INSTRUCTION MANUAL
AUTO TRACKING TOTAL STATION
GTS-900A SERIES
AUTO TRACKING PULSE TOTAL STATION
GPT-9000A SERIES
SERVO PULSE TOTAL STATION
GPT-9000M SERIES
Rev.8
Advertisement
Related Manuals for Topcon GTS-900A Series
Summary of Contents for Topcon GTS-900A Series
- Page 1 Specializing in quality used surveying and optical equipment Hodgens Equipment Sales www.hodgens.net equip@hodgens.net 800-463-4367 INSTRUCTION MANUAL AUTO TRACKING TOTAL STATION GTS-900A SERIES AUTO TRACKING PULSE TOTAL STATION GPT-9000A SERIES SERVO PULSE TOTAL STATION GPT-9000M SERIES Rev.8...
- Page 2 FOREWORD Thank you for purchasing the TOPCON Auto Tracking Total Station GTS-900A/ GPT-9000A series, Servo Total Station GPT-9000M series. For the best performance of the instruments, please carefully read these instructions and keep them in a convenient location for future reference.
- Page 3 Connect the battery as soon as possible or execute RAM back-up. No responsibility TOPCON Corporation has no responsibility for loss of data stored in the memory in case unexpected accidents. Battery cover Completely close the battery cover before using the GTS-900A/GPT-9000A/GPT-9000M.If the battery cover...
- Page 4 • There is a risk of fire, electric shock or physical harm if you attempt to disassemble or repair the instrument yourself. This is only to be carried out by TOPCON or an authorized dealer, only! • Cause eye injury or blindness.
- Page 5 CAUTION • Do not connect or disconnect equipment with wet hands, you are at risk of electric shocks if you • Use of controls or adjustment or performance of procedures other than those specified herein may result in hazardous radiation exposure. •...
- Page 6 The laser beam belongs not very dangerous type but we request you to keep and understand “Safety standard for users” as mentioned in the manual instruction. In case of any failure, do not disassemble the instrument. Contact TOPCON or your TOPCON dealer. Laser class of each mode is as follows.
- Page 7 Symbol Mark while the Laser is Emitting. These symbol marks will come on while the laser is working. Auto-collimating, Auto-tracking, Waiting, Searching (Class 1 (CLASS I) Laser) Optical communication (Class 2 (CLASS II) Laser) Auto-collimating Auto-tracking Waiting Searching When distance is being measured (Class 1 (CLASS I) Laser) When the Laser Pointer light is ON (Class 2 (CLASS II) Laser)
- Page 8 Contents FOREWORD............1 General Handling Precautions .
- Page 9 3 AUTOMATIC TRACKING / AUTOMATIC COLLIMATION ....58 3.1 Automatic Tracking ........... . . 59 3.2 Automatic Collimation .
- Page 10 8 SETTING THE PRISM / NON-PRISM CONSTANT CORRECTION VALUE ..125 9 SETTING ATMOSPHERIC CORRECTION......127 9.1 Calculation of Atmospheric Correction .
- Page 11 1 NOMENCLATURE AND FUNCTIONS NOMENCLATURE AND FUNCTIONS Nomenclature Sighting collimator Carrying handle Handle fixing screw Tracking indicator GTS-900A/GPT-9000A Laser aperture (for Optical communication) Instrument center mark Card cover Hardware reset switch (Inside the cover) Objective lens Laser pointer Card cover lever Only for GPT-9000A Laser aperture Optical plummet...
- Page 12 Specializing in quality used surveying and optical equipment Hodgens Equipment Sales www.hodgens.net equip@hodgens.net 800-463-4367 INSTRUCTION MANUAL (SPECIFICATIONS) AUTO TRACKING TOTAL STATION GTS-900A SERIES GTS-901A GTS-903A GTS-905A AUTO TRACKING PULSE TOTAL STATION GPT-9000A SERIES GPT-9001A GPT-9003A GPT-9005A SERVO PULSE TOTAL STATION...
- Page 13 SPECIFICATIONS SPECIFICATIONS Telescope Length : 165mm Objective lens : 45mm (EDM 50mm) Magnification : 30× Image : Erect Field of view : 1°30' Resolving power : 3" Minimum focus : 1.3m Reticle illumination : Provided Automatic Tracking / Collimating Maximum Automatic Tracking speed : 15°...
- Page 14 SPECIFICATIONS Distance measurement Measurement range [GTS-900A series] • Prism mode Atmospheric conditions Prism Condition 1 Condition 2 Mini prism 1,000m (3,280ft) ---- 1 prism 3,000m (9,842ft) 4,000m (13,123ft) 3 prisms 4,000m (13,123ft) 5,300m (17,388ft) 9 prisms 5,000m (16,404ft) 6,500m (21,325ft) [GPT-9000A/9000M series] •...
- Page 15 SPECIFICATIONS Measurement accuracy/Least Count in Measurement/Measurement Time [GTS-900A series] Prism mode • Measurement Least Count Measurement mode Measurement accuracy *1) in Measurement Time 0.2mm Approx. 3 sec. 0.2mm mode (0.001ft) (Initial 4 sec.) Fine ± (2mm +2ppm x D) m.s.e.
- Page 16 SPECIFICATIONS • Non-prism long mode *3) *4) (Diffusing Surface) Measuring distance Least Count Measurement Measurement mode Measurement accuracy in Measurement Time ± (10mm +10ppm x D) Approx. 1.5~6 sec. Fine 1mm mode m.s.e. (0.005ft) (Initial 6~8 sec.) ± (20mm +10ppm × D) Approx.
- Page 17 SPECIFICATIONS Display : 3.5 inch TFT color LCD (240x320 dots) Touch panel : Electrical analog resistor thin film system Bluetooth™ Unit Bluetooth™ Communication distance : About 5m (The range will be different by a condition) Bluetooth™ Standard : V1.2 Bluetooth™ Transmitting : Class2 Wireless function Communication distance...
- Page 18 : Orange charge lamp should glow Finishing signal : Green charge lamp should glow Weight(with AC/DC converter) : 0.4kg (0.8 lbs) • Battery using time will vary depending on environmental conditions and operations done with GTS-900A/GPT-9000A/GPT-9000M series. ©2006 TOPCON CORPORATION ALL RIGHTS RESERVED...
- Page 19 Specializing in quality used surveying and optical equipment Hodgens Equipment Sales www.hodgens.net equip@hodgens.net 800-463-4367 INSTRUCTION MANUAL REMOTE CONTROL SYSTEM 3 RC-3 Rev.4...
