4. Assemble Procedure
Information in this section is to perform the assembly procedure of the LCD
monitor.
Asus MW221/201 LCD monitor consists of various subsystems. This
section describes the procedures for LCD monitor assembly. In addition, the
detailed assembly procedures of individual modules will be provided for your
service needs.
The assembly procedure consists of the following steps:
4.1 Stand Subsystem
4.2 Board Subsystem
4.3 Panel Subsystem
4.4 Bezel Subsystem
