Calculated Industries Construction Master IV User Manual

For today's construction professional
Hide thumbs Also See for Construction Master IV:
Table of Contents

Advertisement

Quick Links

See also: User Manual
Software copyrighted and licensed to
Calculated Industries by
Construction Master Technologies,
LLC, 2003
Construction Master IV User's Guide
Copyrighted by Calculated Industries,
2003
Construction Master® and
Calculated Industries® are
registered trademarks
of Calculated Industries, Inc.
ALL RIGHTS RESERVED.
Designed in the
United States of America
Printed in China
UG4045E-B
4/03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Construction Master IV and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Calculated Industries Construction Master IV

Summary of Contents for Calculated Industries Construction Master IV

  • Page 1 Software copyrighted and licensed to Calculated Industries by Construction Master Technologies, LLC, 2003 Construction Master IV User’s Guide Copyrighted by Calculated Industries, 2003 Construction Master® and Calculated Industries® are registered trademarks of Calculated Industries, Inc. ALL RIGHTS RESERVED. Designed in the...
  • Page 2 ® ONSTRUCTION ASTER For Today's Construction Professional User’s Guide...

  • Page 3: Table Of Contents

    Board Feet/ Lumber Calculations .32 Right-Triangle Calculations ..33 Hip/Valley & Jack Rafters.....39 Stair Problems (Risers/Treads) ...43 Circle Problems......46 Appendix A ........47 Battery & Auto Shut-Off....47 Default Values......47 Appendix B ........48 Repair and Return ......50 Warranty .........51 ONSTRUCTION 2 — Construction Master IV...
  • Page 4 ® ASTER Designed for today’s construction pro- ® fessional, the Construction Master is so simple, even the novice user will find it easy to solve hundreds of di- mension-related problems right in feet, inches and fractions! Solve Dimensional Math ♦ English/Metric Conversions ♦...

  • Page 5: Getting Started

    Used with the dimensional keys to convert between dimensions or with other keys to access special func- tions. ] — Square Root Key Used to find the square root of a non-dimensional or area value. 4 — Construction Master IV...
  • Page 6 [Conv] [ ] — x Function Finds the square of a linear or non- dimensional value. [M+] — Memory Key Adds the displayed value to Mem- ory. Clears when the calculator is shut off. [Conv] [M+] — Memory Minus (M–) Subtracts the displayed value from Memory.
  • Page 7 [Inch] — Inch Key Enters or converts to inches. Entry can be whole or decimal numbers. Also used with the [/] key for enter- ing fractional inch values (e.g., 9 [Inch] 1 [/] 2). Repeated presses 6 — Construction Master IV...
  • Page 8 during conversions toggle between Fractional and Decimal Inches. [ / ] — Fraction Bar Key Used to enter fractions. Fractions can be entered as proper (1/2, 1/8, 1/16) or improper (3/2, 9/8). If the denominator (bottom) is not entered, the calculator's fractional accuracy setting is automatically used.
  • Page 9 [Conv] [Diag] — Rake Walls This function finds the decreasing stud sizes in a raked wall based on computed or entered values for pitch, rise and/or run. Repeated presses display stud sizes from longest to shortest. 8 — Construction Master IV...
  • Page 10 The on-center spacing of a raked wall can be permanently stored by entering a dimension prior to solving for stud sizes (12 [Inch] [Conv] [Diag]). Default on-center spacing is 16 inches (Metric Mode: 600 mm). [Hip/V] — Hip/Valley Rafter Key Finds the regular or irregular hip/ valley rafter length.
  • Page 11 (e.g., 19.2 [Inch] [Conv] [Jack]). Stair & Circle Keys [Stair] — Stair Key A multi-function key that enters a desired riser height and uses the rise and run values to compute and display the following: 10 — Construction Master IV...
  • Page 12 Press Result Number of Risers Actual Riser Height Riser Overage/Underage Number of Treads Actual Tread Width Tread Overage/Underage Stringer Length Inclination Angle Default value is 7-1/2 inches (Metric Mode: 185 millimeters). [Circ] — Circle Displays the following values, given an entered diameter: 1) diameter, 2) area, and 3) circumference.

  • Page 13: Fractional Settings

    1,000 Bdft (Mbm) Fractional Settings Setting Fractional Accuracy When your calculator is in a default condition (battery change or full reset), it is set to round fractional values to the nearest 1/16th of an inch. The 12 — Construction Master IV...

  • Page 14: Entering Dimensions

    fractional level can be revised by using the following keystrokes: [Conv] 1 = Accuracy set to 1/16 [Conv] 2 = Accuracy set to 1/2 [Conv] 3 = Accuracy set to 1/32 [Conv] 4 = Accuracy set to 1/4 [Conv] 6 = Accuracy set to 1/64 [Conv] 8 = Accuracy set to 1/8 A star ( ) will appear in the bottom...
  • Page 15 17.5 [m] Square and Cubic Dimen- sions Examples of how square and cubic dimensions are entered: Dimension Keystrokes 5 Cubic Yards 5 [Cu] [Yds] 130 Square Feet 130 [Sq] [Feet] 33 Square Meters 33 [Sq] [m] 14 — Construction Master IV...

  • Page 16: Linear Conversions

    Linear Conversions Convert 14 feet to other dimensions: Keystroke Display 14 [Feet] . . . [Conv] [Yds] 4.666667 YD [Conv] [Feet] 14 FT 0 IN [Conv] [Feet] 14 FT [Conv] [Inch] 168 IN [Conv] [mm] 4267.2 MM [Conv] [cm] 426.72 CM [Conv] [m] 4.2672 M Square Conversions...

  • Page 17: Basic Math Operations

    This feature also makes the calculator simple to use for dimensional applica- tions: * The calculator's auto-range function forced the answer to be in meters, as it is out of the calculator's normal 7-digit range (See Appendix A–Auto-Range). 16 — Construction Master IV...

  • Page 18: Adding Dimensions

    Adding Dimensions Add 11 inches to 2 feet 1 inch: 11 [Inch] [+] 2 [Feet] 1 [Inch] [=] 36 IN Subtracting Dimensions Subtract 3 feet from 11 feet 7-1/2 inches: 11 [Feet] 7 [Inch] 1 [ / ] 2 [–] 3 [Feet] [=] 8 FT 7-1/2 IN Multiplying Dimensions Multiply 5 feet 3 inches by 11 feet 6-...

  • Page 19: Percentage Calculations

    Divide 350 cubic yards by 80%: 350 [Cu] [Yds] [÷] 80 [%] 437.5 CU YD Memory Operation Whenever the [M+] key is pressed, the displayed value will be added to the Memory. Other memory functions: 18 — Construction Master IV...
  • Page 20 Function Keystrokes Add to Memory [M+] Subtract from Memory [Conv] [M+] Recall total in Memory [Rcl] [M+] Display/Clear Memory [Rcl] [Rcl] Clear Memory [Conv] [Rcl] Replace Memory [Conv] [Rcl] [M+] Memory is semi-permanent, clearing only when you: turn off the calculator; press [Rcl] [Rcl];...

  • Page 21: Paperless Tape

    Note: The Paperless Tape is cleared each time [On/C] is pressed twice, or the unit is shut off. 20 — Construction Master IV...
  • Page 22 Previewing Paperless Tape Keystroke Display 1. Enter a string of numbers: 4 [Feet] [+] 4 FT 0 IN 5 [Feet] [+] 9 FT 0 IN 6 [Feet] [+] 15 FT 0 IN 7 [Feet] [=] 22 FT 0 IN 2. Access the Tape function: [Rcl] [=] TTL= 22 FT 0 IN 3.

  • Page 23: Examples

    18 [Feet] 7 [Inch] 1 [ / ] 2 18 FT 7-1/2 IN [÷] 16 [Inch] [=] 13.96875 (14 studs) 2. Add one for the end [+] 1 [=] 14.96875 (15 studs) Note: Also applies to trusses and joists. 22 — Construction Master IV...
  • Page 24 Masonry — Estimating Bricks How many standard bricks (3-3/4 inch by 8 inch) are required for a 36.5 feet by 8 feet wall? Keystroke Display 1. Find Brick Area [On/C] [On/C] 3 [Inch] 3[ / ] 4 [x] 8 [Inch] [=] 30 SQ IN 2.

  • Page 25: Area Calculations

    Using the x ([Conv][ ]) function, find the area of a square with sides of 4 feet 7 inches. Keystroke Display [On/C] [On/C] 4 [Feet] 7 [Inch] 4 FT 7 IN [Conv][ 21.00694 SQ FT 24 — Construction Master IV...
  • Page 26 Area — Floor Covering You have an apartment with two rooms of carpet that need to be replaced. The room dimensions are as follows: 12 feet 4 inches by 10 feet and 14 feet 8 inches by 16 feet. How many square yards of carpet are needed and what is the total cost at $11.75 per square yard?
  • Page 27 180 SQ IN [M+] 180 SQ IN 2. Find Total Shingles Required 1745 [Sq] [Feet] 1745 SQ FT [÷] [Rcl] [Rcl] [=] 1396 (shingles) 3. Add 10% for waste [+] 10 [%] 1535.6 (1536 shingles) 26 — Construction Master IV...

  • Page 28: Volume Calculations

    Volume Calculations Rectangular Containers What is the volume of a container 3 feet by 1 foot 9-5/8 inches by 2 feet 4 inches? (LxWxH) Keystroke Display [On/C] [On/C] 3 [Feet] 3 FT [x] 1 [Feet] 9 [Inch] 5 [ / ] 8 1 FT 9-5/8 IN [x] 2 [Feet] 4 [Inch] [=] 12.61458 CU FT...

  • Page 29: Concrete Columns

    3 [Feet] 4 [Inch] 1 [ / ] 2 3 FT 4-1/2 IN [Circ] [Circ] AREA 8.946176 SQ FT 2. Find Total Volume [x] 11 [Feet] 6 [Inch] [=] 102.881 CU FT [Conv] [Yds] 3.810408 CU YD [x] 5 [=] 19.05204 CU YD 28 — Construction Master IV...

  • Page 30: Complex Concrete Volume

    Complex Concrete Volume You’re going to pour an odd-shaped patio 4-1/2 inches deep with the di- mensions shown below. First, calculate the total area (by dividing the drawing into three individual rectangles) and then determine the total yards of con- crete required for this job.
  • Page 31 85.5 SQ FT [M+] 4. Find Total Area [Rcl] [Rcl] 1038.917 SQ FT 5. Find Total Cubic Yards [x] 4 [Inch] 1 [ / ] 2 [=] 389.5937 CU FT [Conv] [Yds] 14.4294 CU YD 30 — Construction Master IV...

  • Page 32: Volume/Weight Calculations

    Volume/Weight Calculations Concrete Footing Find the total volume* of concrete re- quired to pour five 24 inch by 12 inch footings, each 2 feet deep. Then find the weight of the concrete (use 1.5 tons per cubic yard). Keystroke Display [On/C] [On/C] 1.

  • Page 33: Board Feet/Lumber Calculations

    9.333333 B FT 2 [x] 10 [x] 16 [BdFt] [M+] 26.66667 B FT 2 [x] 12 [x] 18 [BdFt] [M+] 36 B FT [Rcl] [Rcl] 72 B FT [x] 250 [Conv] [•] $ 18.00 Per 32 — Construction Master IV...

  • Page 34: Right-Triangle Calculations

    Right-Triangle Calculations The top row of keys provide you with built-in solutions to right triangles. The solutions are available in any of the linear dimensions offered on the calcu- lator. Thus, you can solve right trian- gles directly in feet and inches, deci- mal feet, meters, etc.
  • Page 35 1. Enter Sides as Rise/Run 45 [Feet] 6 [Inch] [Run] RUN 45 FT 6 IN 24 [Feet] 4 [Inch] [Rise] RISE 24 FT 4 IN 2. Find the Square Up (Diagonal) [Diag] DIAG 51 FT 7-3/16 IN 34 — Construction Master IV...

  • Page 36: Area For Roofing Materials

    Area for Roofing Materials You’re ordering roofing materials for a roof with a 5/12 Pitch, an overall span of 27 feet and a length of 34 feet 6 inches. How many squares, at 100 square feet each, are there? Keystroke Display [On/C] [On/C] 1.
  • Page 37 23’ 6” Keystroke Display [On/C] [On/C] 7 [Inch] [Pitch] PTCH 7 IN 23 [Feet] 6 [Inch] [÷] 2 [=] 11 FT 9 IN [Run] RUN 11 FT 9 IN [Diag] DIAG 13 FT 7-1/4 IN 36 — Construction Master IV...
  • Page 38 Finding Rise — (Pitch and Run Known) Though not commonly asked for, you can compute the rise or run of a right angle just as you would the diagonal. Find the rise given a 7/12 pitch and a run of 11 feet 6 inches: Keystroke Display [On/C] [On/C]...
  • Page 39 RW 2 14 FT 0-7/8 IN [Diag] RW 3 13 FT 4-13/16 IN [Diag] RW 4 12 FT 8-3/4 IN [Diag] RW 5 12 FT 0-11/16 IN Etc..Continue pressing [Diag] until last stud size or "0" is reached. 38 — Construction Master IV...

  • Page 40: Hip/Valley & Jack Rafters

    Hip/Valley & Jack Rafters Regular (45°) Hip/Valley & Jack Rafters You’re working with a 7/12 Pitch, and half your total span is 13 feet 9 inches: (A) Find the point-to-point length for the common rafter; (B) Find the length of an adjoining hip (or valley); and (C) Find the lengths of the regular jack rafters (jack rafters at 16”...
  • Page 41 Etc..Continue pressing [Jack] until last Jack is reached or until display shows “0.” * If the entered value is not dimensioned, the calculator will assume the value as inches for English and millimeters for Metric calcu- lations. 40 — Construction Master IV...
  • Page 42 Irregular (non-45°) Hip/Valley & Jack Rafters You’re working with a 7/12 pitch and half your overall span is 15 feet 7 inches. The irregular pitch is 8/12. Find the common rafter length, irregular hip/valley and jack rafter lengths. Keystroke Display [On/C] [On/C] 1.
  • Page 43 [Jack] JK2 14 FT 6-1/8 IN [Jack] JK3 12 FT 9 IN [Jack] JK4 10 FT 11-13/16 IN [Jack] JK5 9 FT 2-5/8 IN Etc..Continue pressing [Jack] until last regular jack or “0.” is reached. 42 — Construction Master IV...

  • Page 44: Stair Problems (Risers/Treads)

    Stair Problems (Risers/Treads) The Construction Master IV easily computes the various values pertaining to stair building. Given values for total rise, total run and a desired stair riser height, your calculator will compute the following with the press of the [Stair]...
  • Page 45 2. Find Stair Values [Stair] RSRS 8 [Stair] R–SZ 5-5/8 IN [Stair] R+/– – 0-1/4 IN [Conv] [x] (Optional) * * An ALL CLEAR is performed here to set the calculator to its default settings. 44 — Construction Master IV...
  • Page 46 Risers & Treads — (7-1/2 Inch Desired Riser Height) You need to build a stairway having a floor-to-floor height of 28 feet 5-1/2 inches, a run of 35 feet 6 inches and a nominal riser height of 7-1/2 inches (default). Find the number of risers, the riser height and underage/overage, the number of treads, the tread width and underage/ overage, stringer length and...

  • Page 47: Circle Problems

    Find the arc length of an 85° portion of a circle with a 5-foot diameter. Keystroke Display [On/C] [On/C] 5 [Feet] [Circ] 5 FT 0 IN DIA 85 [Conv] [Circ] 3 FT 8-1/2 IN ARC [Feet] 3.708825 FT 46 — Construction Master IV...

  • Page 48: Battery & Auto Shut-Off

    PPENDIX Battery & Auto Shut-Off Your calculator is powered by a single 3-Volt Lithium CR-2032 battery. This should last upwards of 800 hours of actual use (1 year plus for most peo- ple). Should the display become very dim or erratic, replace the battery.* Your calculator is designed to shut itself off after about 8-12 minutes of non-use.

  • Page 49: Area Formulas

    PPENDIX Area Formulas Square Area = a Rectangle Area = lw Triangle Area = Circle Circumference = 2πr Area = π r Ellipse Area = πab 48 — Construction Master IV...
  • Page 50 Surface Area & Volume Formulas Cube Surface area = 6a Volume = a Rectangle Surface area = 2hw + 2hl + 2lw Volume = l x w x h Cone Surface area = π r r + h (+ π r if you add the base) Volume = πr h Sphere Surface area = 4 π...

  • Page 51: Repair And Return

    Support, then Repair Services FAQs. 5. If you believe you need to return your calculator, please speak to a Calculated Industries representative for additional information! Call Toll Free: 1-800-854-8075 50 — Construction Master IV...

  • Page 52: Warranty

    ARRANTY Warranty Repair Service – U.S.A. Calculated Industries, Inc. ("CI") warrants this product against defects in materials and workman- ship for a period of one (1) year from the date of original consumer purchase in the U.S. If a defect...
  • Page 53 CONSEQUENTIAL DAMAGES RESULTING FROM ANY DEFECT IN THE PRODUCT OR ITS DOCU- MENTATION. The warranty, disclaimer, and remedies set forth above are exclusive and replace all others, oral or written, expressed or implied. No CI dealer, agent, 52 — Construction Master IV...
  • Page 54 This equipment has been certified to comply with the limits for a Class B computing device, pursuant to Subpart J of Part 15 of FCC rules. Calculated Industries, Inc. 4840 Hytech Drive Carson City, NV 89706 U.S.A 1-775-885-4900 • Fax: 1-775-885-4949 E-mail: info@calculated.com...
  • Page 55 54 — Construction Master IV...
  • Page 56 User's Guide — 55...
