HOME AUTOMATION, INC
Control & Security System
Includes the SIA CP-01 Control Panel Standard
Features for False Alarm Reduction

Installation Manual

Document Number 20I00-2 Rev. 2.13
September, 2006

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Omni Pro II and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HAI Omni Pro II

Summary of Contents for HAI Omni Pro II

  • Page 1: Installation Manual

    HOME AUTOMATION, INC Control & Security System Includes the SIA CP-01 Control Panel Standard Features for False Alarm Reduction Installation Manual Document Number 20I00-2 Rev. 2.13 September, 2006...
  • Page 3 Home Automation, Inc. Installation Manual Includes the SIA CP-01 Control Panel Standard Features for False Alarm Reduction Document Number 20I00-2 Rev. 2.13 September, 2006 Copyright © 2001-2006 Home Automation, Inc. All Rights Reserved...

  • Page 4: Table Of Contents

    GENERAL PURPOSE SWITCHING APPLICATIONS......................16 SOUNDER TRIGGERING ..............................16 COMMUNICATOR OUTPUTS ..............................17 "ARMED" AND "OK TO ARM".............................17 SWITCHED OUTPUT ................................17 HAI COMMUNICATING THERMOSTATS..........................17 REMOTE ARM/DISARM SWITCH............................17 HAI THERMOSTATS ...................................19 PROGRAMMABLE ENERGY SAVER MODULES .........................20 TEMPERATURE, OUTDOOR TEMPERATURE, AND HUMIDITY ..................21 BUILT-IN SERIAL PORTS ................................23 BUILT-IN ETHERNET PORT ..............................24...
  • Page 5 DIGITAL COMMUNICATOR........................32 DESCRIPTION OF CONTACT ID..............................32 DESCRIPTION OF 4/2 FORMAT ...............................32 3/1 FORMAT ....................................33 OPENING AND CLOSING REPORTS ............................33 INSTALLER SETUP............................ 34 SETUP CONTROL ..................................34 UPB Network ID ..................................34 X-10 3-PHASE ..................................35 OUTPUT TYPES ..................................35 SETUP ZONES....................................36 ZONE EXPANSION ................................36 ZONE RESISTORS..................................37 ZONE TYPES ..................................38 LATCHING ZONE TYPES ..............................38...
  • Page 6 FIGURE 8 - SOUNDER CONNECTIONS............................15 FIGURE 9 - RESETTING CONTROLLER OUTPUTS........................16 FIGURE 10 - REMOTE KEYSWITCH CONNECTIONS ......................18 FIGURE 11 - HAI THERMOSTAT CONNECTIONS........................19 FIGURE 12 - TEMPERATURE / HUMIDITY SENSOR CONNECTIONS ..................21 FIGURE 13 - PESM CONNECTIONS ............................22 FIGURE 14 - RS-232 CONNECTIONS............................23 FIGURE 15 - RS-485 CONNECTIONS............................24...

  • Page 7: Introduction

    INTRODUCTION This installation guide is intended as an aid to installing the OmniPro II Control & Security System. The installer should also have thoroughly reviewed and understood the OmniPro II Owner's Manual, which has important information regarding final setup of the system. This manual assumes that the installer has a basic understanding of installing a security system. This guide applies to the 20A00-2, -5, and -22 versions of the OmniPro II series controller.

  • Page 8: Installation

    INSTALLATION Go over your plan with your customer. 1. Install the entire system. Refer to sections in this manual to see how to install various components. 2. Follow the Power-Up and Checkout procedures. 3. Explain the basics to the customer. Deliver all manuals and documentation. 4.

  • Page 9: Figure 1 - Controller Hookup

    1/4" SPACING BLACK WIRE TO - RED WIRE TO + YUASA NP7-12 BATTERY OR EQUIVALENT 12V 7AH THE BATTERY IS NON-POWER LIMITED. THE BATTERY LEADS MUST BE SEPERATED FROM ALL OTHER POWER LIMITED/CLASS II WIRING IN THE ENCLOSURE BY AT LEAST 1/4" Status COLD WATER PIPE POWER TRANSFORMER...

  • Page 10: About Security Zones

    ABOUT SECURITY ZONES Each of the 176 security zone inputs on an OmniPro II system may be configured as a burglary zone, a fire zone, a temperature zone, or an auxiliary input. Zones 1-4, however, are the only inputs that can be used with 2-wire smoke detectors. Zones 9-16 (on the controller) and Zones 49-176 (on expansion enclosures) are the only inputs that can be configured as a PESM.

  • Page 11: About Fire Zones

    1. Smoke detectors must be powered from SWITCH 12V or an Output configured as a SWITCHED POWER OUTPUT. 2. End of line resistor: 1000 ohms. Maximum loop resistance EXCLUDING end of line resistor is a 150 ohms. Use HAI Model 1503A0011 End of Line Resistor Assembly in UL Listed Installations.

  • Page 12: Two-Wire Smoke Detectors

    TWO-WIRE SMOKE DETECTORS OmniPro II supports two-wire smoke detectors connected to Zones 1-4. 1. Use normally open (closed for alarm) two-wire "SYSTEM" type smoke detectors (See - 2-Wire Smoke Detector Compatibility Chart). 2. Smoke detectors must be connected to Zones 1-4 and configured as a Supervised Fire Zone. 3.

  • Page 13: Figure 3 - Two-Wire Fire Zone Connections

    WHEN Z1-Z4 IS CONFIGURED AS A SUPERVISED FIRE OR GAS ZONE, THE CORRESPONDING ZONE JUMPERS J11-J14 MUST BE IN "SMK" POSISTION SYSTEM SENSOR MODEL 2100TS BOTTOM PLATE ZONE ZONE SYSTEM SENSOR MODEL 2100TS BOTTOM PLATE ZONE ZONE MODEL 1503A0011 1K OHM EOL RESISTOR FIGURE 3 - TWO-WIRE FIRE ZONE CONNECTIONS Page 7...

  • Page 14: Figure 4 - Four-Wire Fire Zone Connections

    WHEN Z1-Z4 IS CONFIGURED AS A SUPERVISED FIRE OR GAS ZONE, THE CORRESPONDING ZONE JUMPERS J11-J14 MUST BE IN "SMK" POSISTION GREEN YELLOW BLACK BLACK SYSTEM SENSOR MODEL 2112/24TR YELLOW BOTTOM GREEN PLATE SYSTEM SENSOR MODEL 2112/24TR BOTTOM PLATE ZONE YELLOW ZONE GREEN...

  • Page 15: Telephone Connections

    TELEPHONE CONNECTIONS 1. If an RJ31X jack has been supplied by the telephone company, it is probably wired correctly and the controller can be connected by plugging the supplied 8 conductor telephone cable into the RJ31X jack. The other end of the cable is spaded. The green, red, brown, and gray wires must be connected to the controller at the designated terminals under the section of the board marked 'PHONE'.

  • Page 16: Figure 5 - Rj31X Jack Connections

    BEND TAB UP IF NECESSARY TO ENSURE TIGHT FIT RED(-) GREEN(+) TELEPHONE NETWORK INTERFACE CUSTOMER ACCESS RED(-) GREEN(+) SURGE ARRESTOR SURGE ARRESTOR MUST BE GROUNDED! RJ11 HOUSE PHONE TO TELCO JACK(S) INTERFACE AT SURGE ARRESTOR TO ALL HOUSE TELEPHONES OR PBX FIGURE 5 - RJ31X JACK CONNECTIONS Page 10...

  • Page 17: Lcd Console Hookup

    RED(-) GREEN(+) TELEPHONE NETWORK RED(-) GREEN(+) INTERFACE CUSTOMER ACCESS DSL SPLITTER SURGE ARRESTOR VOICE SURGE ARRESTOR LINE IN MUST BE GROUNDED! RJ11 TO ALL HOUSE HOUSE TELEPHONES PHONE DATA JACK(S) DSL MODEM COMPUTER FIGURE 6 – DSL SPLITTER CONNECTIONS LCD CONSOLE HOOKUP 1.

  • Page 18: Console Setup

    CONSOLE SETUP The console has different operating options that can be setup from the console to the user's preference. If more than one console is being used, it is required that you give each console a different address. You can change the address of a console through the console setup mode.

  • Page 19: Figure 7 - Console Connections

    FOR MODEL NUMBERS SEE NOTE 1 UNDER "LCD CONSOLE HOOKUP" CONSOLE FACE (SNAPS ON TO BOTTOM PLATE) CONTROL SECURITY BUTTONS TEMP STATUS FIRE BOTTOM PLATE EVENTS MESSAGE SETUP CANCEL MENU CONSOLE PC BOARD (MOUNTED TO CONSOLE FACE) SUPPLIED CABLE (PLUGS INTO J1) YELLOW GREEN BLACK...

  • Page 20: Sounder Outputs

    SOUNDER OUTPUTS The Horn Output provides 12VDC to power bells, piezo sirens, self-contained sirens, and siren drivers (do not connect speakers to the Horn Output). Sounders can draw up to 1 amp MAXIMUM, split between the Interior and Exterior Horn Outputs - (See Specifications for UL Ratings).

  • Page 21: Figure 8 - Sounder Connections

    FIGURE 8 - SOUNDER CONNECTIONS Page 15...

  • Page 22: Controller Outputs

    CONTROLLER OUTPUTS The OmniPro II provides 8 programmable hardwired voltage outputs and two horn voltage outputs. These outputs are programmable for the following output types: • General Purpose low voltage switching applications (12 VDC) - Units 385 - 392 • Sounder triggering (a trigger for siren and voice drivers for BURG and FIRE) •...

  • Page 23: Communicator Outputs

    HAI COMMUNICATING THERMOSTATS When HAI RC-Series thermostats are used, Output 8 is used to communicate with up to 64 thermostats. There is no need to configure this output when used with HAI thermostats. It may be left at the default setting of "General Purpose".

  • Page 24: Figure 10 - Remote Keyswitch Connections

    YELLOW GREEN GREEN BLACK MOMENTARY CONTACT KEYSWITCH FIGURE 10 - REMOTE KEYSWITCH CONNECTIONS Page 18...

  • Page 25: Hai Thermostats

    HAI THERMOSTATS OmniPro II supports up to 64 HAI RC-Series Communicating Thermostats. The controller can send commands to the thermostat to change mode, cool setting, heat setting, status of fan and hold, and other items. Run a 3 (or 4) conductor wire from OmniPro II to the thermostat location. All thermostats are connected in parallel to Zone 16 and Output 8.

  • Page 26: Programmable Energy Saver Modules

    PROGRAMMABLE ENERGY SAVER MODULES Programmable Energy Saver Modules may be connected to: Controller: Zone 9 and Output 1 through Zone 16 and Output 8, respectively Expansion Enclosures: Zone 1 and Output 1 through Zone 16 and Output 16, respectively 1. OmniPro II can support up to 136 Programmable Energy Saver Modules (PESM). Each PESM requires one security zone input and one controller output.

  • Page 27: Temperature, Outdoor Temperature, And Humidity

    0 to 100 percent or for sensing the outdoor temperature and/or reporting the outdoor relative humidity. The outdoor temperature can be displayed on the console, spoken over the telephone, or displayed on an HAI Communicating Thermostat.

  • Page 28: Figure 13 - Pesm Connections

    BLACK YELLOW GREEN EXISTING LOW VOLTAGE THERMOSTAT RED LED ON - ENERGY SAVER IS OVERRIDING THERMOSTAT OFF - THERMOSTAT IS WORKING NORMALLY HEAT / AIR SYSTEM PROGRAMMABLE ENERGY SAVER MODULE FIGURE 13 - PESM CONNECTIONS Page 22...

  • Page 29: Built-In Serial Ports

    (J1-J3). To access a serial port, use the HAI Model 21A05-2 Serial Cable Kit. Plug one end of the cable into one of the modular serial port connectors on the controller. Plug the other end into the Model 21A05-1 Communication Cable Adaptor (modular to DB-9 RS-232), which connects the OmniPro II serial port to the computer's DB-9 RS-232 port.

  • Page 30: Built-In Ethernet Port

    The following Setup items can only be assigned and changed from an HAI console. These items can not be assigned or changed via PC Access; although the IP address and port number may be viewed via PC Access:...

  • Page 31: Controller Ip Address

    CONTROLLER IP ADDRESS The controller’s local network IP address is used to identify the OmniPro II controller on the network. To view and assign the controller’s local network IP address, from the Set Up menu, press the 6 (MISC) key. Using the down arrow key (↓), scroll to the following menu item: IP ADDRESS 192.168.0.101...

  • Page 32: Connecting To Network Via Pc Access

    192.168.0.101 Hub or Router HAI OmniPro II Controller To connect to an OmniPro II controller on 192.168.0.50 a local network using HAI PC Access, under Configure >> Network enter the Computer controller’s IP address: (i.e. 192.168.0.101) 192.168.0.51 Computer FIGURE 16 - LOCAL NETWORK...

  • Page 33: Figure 17 - Local / Wide Area Network

    If the controller is connected to the Internet via a dynamic IP address, to locate and communicate with the controller from remote locations over the Internet using HAI PC Access, you must subscribe to a Dynamic DNS (Domain Name Service). Dynamic DNS is a service that maps your dynamic (changing) IP address to a static (permanent) hostname, allowing you to access your OmniPro II controller over the Internet using your static hostname instead of an IP address.

  • Page 34: System Power Up Procedure

    SYSTEM POWER UP PROCEDURE 1. Carefully review hookups to the zones, grounds, sounders, and consoles. 2. Disconnect 1 lead of both the interior and exterior sounders. NOTE: Follow this power up procedure to verify proper operation of the power supply, battery charger, and low voltage cut out relay.

  • Page 35: Burglar Zone Check Out

    5. Record the owner's NAME and ADDRESS in the ADDRESS speech memory as shown in SETUP ADDRESS in the OWNER'S MANUAL (Press 8, 9, then 1111 or the current Master code to record the address). NOTE: DO NOT record any TOUCH TONES in the ADDRESS!! 6.

  • Page 36: In Case Of Trouble

    13.7 volts. If not, make sure that there isn't too much load on the system. Disconnect all loads. If the STATUS LED still won't blink, there is a problem with the controller board and it must be returned to HAI for repair.
  • Page 37 13. NOTE: When a controller is returned from being repaired, all setup and programming is lost. The board is returned with the factory default setup and programming. FOR HELP: Call HAI between the hours of 9:00 AM and 5:00 PM Central time, Monday - Friday, at (800) 229-7256. Page 31...

  • Page 38: Digital Communicator

    DIGITAL COMMUNICATOR The OmniPro II digital communicator can use Contact ID, or Standard 4/2 or 3/1, (20 pps, 1800 Hz data, 2300 Hz handshake), or (10 pps, 1900 Hz data, 1400 Hz handshake), dual round compared format. Any central station with modern equipment can receive these formats.

  • Page 39: 3/1 Format

    3/1 FORMAT Older central stations may require a 3/1 format. To use 3/1 format, both account numbers must be changed to 3 digit codes and EVERY alarm code must be changed to a 1-digit code. Do not mix code lengths! OPENING AND CLOSING REPORTS The OmniPro II system can send opening and closing reports by user to the central station.

  • Page 40: Installer Setup

    INSTALLER SETUP This section describes the items that the installer must setup as part of system installation. The Installer Setup mode is used to configure the general operation of the system, the Outputs, the Areas, the Zone Types, the Digital Communicator, and various other settings.

  • Page 41: X-10 3-Phase

    UPB Status Time (Status Tracking): When using HLC, “Status Tracking” is used to update the status of each HLC device in a room whenever a scene is executed in that room. For example, the scene “A” button is pushed on a Room Controller in the Living Room. All of the lighting loads in the Living Room are changed, but the status for the individual lighting loads isn’t updated in OmniPro II until a status request message is sent to each unit.

  • Page 42: Setup Zones

    The Setup Control items are: OUTPUT 1 TYPE: GENERAL PURPOSE #=CHNG OUTPUT 2 TYPE: GENERAL PURPOSE #=CHNG OUTPUT 3 TYPE: GENERAL PURPOSE #=CHNG OUTPUT 4 TYPE: GENERAL PURPOSE #=CHNG OUTPUT 5 TYPE: GENERAL PURPOSE #=CHNG OUTPUT 6 TYPE: GENERAL PURPOSE #=CHNG OUTPUT 7 TYPE: GENERAL PURPOSE #=CHNG OUTPUT 8 TYPE:...

  • Page 43: Zone Resistors

    Wireless Receives can also be used to add additional zones to the OmniPro II system. When connected to an OmniPro II, the Wireless Receiver is recognized as an Expansion Enclosure. Each Wireless Receiver can handle up to 64 wireless zones, in groups of 16.

  • Page 44: Zone Types

    ZONE TYPES ZONE TYPE NUMBER DESCRIPTION ENTRY/EXIT Entry/Exit PERIMETER Perimeter NIGHT INT Night Interior AWAY INT Away Interior 2X ENTRY DELAY Double Entry Delay 4X ENTRY DELAY Quadruple Entry Delay LATCH PERIM Latching Perimeter LATCH NIGHT INT Latching Night Interior LATCH AWAY INT Latching Away Interior PANIC...
  • Page 45 ENTRY DELAY is extended on these zone types. The EXIT DELAY is not extended. If an ENTRY/EXIT ZONE is tripped first, all other zones will are delayed. PERIMETER and LATCHING PERIMETER PERIMETER ZONE types are intended for windows and exterior doors not requiring an entry delay. All PERIMETER ZONES are armed in security modes DAY, NIGHT, AWAY, and VACATION.
  • Page 46 OUTDOOR TEMPERATURE AND ER OUTDOOR TEMPERATURE Use this zone type for Outdoor Temperature Sensors. The outdoor temperature can be displayed on the console, spoken over the telephone, or displayed on an HAI Communicating Thermostat. TEMPERATURE AND EXTENDED RANGE TERMPERATURE The general-purpose TEMPERATURE ZONE type is typically used to monitor indoor temperatures and control devices. It sets the zone secure/not ready state for program conditionals and event button activation programs.
  • Page 47 TEMPERATURE ALARM AND EXTENDED RANGE TEMPERATURE ALARM The TEMPERATURE ALARM ZONE type will generate an alarm (console beeper, no sirens) and dial out if the temperature goes above the high setpoint or drops below the low setpoint. HUMIDITY The HUMIDITY ZONE type is used to monitor indoor and outdoor humidity levels from 0 to 100 percent using the Model 31A00-2 Indoor/Outdoor Temperature and Humidity Sensor.

  • Page 48: Setup Digital Communicator

    SETUP DIGITAL COMMUNICATOR To setup the Digital Communicator, from the Installer Setup menu, select the 3 (DCM) key. FIRST PHONE NUMBER, FIRST ACCOUNT NUMBER The first item in the DIGITAL COMMUNICATOR category is the FIRST PHONE NUMBER. Enter the FIRST PHONE NUMBER on the keypad.

  • Page 49: Report Open/Close

    After the transmission of the alarm to the central station, the operator can talk and listen to people and sounds at the premises. TWO-WAY AUDIO: 0=NO 1=YES If a Two-Way Audio Module is part of the system, select the 1 (YES) key to enable this feature. REPORT OPEN/CLOSE The communicator can be setup to send an opening and a closing report by user code.

  • Page 50: Setup Areas

    ZONE 1 ALARM CODE: 0-FF THROUGH USER 16 CLOSE CODE: 76 ↑ 0-FF SETUP AREAS To configure the system for multiple areas, from the Installer Setup menu, press the 4 (AREA) key. The number of areas must be specified. Also, consoles, zones, units, thermostats, and buttons must be assigned to areas. By default, the system is setup for one area.
  • Page 51 UNITS 285-288 AREAS: UNITS 373-376 AREAS: UNITS 465-472 AREAS: 1 2 3 4 5 6 7 8 0=CLR 1 2 3 4 5 6 7 8 0=CLR 1 2 3 4 5 6 7 8 0=CLR UNITS 289-292 AREAS: UNITS 377-380 AREAS: UNITS 473-480 AREAS: 1 2 3 4 5 6 7 8 0=CLR...

  • Page 52: Setup Areas: Zones

    SETUP AREAS: ZONES To assign zones to areas, from the Setup Areas menu, press 2 (ZONE). Each zone must be assigned to one and only one area. ZONE 1 AREA: ↓ THROUGH ZONE 176 AREA ↑ SETUP AREAS: BUTTONS To assign groups of macro buttons to specific areas, from the Setup Areas menu, press the 3 (BTTN) key. Buttons can be configured so that they can only be activated from a particular area or from any area.

  • Page 53: Set-Up Areas: Thermostats

    SET-UP AREAS: THERMOSTATS To assign thermostats to specific areas, from the Set-up Areas menu, press the 5 (TEMP) key. Thermostats can be set up so that they can only be controlled from a specific area or from all areas. PESMs and Temperature Sensors can only be controlled from a single area, as specified in SETUP AREAS.

  • Page 54: Thermostat Type

    THERMOSTAT TYPE If HAI thermostats are part of the system, this item specifies the thermostat type for each thermostat (this enables the thermostat). If thermostats are used, they must be configured to the applicable thermostat type. When any THERMOSTAT TYPE is changed from the default setting of "Not Used", Zone 16 and Output 8 is automatically configured for thermostats.

  • Page 55: Pc Access Code

    PC ACCESS CODE This code allows dealers to put an access code in the system that is separate from the customer's Master code and the Installer code. Dealers can use the PC Access code to access the system by PC. The PC Access code cannot arm and disarm the system. The PC Access code is NOT programmed from the factory.

  • Page 56: Arming Confirmation

    ARMING CONFIRMATION The Arming Confirmation is a quick pulse (squawk) given by the outside siren when the alarm system is armed into a security mode and the EXIT DELAY is expired. ARMING CONFIRMATION: 0=NO 1=YES To enable the arming confirmation feature, press the 1 (YES) key, then press the ' # ' key. The default setting is 0 (NO) disabled.

  • Page 57: Enable Emergency Keys

    DEAD LINE DETECT NOTE: To disable OmniPro II from detecting a dead line, set this item to '0'; otherwise adjust only under direction of HAI. This item adjusts the threshold that is used to determine when the phone line goes dead.

  • Page 58: Clock Adjustment

    The default setting is 30. MODEL AND SOFTWARE VERSION Next, the model number and software version for the system is displayed: HAI OMNIPRO II S/W VERSION 2.0 RESET SYSTEM EEPROM Select the 1 (YES) key to reset the EEPROM. All programs, names, and setup items will be reset. All system RAM will also be initialized and the system will restart.

  • Page 59: Setup Expansion

    SETUP EXPANSION To configure each Expansion Module that is installed on your system, from the Installer Setup menu, press the 7 (EXP) key. Expansion Modules include Hardwire Zone Expanders, ALC Interface Modules, and Serial Interface Modules using either the Omni-Link or Pro-Link Protocol. MODULE 1 TYPE The Module Type defines the function of each expansion module on the controller.

  • Page 60: Serial 1 Function

    SERIAL 3 FUNCTION The “Serial 3 Function” by default is set to UPB to utilize HLC Lighting. When using HLC, plug the HAI Powerline Interface Module (PIM) into the third built-in serial interface (J3 Serial) on the OmniPro II controller. To change the “Serial 3 Function”, select the function for the built-in serial interface from the list.

  • Page 61: Setup Zone Options

    SETUP ZONE OPTIONS Zone options are parameters that define the way that a zone functions. There are global zone options that affect all zones and there are individual zone options that affect how each individual zone functions. To configure zone options, from the Installer Setup menu, press the 8 (ZOPT) key. SWINGER SHUTDOWN NUMBER Swinger Shutdown is a false alarm prevention feature that counts the number of alarms caused by a specific zone.

  • Page 62: Sia Cp-01 Compliance

    SIA CP-01 COMPLIANCE This control complies with the SIA CP-01 Control Panel Standard - Features for False Alarm Reduction. CP-01 is a standard sponsored by the Security Industry Association (SIA) designed with features for security systems and associated arming and disarming devices intended to reduce the incidence of false alarms. PROGRAMMABLE FEATURES SHIPPING DEFAULTS AND RECOMMENDED PROGRAMMING CP-01...

  • Page 63: Omnipro Ii Specifications

    OMNIPRO II SPECIFICATIONS Size: Controller: 13 W x 13 H x 4.5 D Console: 4.6 W x 4.5 H x 1.2 D Weight: Controller: approx. 10 lb. Console: approx. 0.5 lb. Operating 32 - 122 degrees F (0 - 50 degrees C) Ranges: 10 - 95 % relative humidity, non-condensing Power:...

  • Page 64: Underwriter's Laboratories (Ul) Installation Requirements

    UNDERWRITER'S LABORATORIES (UL) INSTALLATION REQUIREMENTS The OmniPro II control units (20A00-2, -5, and -22) are suitable for Grade A household burglar and fire applications. Refer to UL1641 for installation requirements. Model 20A00-5 is also suitable for use in Commercial Burglar Alarm Applications, Grade B, C Central Station, Grade A Local, and Grade A Police Connect.

  • Page 65: 24-Hour Standby Battery Capacity

    24-HOUR STANDBY BATTERY CAPACITY Maximum current ratings for 24-hours: Aux 12 VDC, Switch 12 VDC, Console, and Outputs 1-8: 250 mA Interior Horn and Exterior Horn: 350 mA 3M, P/N 952 SNAP CONNECTOR OVER WIRE 12" 12" BLACK BLACK WIRE TO - RED WIRE TO + BATTERY BATTERY...

  • Page 66: Smoke Detector Installation Guidelines

    SMOKE DETECTOR INSTALLATION GUIDELINES 1. Ceiling mounted smoke detectors should be located in the center of the room or hall, or not less than 4 inches from any wall. When the detector is mounted on a wall, the top of the detector should be 4 to 12 inches from the ceiling. 2.

  • Page 67: Appendix A - Contact Id Reporting Format

    APPENDIX A – CONTACT ID REPORTING FORMAT ZONE TYPE TRIP TROUBLE DESCRIPTION Entry/exit (also Double & Quad) Entry/exit burglary Perimeter (also Latching) Perimeter burglary Night Interior (also Latching) Interior burglary Away Interior (also Latching) Interior burglary Panic Panic alarm Police Emergency Panic alarm Silent Duress Silent panic...

  • Page 68: Appendix B - Digital Communicator Code Sheet

    APPENDIX B - DIGITAL COMMUNICATOR CODE SHEET INFORMATION FOR CENTRAL STATION Date: _________________________ Subscriber Name: ______________________________________________________________________ Address 1: ______________________________________________________________________ Address 2: ______________________________________________________________________ City, State, Zip: ____________________________________________ Home #: _______________________ Work #: _________________ Password: ________________________________________________ Installer Name: ______________________________________________________________________ Address 1: ______________________________________________________________________ Address 2: ______________________________________________________________________ City, State, Zip: ____________________________________________...
  • Page 69 CODE ZONE DESCRIPTION ACTION TO TAKE TEST CODE _________________________ __________________________________ ZONE 1: _________________________ __________________________________ ZONE 2: _________________________ __________________________________ ZONE 3: _________________________ __________________________________ ZONE 4: _________________________ __________________________________ ZONE 5: _________________________ __________________________________ ZONE 6: _________________________ __________________________________ ZONE 7: _________________________ __________________________________ ZONE 8: _________________________ __________________________________ ZONE 9:...
  • Page 70 CODE ZONE DESCRIPTION ACTION TO TAKE ZONE 56: _________________________ __________________________________ ZONE 57: _________________________ __________________________________ ZONE 58: _________________________ __________________________________ ZONE 59: _________________________ __________________________________ ZONE 60: _________________________ __________________________________ __________________________________ ZONE 61: _________________________ ZONE 62: _________________________ __________________________________ ZONE 63: _________________________ __________________________________ ZONE 64: _________________________ __________________________________ ZONE 65:...
  • Page 71 CODE ZONE DESCRIPTION ACTION TO TAKE ZONE 114: _________________________ __________________________________ ZONE 115: _________________________ __________________________________ ZONE 116: _________________________ __________________________________ ZONE 117: _________________________ __________________________________ ZONE 118: _________________________ __________________________________ ZONE 119: _________________________ __________________________________ ZONE 120: _________________________ __________________________________ ZONE 121: _________________________ __________________________________ ZONE 122: _________________________ __________________________________ ZONE 123:...
  • Page 72 CODE ZONE DESCRIPTION ACTION TO TAKE ZONE 170: _________________________ __________________________________ ZONE 171: _________________________ __________________________________ ZONE 172: _________________________ __________________________________ ZONE 173: _________________________ __________________________________ ZONE 174: _________________________ __________________________________ ZONE 175: _________________________ __________________________________ ZONE 176: _________________________ __________________________________ FREEZE ALARM _________________________ __________________________________ FIRE EMERG _________________________ __________________________________ POLICE EMERG...

  • Page 73: Appendix C - Zone And Unit Mapping

    APPENDIX C - ZONE AND UNIT MAPPING ZONE DEVICE Zones 1-16 Zones 1-16 on Controller Zones 17-32 Zones 1-16 on 1st Model 10A06 Hardwire Expander Zones 33-48 Zones 1-16 on 2nd Model 10A06 Hardwire Expander Zones 49-64 Zones 1-16 on 1st Model 17A00 Expansion Enclosure Zones 65-80 Zones 1-16 on 2nd Model 17A00 Expansion Enclosure Zones 81-96...
  • Page 76 HAI • New Orleans, LA • U S A...
