ROUND CENTREX
Centrifugal Inline Fans
OPERATION & MAINTENANCE MANUAL
IMPORTANT! Read before proceeding!
The information contained herein is, to the best of our knowledge, accurate and
applicable for proper operation and installation of the specified equipment at
the time this document entered service. Before proceeding, it is recommended
that you check for a more current version of this Installation Operation Manual
(IOM) on our website at www.pennbarry.com.
Read carefully before attempting to assemble, install, operate or maintain the
product described. Protect yourself and others by observing all safety informa-
tion. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ROUND CENTREX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PennBarry ROUND CENTREX

Summary of Contents for PennBarry ROUND CENTREX

  • Page 1 Before proceeding, it is recommended that you check for a more current version of this Installation Operation Manual (IOM) on our website at www.pennbarry.com. Read carefully before attempting to assemble, install, operate or maintain the product described.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION & INSTALLATION START-UP AND OPERATION MAINTENANCE SPECIAL PURPOSE SYSTEMS, HIDDEN DANGER & GUARDS PARTS REPLACEMENT TROUBLESHOOTING CHECKLIST www.PennBarry.com...

  • Page 3: Introduction & Installation

    PennBarry fans are carefully inspected before leaving the factory. When the unit is received, inspect the carton for any signs of tampering. Inspect the unit for any damage that may have occurred during transit and check for loose, missing or damaged parts.

  • Page 4: Start-Up And Operation

    This set up must match the line voltage. If the motor is multi-speed or multi-voltage, the winding leads must be grouped and connected as shown on the motor wiring diagram. The line voltage must correspond with proper grouping of motor leads. The wiring diagram must be followed explicitly or serious motor or starter damage will occur.) www.PennBarry.com...
  • Page 5 After eight hours of satisfactory operation, shut down the fan and lock out the electrical power to check the following items and adjust if necessary: All set-screws, keys and fasteners. Drive coupling alignment. Belt alignment. Belt tension. www.PennBarry.com...

  • Page 6: Maintenance

    Gulf Gulfcrown EP-1 Below 32°F (0°C) Imperial Oil Unirex EP-1 Shell Alvania R-1 Energrease, MPMK11 Gulf Gulfcrown EP-2 Imperial Oil Unirex EP-2 32°F to 150°F (0°C to 66°C) Shell Alvania R-3 Sun Oil Sun Prestige 42 Texaco Regal AFB2 www.PennBarry.com...

  • Page 7: Special Purpose Systems, Hidden Danger & Guards

    Centrifugal fans may be connected directly to ductwork which will prevent contact with the internal moving parts, but when the inlet or outlet is exposed, install a suitable guard. PennBarry recommends the use of guards on all exposed non-ducted fans, ceiling and wall mounted.

  • Page 8: Parts Replacement

    Vibration Isolators DIRECT DRIVE Straightening Vane Gasketed Access Panel Suspension Angle Supports Ball Bearing Motor Belt Guide Enclosure* Wheel Shaft and Bearings* Belt and Pulleys* Bearing Support Frame* Adjustable Motor Frame* * Applies to belt drive models only BELT DRIVE www.PennBarry.com...

  • Page 9: Troubleshooting Checklist

    Exchange, repair or replacement will be provided on a no charge basis if the motor is defective within the warranty period. The PennBarry representative in your area will provide a name and address of an authorized service station if requested.
  • Page 10 PennBarry is proud to be your preferred manufacturer of commercial and industrial fans and blowers. Learn how PennBarry can assist you in your next application by contacting your PennBarry Representative or visiting us on the web at www.pennbarry.com. PennBarry | www.pennbarry.com | pennbarrysales@pennbarry.com | tel: 972.212.4700 | fax: 972.212.4702 PennBarry reserves the right to make changes at any time, without notice, to models, construction, specifications, options and availability.
