page 3-6 and “Using the GNSS Compass, Camera” on page 4-1. • Topcon Communication Manager - TPS Connection Manager is Topcon’s tool that comes on the GRS-1 field controller to setup the internal GSM modem for new network connections in Windows Mobile 6.1.
  • Page 33 Optional Accessories Table 1-2. GRS-1 Optional Accessories (Continued) Accessory Illustration External Dual-Frequency GNSS Antenna for Static and RTK, and Cable Connecting an external PG-A1 GNSS antenna increases the range of the GRS-1. External Dual-Frequency GNSS Antenna for Static and RTK, and Cable...
  • Page 34 Introduction Table 1-2. GRS-1 Optional Accessories (Continued) Accessory Illustration Battery Holder Connecting the BH-1 battery holder enables long life operation of the GRS-1. Serial Cable Connects the GRS-1 to an external device (controller or computer) for data transfer and receiver configuration.
  • Page 35 Optional Accessories Table 1-2. GRS-1 Optional Accessories (Continued) Accessory Illustration Serial Cable for Modem Connects the GRS-1 to an external modem. p/n 14-008104-01LF Serial Cable for External Receiver Connects the GRS-1 to a Topcon GPS+ receiver. p/n 14-008103-01LF Battery Charger Charges the BT-66Q battery.

  • Page 36: Option Authorization File (Oaf)

    • Make sure the GRS-1 is functioning correctly with normal performance before using it. • Always make sure the GRS-1 is dry before putting it in the soft case. • Do not leave the GRS-1 under strong sunlight for a long time. It may cause the device to malfunction.

  • Page 37: Storing The Grs-1

    • Use a clean cloth moistened with neutral detergent or water. • Never use an abrasive cleaner, ether, thinner benzene, or other solvents. • Always make sure the GRS-1 is completely dry before storing it. Dry any moisture with a soft, clean cloth. P/N 7010-0926...
  • Page 38 Introduction Notes: GRS-1 Operator’s Manual 1-24...

  • Page 39: Preparing The Grs-1 For Use

    Preparing the GRS-1 for Use Before using the GRS-1, make sure the battery is fully charged. If you are using other survey software, such as TopSURV, install it in the office. Insert an optional SD card before beginning to survey.

  • Page 40: Powering The Grs-1

    Powering the GRS-1 The GRS-1 uses a BT-66Q battery for it’s primary power source. When using the GRS-1 for static surveys, the battery will last up to four hours. The battery will last up to fifty hours during continuous standby use (that is, no GPS usage, the display LED is off, and the touch screen is not being used).

  • Page 41: Charging The Battery

    Figure 2-2. Installing the Primary Battery Charging the Battery The AC/DC converter AD-11 provides power to the GRS-1 and charges the primary battery. Note that using the GRS-1 while charging increases the charge time. The battery will be fully charged in approximately seven hours.
  • Page 42 Figure 2-3. Charging the Battery in the GRS-1 (Figure 2-4): To charge the battery using the optional charger 1. Remove the battery from the GRS-1 (see “Installing the Battery” on page 2-2 for details), and insert it into the charger. GRS-1 Operator’s Manual...

  • Page 43: Charging And Battery Storage Notes

    50°F to 104°F (10°C to 40°C). Charging at a high temperature increases the time it takes to charge the battery. • Always check the battery charge before using the GRS-1. The battery will discharge during storage. • Charge a stored battery every seven days. Allowing a battery to become discharged can reduce the overall performance of the battery and charge efficiency.

  • Page 44: Replacing The Backup Battery

    Preparing the GRS-1 for Use Replacing the Backup Battery The backup battery ensures GPS and clock settings are saved when the primary battery and internal rechargeable battery are depleted. Under normal conditions, the backup battery lasts two to three years.

  • Page 45: Starting The Grs-1

    Figure 2-5. Replacing the Coin Battery Starting the GRS-1 To start the GRS-1, briefly press the power button. The touch screen lights up, and the GRS-1 splash screen displays while the system loads, and then the Microsoft Windows Mobile desktop displays.
  • Page 46 Preparing the GRS-1 for Use 2. Press Settings System tab Screen Figure 2-7. Stylus Properties 3. Press Align Screen. 4. Press and hold the stylus on the center (+) of the cross lines (targets) as it moves about the screen.

  • Page 47: Setting The Power Management

    LED is off, and the touch screen is not being used) or Suspend (power off) mode when the unit is left turned on. To set the Standby or Suspend mode: 1. On the main screen of the GRS-1, press the Start icon. 2. Press Settings System tab Power.

  • Page 48: Installing An Optional Sd Card

    SD (secure digital) cards can be purchased at a local computer supply store. When inserted into the GRS-1, an SD card provides additional data storage, as well as data transfer. The GRS-1 supports SD cards with up to 2 GB capacity. This device does not currently support SDHC cards.
  • Page 49 Installing an Optional SD Card Some SD cards may not be used with the GRS-1. NOTE 1. Open the SD card slot door. 2. Gently insert an SD card into the slot as shown in Figure 2-10. 3. Close the SD card slot door.
  • Page 50 Preparing the GRS-1 for Use Notes: GRS-1 Operator’s Manual 2-12...

  • Page 51: Using The Grs-1

    Connecting the GRS-1 with Other Devices Using the GRS-1 The GRS-1 can be used as a stand-alone hand held L1 device for mapping, or with the external PG-A1 antenna as a dual frequency RTK rover. When installing software or performing file transfers, the USB cable or Bluetooth module connects the GRS-1 to a computer for in-office processing.

  • Page 52: Connecting The Grs-1 And A Computer

    “Installing Software” on page 2-9 for details. For a Bluetooth connection, see “Connecting the GRS-1 and a Bluetooth Device” on page 3-4 for NOTE details. 2. Connect the GRS-1 and the computer using the interface cable F- 25 (USB) or Bluetooth wireless technology. GRS-1 Operator’s Manual...

  • Page 53: About Activesync And Windows Mobile Device Center

    3. When ActiveSync on the computer prompts to set up a partnership, select No, and click Next. 4. Once the connection has been established, click the Explorer icon on the ActiveSync screen to view data on the GRS-1 on- board memory. About ActiveSync and Windows Mobile Device...

  • Page 54: Connecting The Grs-1 And A Bluetooth Device

    Connecting the GRS-1 and a Bluetooth Device The GRS-1 is equipped with Bluetooth capability, so you can transmit data wirelessly between equipment. The Bluetooth Devices screen displays the List of Favorite Devices, so you can quickly and easily connect with a saved device.

  • Page 55: Pairing Bluetooth Devices

    Connecting the GRS-1 with Other Devices Figure 3-4. Bluetooth Devices - Discovery 3. After the devices are found, you can: • Select a device, and tap Next. You can choose more than one device. • A confirmation message appears when the devices are successfully added to the List of Favorite Devices.

  • Page 56: Topcon Receiver Utility (Tru)

    Surveying with the GRS-1 Using Topcon Receiver Utility (TRU) The GRS-1 can be used in many surveying situations. From GIS surveying to data collection on a construction jobsite, the GRS-1 provides an integrated solution for all your needs. Simple surveying (data collection) with the GRS-1 can be handled with the on-board TRU software.

  • Page 57: Surveying With The Grs-1 And An External Antenna

    Surveying with the GRS-1 Using Topcon Receiver Utility (TRU) 5. Open Receiver Settings Tracking. 6. Check the antenna, and elevation mask, and PDOP mask settings. For typical surveys, the antenna should be set to Internal. 7. Press OK. 8. Open Status.

  • Page 58: Surveying With The Grs-1 And A Beacon Receiver

    Chapter 2. 2. Setup the Beacon receiver according to its documentation. 3. Using BTManager, connect the GRS-1 and GPS receiver as described in “Connecting the GRS-1 and a Bluetooth Device” on page 3-4. In BTManager, the BR-1 would be considered an “Unclassified”...

  • Page 59: Surveying With The Grs-1 And An External Gps Receiver

    5. Begin logging data using the data collection software. 6. When you reach a location to record a point, pause and press the Ent (Enter) button on the GRS-1. Wait until the point is recorded before moving to the next location.
  • Page 60 5. Via the data collection software, begin logging data. 6. When you reach a location to record a point, pause and press the Ent (Enter) button on the GRS-1. Wait until the point is recorded before moving to the next location.

  • Page 61: Using The Gnss Compass, Camera

    Topcon Receiver Utility for GRS-1 is a simple utility that manages the compass and receiver board settings in the GRS-1. When first opening Topcon Receiver Utility or after a reset, all settings will be at the default selections. Typical GNSS settings only need to be configured once.
  • Page 62 Using the GNSS Compass, Camera Table 4-1. Topcon Receiver Utility Screens (Continued) Description Screen Receiver Settings The receiver settings (tracking options) screen selects the antenna (internal or external), elevation mask, and PDOP mask. Tools The tools screen allows you to clear the NVRAM and reset the receiver.

  • Page 63: Using The Compass

    Press Start TRU Device GMS/GRS Tools. The Compass tab displays the current direction, roll, and pitch of the GRS-1. This tab also calibrates the compass. • Pointer – North (red portion of pointer) and South (black portion of pointer) directions.
  • Page 64 • A magnet, motor, and electric products, including digital camera, personal computer, data collector, etc. • The surrounding area of a plant that induces a magnetic field like a high-voltage line and substation. • The surrounding area of a metal (iron, nickel, and cobalt) mine. GRS-1 Operator’s Manual...

  • Page 65: Calibrating The Compass

    Topcon Receiver Utility • A wrist watch. (Keep a distance of 15 cm or more between the GRS-1 and a wrist watch.) Because azimuth accuracy worsens near ferrous materials as described above, correct the azimuth by methods other than magnetism. For example, you can: •...
  • Page 66 2. Press Calibrate, and then start the calibration as shown in Figure 4-3. Figure 4-3. Begin Compass Calibration 3. Hold the GRS-1 horizontally in your hand and turn to any direction. 4. Rotate the device 360 degrees in a horizontal direction for five or more seconds.
  • Page 67 Topcon Receiver Utility 8. Press OK. If calibration is successful, the Calibration completed successfully window appears, and the calibration value is saved. Press OK. Figure 4-5. Calibration Successful If you did receive an error message, then you may have rotated the device too quickly or in the wrong direction.

  • Page 68: Recalibrating The Compass

    Recalibration is needed in the following cases: • The survey location changes frequently. • The GRS-1 receives a shock, such as being dropped. • The temperature changes 10 degrees or more. • The device is transported by car or airplane.
  • Page 69 Figure 4-7. Take a picture 3. Aim the camera at the desired object(s), using the finder/review pane to frame the image. 4. Press the ENT key on the GRS-1 to take the picture. 5. Press Thumbnails. 6. Check to save the picture.
  • Page 70 Figure 4-10. Do not use the camera with the camera dial set halfway between the macro and long distance mode NOTICE settings. GRS-1 Operator’s Manual 4-10...
  • Page 71 Topcon Receiver Utility Long Distance Mode (90 cm or more distance) Macro Mode (Approx. 5-10 cm Distance) Figure 4-10. Camera Dial Modes P/N 7010-0926 4-11...
  • Page 72 Using the GNSS Compass, Camera Notes: GRS-1 Operator’s Manual 4-12...

  • Page 73: Using The Bluetooth Manager

    Chapter 5 Using the Bluetooth Manager The BTManager utility controls the GRS-1 Bluetooth module. Getting Started To start BTManager: 1. Turn on the GRS-1. 2. Press the Bluetooth icon in the system tray, and select Bluetooth Manager from the pop-up menu.

  • Page 74: Getting Acquainted

    Wizard searches for those devices when you tap Next. Device List This screen displays all discovered devices of a selected type. From this list, you can choose a device to add to your List of Favorite Devices by tapping Next. GRS-1 Operator’s Manual...
  • Page 75 My Bluetooth Device This screen displays the internal GRS-1 Bluetooth module information. On this screen, you can set your preferences and choose how to connect with other devices.
  • Page 76 Table 5-1. BTManager Screens (Continued) Description Screen Pairing This screen displays when the GRS-1 is in pairing mode, and it accepts a pairing request initiated by a remote device. Bluetooth Devices This screen displays the List of Favorite Devices. If you do not see...

  • Page 77: Working With Bluetooth Manager

    BTManager. Working with Bluetooth Manager Before the GRS-1 can pair with another Bluetooth-enabled device, it must discover which devices are available within your coverage area. You can use the Device Discovery wizard to search for any Bluetooth-enabled device within range or a particular type of device, and then save the device(s) to your Bluetooth Devices folder for future connections.

  • Page 78: Discovering Devices

    Using the Bluetooth Manager Figure 5-2. List of Favorite Devices Discovering Devices To discover other Bluetooth-enabled devices within your coverage area. 1. Tap Tools Device Discovery. The Discovery Wizard appears (Figure 5-3). Figure 5-3. Discovery Wizard GRS-1 Operator’s Manual...
  • Page 79 Working with Bluetooth Manager 2. Tap Next to display a list of device types. Figure 5-4. Device Categories 3. Choose a type of device to discover, and tap Next. The Discovery Wizard searches for Bluetooth-enabled devices in your coverage area and displays the icons of the devices it detects on the Device List.

  • Page 80: Adding To The List Of Favorite Devices

    To add a device from the Device List to the List of Favorite Devices: 1. Select a device, and tap Next. You can choose more than one device. Figure 5-5. Select Device(s) A confirmation message appears when the devices are successfully added to the List of Favorite Devices. GRS-1 Operator’s Manual...
  • Page 81 Working with Bluetooth Manager 2. Tap Finish to exit the Wizard and display the List of Favorite Devices. Figure 5-6. Devices Added To save time, you can save Bluetooth-enabled devices on the List of Favorite Devices, so you do not have to rediscover it. You can view devices by icon and name or by name and address.

  • Page 82: Viewing Device Properties

    To view the properties of a device, select the device in the List of Favorite Devices (Figure 5-7 on page 5-9), and tap Device Properties. Figure 5-9. Bluetooth Device Properties The Bluetooth Device Properties screen displays major and minor class identifiers, the name, and address of the selected device. GRS-1 Operator’s Manual 5-10...

  • Page 83: Deleting A Device From The List

    Setting Device Preferences The My Bluetooth Device screen (Figure 5-11 on page 5-12) displays information about the internal GRS-1 Bluetooth module. The preferences you set on this screen determine how your GRS-1 pairs with and connects to remote devices. P/N 7010-0926...
  • Page 84 Figure 5-11. My Bluetooth Device My Bluetooth Device always displays the following information: • Class (major and minor) • Name (Other devices use this name to identify the GRS-1.) • Address This screen also allows you to enable the following accessibility options: •...

  • Page 85: Pairing Bluetooth Devices

    Pairing Bluetooth Devices The Pairing Mode allows a remote Bluetooth-enabled device to initiate a request to pair with the GRS-1. If the Pairing Mode option is activated, then the GRS-1 switches to Pairing Mode for two minutes. During this two-minute period, any remote device can attempt to pair with it.
  • Page 86 Using the Bluetooth Manager To activate Pairing Mode, tap Device Pair. Figure 5-12. Device Menu - Pairing Enable The Pairing screen appears, displaying how much time is left to pair with another device. Figure 5-13. Pairing Mode GRS-1 Operator’s Manual 5-14...
  • Page 87 Once the two minutes expires, a message appears stating if the pairing succeeded or failed. Figure 5-14. Pairing Confirmation For information about connecting Bluetooth Devices, see “Connecting the GRS-1 and a Bluetooth Device” on page 3-4. For information about troubleshooting Bluetooth error messages, see “Bluetooth Problems” on page 7-8. P/N 7010-0926...
  • Page 88 Using the Bluetooth Manager Notes: GRS-1 Operator’s Manual 5-16...

  • Page 89: Tps Connection Manager

    Chapter 6 TPS Connection Manager TPS Connection Manager is Topcon’s tool that comes on GRS-1 field controller to setup the internal GSM modem for new network connections in Windows Mobile 6.1. The tool includes the following functionality: • Power on the modem and dial based on settings.

  • Page 90: Main Menu

    • Resume cellular power – if this Resume function for the internal GSM is ON (checked with a tick), the GSM power state is automatically restored when the GRS-1 is turned on. • Data connection – sets up network connections to the best available for “My ISP”.

  • Page 91: Create New Connection

    Create New Connection Create New Connection When selected, the Create new connection entry option will open the dialog to enter settings for a new network connection. Create Connection Entry Figure 6-3. Create New Connection Entry • Connection Name – the new connection name. •...

  • Page 92: Cellular Power On

    Note that the Data Connection option becomes available. • Resume cellular power – check mark this option to have the GSM power turned on after a soft reset or switching the GRS-1 off. Data Connection This option is used for dialing the cell phone to reach the Internet.
  • Page 93 Data Connection Data Connection Figure 6-6. My Internet Service Provider Connection You can check that the connection is established if you tap the status icon on the top of the screen. Tapping this arrows status icon brings up a screen to view network status. To check or modify the settings of the created network connection, you can use standard Windows Mobile interface: 1.
  • Page 94 Advanced tab and select “My ISP” as an active network. Figure 6-9. Settings - My ISP You can also open the Internet Explorer on the Windows Mobile to check on the Internet availability (Figure 6-10 on page 6-7). GRS-1 Operator’s Manual...

  • Page 95: Gps Receiver Power

    GPS Receiver Power Figure 6-10. Internet Explorer GPS Receiver Power Check mark the GPS Receiver Power option to turn on the GPS receiver in the GRS-1 system. Receiver Figure 6-11. GPS Receiver Power P/N 7010-0926...

  • Page 96: About The Tool

    TPS Connection Manager About the Tool Select the About option from the main menu to view information about the TPS Connection Manager version. Figure 6-12. About TPS Connection Manager GRS-1 Operator’s Manual...

  • Page 97: Chapter 7 Troubleshooting

    • Check all power sources for drained batteries or incorrectly connected batteries/cables. • Check that the most current software is downloaded onto the GRS-1, and the most current firmware is loaded into the receiver. Check the TPS website (www.topconpositioning.com) for the latest updates.

  • Page 98: Troubleshooting Quick List

    If “Installed software and other data has been erased” see page 7-8. For Bluetooth problems: If “The GRS-1 is no longer connected via Bluetooth” see page 7- If “You cannot connect to another Bluetooth-enabled device” see page 7-8. GRS-1 Operator’s Manual...

  • Page 99: Resetting The Software

    Resetting the Software Resetting the Software Only perform a software reset in the following instances: • To quit all active applications. • After installing new applications. • When there is no response after pressing a key or tapping on the screen.

  • Page 100: Restoring Bluetooth Module Defaults

    For the Bluetooth module, tap Reset on the Accessibility tab in BTManager. Resetting the Hardware If the GRS-1 does not operate after a software reset or the GRS-1 has become completely unresponsive, then perform a hardware reset. A hardware reset reverts all settings to defaults and erases all applications and data stored in RAM.

  • Page 101: Format Reset

    Completely draining the battery performs the same function as a hardware reset. Format Reset If the GRS-1 does not operate properly after a hardware reset perform a format reset. When the format reset is performed, the registry information registered by applications to the OS are reset. Data stored by the user is saved;...

  • Page 102: Charging/Powering Problems

    The GRS-1 does not power up The batteries may be discharged. • Connect the GRS-1 to a grounded outlet to charge the battery. See “Charging the Battery” on page 2-3. • Insert a fully charged battery. See “Installing the Battery” on page 2-2.

  • Page 103: Grs-1 Problems

    Bluetooth module. • White – a connection between BTManager and the Bluetooth module has been established. • Green – via a serial port, a connection between the GRS-1 and an external Bluetooth-enabled device has been established. 2. If needed, select the device to connect to, and tap Connect.

  • Page 104: Bluetooth Problems

    Troubleshooting Installed software and other data has been erased The battery in the GRS-1 has been completely drained or a hardware reset has been performed. Reinstall all software. See “Installing Software” on page 2-9 and the software manual for details.
  • Page 105 1. The PIN you entered on the My Bluetooth Device page does not match the PIN you entered on the remote device. Make sure the GRS-1 and the remote device use the same PIN. 2. The Connectable setting was not selected on the remote device or the device was switched off.

  • Page 106: Obtaining Technical Support

    Close the application or release the port. The COM2 serial port is reserved for the Bluetooth Manager. Port B of the GRS-1 GPS receiver, through which the Bluetooth Manager connects to the Bluetooth module, is not in command mode. Change Port B input mode back to command mode or clear the GRS-1 NVRAM.

  • Page 107: E-Mail

    1. The device’s model and configuration settings. In TRU (Topcon Receiver Utility), click File Receiver Info and click Save to file. Enter a name for the file and save it to your computer. Attach this file to the email.

  • Page 108: Website

    Website The Topcon Positioning Systems website provides current information about Topcon’s line of products. The support area of the website provides access to frequently asked questions, configuration procedures, manuals, e-mail support, etc.

  • Page 109: Updating The Operating System

    WARNING programs. Prior to updating the OS of the GRS-1, back up all registration codes, user data, TopSURV jobs, or any other data that is stored on the internal memory. Anything that is not part of the original OS will be erased and will not be recoverable.

  • Page 110: Os Installation File

    Version up (operating system update) screen. 1. Disconnect all cables and remove the SD card (if inserted). 2. Power on the GRS-1, and remove the battery while it is powered 3. When the GRS-1 is off, simultaneously hold the ESC and ENT buttons while pushing the software reset button with the stylus pen for two or more seconds (Figure 8-1 on page 8-3).
  • Page 111 Format Reset Push the Software Reset Button While Pressing the Ent and Esc Buttons Figure 8-1. format Reset 5. Simultaneously hold the ESC, Power, and Reset buttons until a black screen appears with text at the bottom that reads DIAG start, then release the buttons.

  • Page 112: Installing The Os

    1. Insert the SD card that contains the OS installation file. 2. Attach the external power supply. If you lose power during the OS update, the GRS-1 could become dysfunctional. 3. With Windows Mobile selected, press the ENT button. 4. Once the screen turns green to signify that the update is complete, press the ENT button as instructed.

  • Page 113: Troubleshooting

    Troubleshooting 5. Finally, press and hold ESC and POWER until the GRS-1 splash screen appears. This takes about 10 seconds. 6. Release the buttons and wait for the screen calibration process to display. It takes about 30 seconds for the device to reboot.
  • Page 114 Updating the Operating System Notes: GRS-1 Operator’s Manual...

  • Page 115: Appendix A Specifications

    Appendix A Specifications The GRS-1 is a 72-channel GPS/GLONASS Dual Frequency receiver integrated with an internal computer and Windows Mobile operating system with touch screen, a digital camera, a Bluetooth® wireless technology module, a Wireless LAN module, an electronic compass, and an SD card slot.

  • Page 116: Grs-1 Specifications

    Specifications GRS-1 Specifications The following sections provide specifications for the GRS-1 and its internal components. General Details Table A-1 table lists the receiver’s general specifications. Table A-1. GRS-1 General Specifications Physical Enclosure Polycarbonate Color Topcon Yellow and Topcon Grey Dimensions...
  • Page 117 GRS-1 Specifications Table A-1. GRS-1 General Specifications (Continued) Waterproof IP66 at closing all connector caps. IPX4 (Weatherproof) at connecting external antenna cable. Power Internal battery Li-ion, 2500 mAh 7.4V; replaceable (BT-66Q) Operating time No less than 3.5 hours with GPS and cell phone use...
  • Page 118 Specifications Table A-1. GRS-1 General Specifications (Continued) Wireless LAN Transmission specifications: IEEE802.11b/g Transmission method: Direct sequence spread spectrum (DS-SS) communication Access method: Infrastructure mode, Ad hoc mode Security: WEP(128/64bit), TKIP Frequency range: 2.4GHz (2,412~2,462MHz) (1~11ch) Transmission output: 30mW Transmission distance: 10m (In good visibility) Version 1.1 (mini B)
  • Page 119 GRS-1 Specifications Table A-1. GRS-1 General Specifications (Continued) Sensor element 1/4 inches color C-MOS sensor Angle of View 53°x 40° F number Focus Range 90 cm to infinity (normal mode), 5 to 10 cm (macro mode) Zoom Digital zoom x2, x4, x8...

  • Page 120: Gps Details

    Specifications Table A-1. GRS-1 General Specifications (Continued) Serial port 1 port for communication with the GMS+ board (port A); small connector USB port 1 port for Windows Mobile; type Mini-B ver. 1.1; connect to PC using ActiveSync or Device Center External power port 1 port;...

  • Page 121: Bluetooth Details

    GRS-1 Specifications Table A-2. GPS Board Specifications (Continued) Kinematic, RTK For L1/L1 +L2 – H: 10mm + 1.0ppm (x baseline length) V: 15mm + 1.0ppm (x baseline length) DGPS Post processing/RTCM: typically less than 0.5m (RMS) Other (GPS) Real time data RTCM 2.3, 3.0;...

  • Page 122: Connector Specifications

    Specifications Connector Specifications The GRS-1 has one antenna connector for radio transmission/ reception and three port connectors for power and data upload/ download. Serial Connector The serial connector (Figure A-1) is a sealed receptacle, 5 pin, port. This connector is configured as port A of the internal GPS receiver.

  • Page 123: Usb Connector

    Connector Specifications USB Connector Rimmed in yellow, the USB connector is a sealed receptacle, 4 pin TPS cable connector (Figure A-2). Figure A-2. USB Connector for GGD Options Table A-5 gives the USB connector specifications. Table A-5. USB Specifications Number Signal Name Details Bus power input...
  • Page 124 Specifications Notes: GRS-1 Operator’s Manual A-10...

  • Page 125: Appendix B Safety Warnings

    Appendix B Safety Warnings General Warnings TPS receivers are designed for survey and survey related uses (that is, surveying coordinates, distances, angles and depths, and recording such WARNING measurements). This product should never be used: • Without the user thoroughly understanding this manual.

  • Page 126: Battery Pack Warnings

    • Do not use a wet battery or charger. Do not allow skin or clothing to come into contact with acid from the batteries. If this does occur, then CAUTION wash off with water and seek medical advice. GRS-1 Operator’s Manual...

  • Page 127: Usage Warnings

    Usage Warnings Do not touch the charger, AC-DC converter or a heated part of the device for a long period while CAUTION charging the battery. There is a risk of low- temperature burn. Usage Warnings If this product has been dropped, altered, transported or shipped without proper packaging, or CAUTION otherwise treated without care, erroneous...
  • Page 128 Safety Warnings Notes: GRS-1 Operator’s Manual...

  • Page 129: Regulatory Information

    Appendix C Regulatory Information The following sections provide information on this product’s compliance with government regulations for use. FCC Compliance The Federal Communication Commission Radio Frequency Interference Statement includes the following paragraph: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules.

  • Page 130: Federal Communication Commission Declaration Of Conformity (Doc) Statement

    Regulatory Information Federal Communication Commission Declaration of Conformity (DoC) Statement Model No: GRS-1 Trade Name Topcon Responsible Party Topcon Positioning Systems, Inc. Address 7400 National Drive, Livermore, CA 94550 Telephone No 925-245-8300 Industry Canada (IC) Regulatory Information This device complies with RSS 210 of Industry Canada.

  • Page 131: Fcc/Ic Rf Radiation Exposure Statement For Bluetooth And 802.11B/G

    FCC Compliance FCC/IC RF Radiation Exposure Statement For Bluetooth and 802.11b/g To comply with FCC/IC RF exposure compliance requirements, this device must not be co-located or operating in conjunction with any other antenna or transmitter. For mobile operation, To comply with FCC/IC RF exposure compliance requirements, a separation distance of at least 20cm must be maintained between the antenna of this device and all persons.

  • Page 132: European Community Declaration Of

    (2) this device must accept any interference, including interference that may cause undesired operation of the device. 2. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent GRS-1 Operator’s Manual...

  • Page 133: Declaration Of Conformity With Regard To The R&Tte Directive 1999/5/Ec

    English declares that this (GRS) is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Por medio de la presente (Topcon Positioning Español Systems, Inc.) declara que el (GRS) cumple con [Spanish] los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE.
  • Page 134 (GRS) è conforme ai requisiti [Italian] essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE. Ar šo (Topcon Positioning Systems, Inc.) deklar , Latviski ka (GRS) atbilst Direkt vas 1999/5/EK b tiskaj m [Latvian] pras b m un citiem ar to saist tajiem noteikumiem.
  • Page 135 Português este (GRS) está conforme com os requisitos [Portuguese] essenciais e outras disposições da Directiva 1999/5/CE. (Topcon Positioning Systems, Inc.) izjavlja, da je Slovensko ta (GRS) v skladu z bistvenimi zahtevami in [Slovenian] ostalimi relevantnimi dolo ili direktive 1999/5/ES. (Topcon Positioning Systems, Inc.) týmto Slovensky vyhlasuje, e (GRS) sp a základné...

  • Page 136: Community Of Europe Compliance

    The product described in this manual is in compliance with the R&TTE and EMC directives from the European Community. Perchlorate Material – Special Handling May Apply NOTICE For more information, see www.dtsc.ca.gov/ hazardouswaste/perchlorate This applies to California, USA only. GRS-1 Operator’s Manual...

  • Page 137: Appendix D Warranty Terms

    1. The warranty against defects in a Topcon battery, charger, or cable is 90 days. P/N 7010-0926...
  • Page 138 Warranty Terms Notes: GRS-1 Operator’s Manual...
  • Page 139 Notes: Notes...
  • Page 140 Notes: Notes...
  • Page 142 Topcon Positioning Systems, Inc. 7400 National Drive, Livermore, CA 94550 800∙443∙4567 www.topconpositioning.com GRS-1 Operator’s Manual P/N: 7010-0926 Rev A 04/09 ©2009 Topcon Corporation All rights reserved. No unauthorized duplication.
