SWP
(Models SWP08 through SWP20)
OPERATION & MAINTENANCE MANUAL
IMPORTANT! Read before proceeding!
Read carefully before attempting to assemble, install, operate or maintain
the product described. Protect yourself and others by observing all safety
information. Failure to comply with instructions could result in personal injury
and/or property damage! Retain instructions for future reference.
1
Advertisement
Table of Contents
Related Manuals for PennBarry SWP series
Summary of Contents for PennBarry SWP series
- Page 1 (Models SWP08 through SWP20) OPERATION & MAINTENANCE MANUAL IMPORTANT! Read before proceeding! Read carefully before attempting to assemble, install, operate or maintain the product described. Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or property damage! Retain instructions for future reference.
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION INSTALLATION START-UP AND OPERATION MAINTENANCE DIMENSIONAL DATA FAN EXPLODED VIEW WALL MOUNTING SLEEVE ASSEMBLY WEATHER SHIELD ASSEMBLY DAMPER GUARD ASSEMBLY TROUBLESHOOTING CHECKLIST www.PennBarry.com... -
Page 3: Introduction
Receiving and Handling PennBarry fans are carefully inspected before leaving the factory. When the unit is received, inspect the carton for any signs of tampering. Inspect the unit for any damage that may have occurred during transit and check for loose, missing or damaged parts. -
Page 4: Installation
7’ above the floor require guarding as specified in the Occupational Safety and Health Act (OSHA). UL listed fans, to maintain their personal safety listing, must be installed not less than 10 feet above the floor. PennBarry recommends the use of guards on all exposed non-ducted fans. - Page 5 Figure 1 for the proper mounting arrangements. Secure the damper to the wall opening without undue twisting which may distort the frame. Check for free operation. If dampers are motor operated type, ascertain the proper voltage is present on motor terminals. The fan is now ready for service. Speed Controller www.PennBarry.com...
- Page 6 Minimum Clearance between Fan and Shutter – Figure 4 Dimension (D) Model Figure 4: Typical Wall Sleeve and Damper Installation Figure 3: Typical Wall Sleeve Installation Figure 5: Other Typical Mounting Arrangements Wall Shutter Recess Mounting Wall Shutter Surface Mounting Louver www.PennBarry.com...
-
Page 7: Start-Up And Operation
At this time, also check motor input current and motor bearing temperatures to ensure that they do not exceed manufacturer’s recommendations. After eight hours of satisfactory operation, shut down the fan and lock out the electrical power to check the following items and adjust all set-screws, keys, and fasteners as necessary. www.PennBarry.com... -
Page 8: Maintenance
Unprotected fans located less than 7’ above the floor also require guarding as specified in the Occupational Safety and Health Act (OSHA). PennBarry recommends the use of guards on all exposed non-ducted fans, ceiling and wall mounted. www.PennBarry.com... -
Page 9: Dimensional Data
DIMENSIONAL DATA Sizes 08 - 12 Sizes 14 - 20 Size DIM A DIM B 13.0 11.06 15.0 11.13 18.0 11.75 20.0 13.88 22.0 14.68 24.0 14.13 26.0 13.94 www.PennBarry.com... -
Page 10: Fan Exploded View
3. Wire Guard H/W package 4. Wire Guard 5. Motor 6. ¼-20 x 1.25” Whiz Bolt 7. ¼-20 Whiz Nut 8. #8-32 Whiz Nut 9. #8 Washer 10. 10-32 x 1.00” Bolt 11. Controller Support Bracket 12. #10-32 Whiz Nut www.PennBarry.com... -
Page 11: Wall Mounting Sleeve Assembly
WALL MOUNTING SLEEVE ASSEMBLY Legend 1. L Panels 2. Screen Guard 3. Hex #10 X 5/8 Self Drilling 4. Slip Flange www.PennBarry.com... -
Page 12: Weather Shield Assembly
WEATHER SHIELD ASSEMBLY 45 Degree Weather Hood 90 Degree Weather Hood Legend 1. Top Panel 2. Bottom Panel 3. Left Panel 4. Right Panel 5. Screen Guard 6. Hex #10 X 5/8 Self Drilling www.PennBarry.com... -
Page 13: Damper Guard Assembly
DAMPER GUARD ASSEMBLY Legend 1. L Panels Top 2. L Panels Side 3. Screen Guard 4. Hex #10 X 5/8 Self Drilling www.PennBarry.com... -
Page 14: Troubleshooting Checklist
Exchange, repair or replacement will be provided on a no charge basis, if the motor is defective within the warranty period. The PennBarry representative in your area will provide a name and address of an authorized service station if requested. - Page 15 PennBarry is proud to be your preferred manufacturer of commercial and industrial fans and blowers. Learn how PennBarry can assist you in your next application by contacting your PennBarry Representative or visiting us on the web at www.pennbarry.com. PennBarry | www.pennbarry.com | pennbarrysales@pennbarry.com | tel: 972.212.4700 | fax: 972.212.4702 PennBarry reserves the right to make changes at any time, without notice, to models, construction, specifications, options and availability.
