Zephyr Ceiling/Wall Ventilating Fans Model Z1

Troubleshooting Checklist

Symptom Possible Cause(s)
1. Defective or loose motor bearings
2. Ventilator base not securely anchored
3. Loose or unbalanced wheel/propeller
Excessive noise
4. Misaligned pulleys or shaft
5. Loose or damaged wheel/propeller
6. Wheel running in wrong direction
1. Blown fuse or open circuit breaker
2. Loose or disconnected wiring
Fan inoperative
3. Defective motor
4. Broken belts
1. Open access doors or loose sections of ducts
2. Clogged filters
Insufficient airflow 3. Operation in wrong direction
4. Insufficient make-up air direction
1. Fan installed with slope in the wrong direction
Water leaking
2. Clogged drain spout
into ductwork or
collection of grease
3. Cooling tube or motor dome top removed
under fan
4. Grease container full
1. Belt slippage
2. Overvoltage or under voltage
3. Operation in wrong direction
4. Fan speed too high
5. Incorrect motor (service factor 1.0,
Motor overheating
6. Blocked cooling tube or leaky gasket
7. Insufficient airflow to kitchen hood fan operating
8. Undersized motor
Note: Care should be taken to follow all local electrical, safety and building codes. Provisions of the National Electric Code (NEC), as wells as the Occupational Safety
and Health Act (OSHA) should be followed.
All motors are checked prior to shipment. If motor defects should develop, prompt service can be obtained from the nearest author-
ized service station of the motor manufacturer while under warranty. Exchange, repair or replacement will be provided on a no
charge basis if the motor is defective within the warranty period. The PennBarry representative in your area will provide a name and
address of an authorized service station if requested. WARNING: Motor guarantee is void unless overload protection is provided in
motor wiring circuit.
